Coral Terminal Equipment
be attached to the FlexSet 280/281 series sets. The first FlexSet 40B is listed as device
ID #4, the second as device ID #5, and the third as device ID #6; the APA is ID #6.
Keyset Definition __________________________________________ (Route: KEY) .
An operating profile for each keyset is defined in the keyset definition. In addition
to the information in Database Programming on page 1-9 the following parameters
must be defined for FlexSet 40Bs:
ACTIVE DPEM ID'S
INSTALLED DPEMS

Parameters Relevant for Turret Console Applications

Sizes Definition ____________________________________________ (Route: SIZ) .
The maximum number of turret consoles allowed for the system is controlled by
the following parameter:
TURRET CONSOLE
Keyset Definition __________________________________________ (Route: KEY) .
Assign terminals using the following parameter:
TURRET Console Extended DPEM
Assign a partner terminal to a FlexSet 280/281 by defining this parameter as the
partner keyset number. This then sets that keyset as a secondary. An "s" identifier
automatically appears to the right of the secondary keyset number.
The dial number of the primary keyset will automatically appear with a "p"
identifier in the TURRET Console Extended DPEM parameter under Keyset
Definitions of the phone defined as secondary.

Programming Buttons

To program a FlexSet 40B button from the keyset, follow the instructions in
Programming the Buttons on page 1-13.
