Tadiran Telecom FlexSet 280 Manual page 56

Figure 3-16 Handset
hook
C. Removing the Telephone from the Elevation Stand
3-14
Coral Terminal Equipment
Handset
Off-Hook
Removable
Handset
On-Hook
Place
Telephone
Number
here
under
plastic
cover
To remove the phone from the Desk Elevation Stand:
1. Disconnect the telephone line plug from the telephone.
2. Hold the telephone, with the stand upright, perpendicular to the desk.
Push down firmly on the Desk Elevation stand at the point where the top legs join
3.
the slots.
The top legs release from the slots.
4. Once the top legs are released, gently pull the bottom legs from the slots.
Step 1
Lift and remove the
tab from the
opening
Step 2
Rotate the tab
Step 3
Re-insert the tab into
the opening with the
projection
at the edge of the
tab extended out
