Figure 3-2 Side View,
Completed Wall Mounting
Bracket
2. Using the Wall Mount Bracket as a template, mark the wall in the middle of the
vertical groove above the cutouts on the right and left sides (A) and at the top of
the long groove at the bottom center of the bracket (B), as indicated in Figure 3-1.
3. Use a small drill bit (#7, 13/64", 5mm or smaller) to drill three holes into the wall
for the mounting screws. The drilled hole should be wide enough to allow the
wall plugs to enter snugly.
4. Insert the three wall plugs into the holes.
5. Insert the three screws into the wall plugs, and partially tighten them to the wall,
taking care to leave enough space to insert the Wall Mount Bracket.
6. Mount the Wall Mount Bracket on the wall (see Figure 3-2), use the cut outs to
align the Wall mount bracket with the screws, and then slide it down into place.
7. Tighten the three screws completely.
8. Connect the handset and line cords and feed them into the groove located at the
top of the phone's back.
2 screws
1 screw
Wall Mounting
Bracket
3-3
Coral Terminal Equipment
