Table 2-3 Display Size
Mismatch Errors
Table 2-4 Display Size
(Coral Version 15 or
higher)
2-12
Coral Terminal Equipment

Displays

Installing FlexSet telephones with a display size or type different than the Coral
default requires making manual changes to the PI (Program Interface). This
parameter cannot be specified for FlexSet phones that are identified by the system as
being without displays. In order to change the display parameter:
1. Go to the PI branch: KEYSET Definition
2. Set the parameter DISPLAY_SIZE to reflect the actual size of the telephone display.
If the Coral incorrectly identifies the actual display size of the telephone, the display
will be incorrect. The following tables list the possible display discrepancies:
Table 2-3 "Display Size Mismatch Errors",
Table 2-4 "Display Size (Coral Version 15 or higher)"
Table 2-5 "Display Size (Coral Version 14.67 and below)"
Actual Size
DSP48
DSP80
Entry Type
0 No display
2 DSP48
3 DSP80
6 DSP72
7 DSP120
(Route: KEY)
PI Setting
DSP80
DSP48
Description
FlexSet 120 &120L/DST/ADPL/CPA
FlexSet 120D (2 rows x 24 characters)
FlexSet 120S/121S) 3 rows x 24 ch.
3rd line is controlled by FlexSet software
FlexSet 280D & 280D-Z (2 rows x 40 ch.)
FlexSet-IP 280S, FlexSet 280S/281S (3 rows x 40 ch.)
3rd line is controlled by FlexSet software
GKT/FlexSet 80 (Graphic Display)
FlexSet 120S/121S (3 rows x 24 characters)
3rd line is controlled by main Coral software
FlexSet 280S/281S (3 rows x 40 characters)
3rd line is controlled by main Coral software
.
Result
The display appears garbled
The display moves right and shows
16 x 2 characters
