Specifications

Relay Contacts:
Connectors............................................................ RJ-11 (two conductors 2/5)
Contact Type......................................................... Isolated (Dry) Form A (SPST-NO)
Voltage Limit ........................................................ 48VDC Max.
Switching Limit.................................................... 220VDC/250VAC Max.
Current Limit........................................................ 1.0A Max non-inductive
Power Limit.......................................................... 0.5A @ 120VAC
External Paging (600 Ohm):
Connectors............................................................ RJ-11 (2 centered conductors 3/4)
Termination .......................................................... Capacitor-coupled transformer, non-grounded
Impedance ON...................................................... less than 600Ω Nom.
Impedance OFF .................................................... less than 6KΩ. Nom
Output Level......................................................... –15dBm Nom (1dBm max.)
External Paging (Hi-Z):
Connectors............................................................ RCA
Termination .......................................................... Resistor and capacitor-coupled transformer,
Impedance ON...................................................... 22KΩ
Impedance OFF .................................................... 22KΩ
Output Level......................................................... 1V / 100KΩ max.
1.0A @ 30VDC
non-grounded
