Figure 1-7
FlexSet
280S and 281S Top Plate
Removal
Figure 1-8
FlexSet
280D and 280D-Z Top
Plate Removal
Printing the multi-designation label:
1.
Use the DESI software to select the layout of your multi-designation label (as
described on the previous page).
2.
Enter the extensions assigned to the buttons on your FlexSet and the telephone
number.
3.
Feed your printer with the label sheet.
4.
From the DESI Plus/DESI Lite menu, choose
The left column on the multi-designation label is intended for the four system
defined fixed keys. Other columns are intended for the programmable speed
dial keys.
5.
To attach the label to the FlexSet, lift the top plate as shown in the figures below,
insert the label and replace the top plate. To attach the telephone number, see
Placing the Telephone Number on page 1-13.
File > Print
Lift up to remove cover
Lift up to remove cover
.
1-15
Coral Terminal Equipment
