Desk Elevation Bracket (28 Degree); Desktop Elevation Rubber Bumpers - Tadiran Telecom FlexSet 280 Manual

2
A. Unpacking the Shipping Container
B. Elevating the FlexSet on the Desktop
Figure 3-9 Desktop
Elevation Rubber
Bumpers
3-8
Coral Terminal Equipment
Desk Elevation Bracket (28
The FlexSet Wall Mount and Desktop Elevation kit includes the following items:
One (1) plastic wall mount bracket
Cat.No. 7244-8131540 pearl white
Cat.No. 7244-8131548 dark gray
Three (3) tap screws (used when wall mounting)
Three (3) wall plugs (used when wall mounting)
Two (2) rubber bumpers (used when wall mounting)
The Wall Mount bracket may be used to elevate the FlexSet on a desktop in order to
lower the viewing angle of the keyboard, instead of being used to mount the phone on
a wall.
Rubber
Feet
1. Put the handset and line cords into the grooves located at the side and top of the
phone's back, respectively.
Hold both the telephone and the desktop elevation bracket with the thin ends
2.
downward.
3. Place the bracket's legs, located on the thin edge of the bracket, into the matching
narrow slots on the bottom of the phone towards the thin edge, as shown in Figure
3-10 and Figure 3-11.
)
degree
