2
Table 7-1
Coral FlexSet
40B Capabilities and
Pre-Installation
Requirements
7-4
Coral Terminal Equipment
Pre-Installation Requirements
In order to connect a FlexSet 40B, the FlexSet 280/281 must be equipped with a PEX or
PEX/APA module as described in Table 7-1.
Model Name
FlexAPDL
FlexSet 120/121
FlexSet 280
PEX-FS, PEX/APA-FS, or PEX-F
FlexSet 280D
PEX-FS, PEX/APA-FS, or PEX-F
FlexSet 280D-Z
PEX-FS, PEX/APA-FS, or PEX-F
FlexSet 280S
PEX-FS, PEX/APA-FS, PEX-F, or PEX/APA-F
FlexSet 281S
PEX-FS, PEX/APA-FS, or PEX-F
The PEX or PEX/APA must be powered by a TPS power adapter located near the
FlexSet 280/281, or through the FlexSet 280/281 line cord from a source at the main
distribution frame.
Base Adapter Required
—
—
External Power
Required (TPS)
—
—
Must
Must
Must
Must
Must
