Figure 3-3 Inserting the
Rubber Bumpers to
FlexSet 280x
Figure 3-4 Fitting the
Wall Mount Base to
FlexSet
3-4
Coral Terminal Equipment
9. Insert the two rubber bumpers into upper holes, as shown in Figure 3-3.
Insert rubber bumpers
into upper holes
10. Mount the telephone on the wall, place the slots on the bottom of the phone (A)
towards bottom legs of the bracket, and snap them in place, as shown in Figure
3-4.
11. Snap the legs, located on the top of the bracket, into the matching slots (B) at the
top of the phone, as shown in Figure 3-4.
Step 2
Lift phone and push
upper slots (B)
over top legs
Step 1
Slip lower slots (A)
over bottom legs
(B)
(A)
