Table 9-3 FlexAPDL
RS-232E Interface Pin
Functions
9-6
Coral Terminal Equipment

Connecting the FlexAPDL to a PC

1. Attach the D-Type connector side of the RS-232E cable to a free COM port on the
PC.
2. Attach the free RJ-45 connector to the jack marked RS-232 on the rear of the
FlexAPDL.
Pin Designation
Data Carrier Detector (DCD)
Receive Data (RD)
Transmit Data (TR)
Data Terminal Ready (DTR)
Signal Ground (GND)
Data Set Ready (DSR)
Request to Send (RTS)
Clear to Send (CTS)
Not Connected (NC)
Pin Number
RJ-45 9-Pin
Connector D-Type
2 1
5 2
6 3
3 4
4 5
1 6
8 7
7 8
9
Function
Output from FlexAPDL
Input to FlexAPDL
Input to FlexAPDL
Signal Return
Output from FlexAPDL
Input to FlexAPDL
Output from FlexAPDL
Not used
