DSA3200-PTP
ERROR: CALB baro value not valid
The value was not entered, negative, or not numeric
ERROR: CALB period value not valid
The value entered was outside the range of the PERIOD variable.
ERROR: CALB average value not valid
The value entered was less than 1 or greater than 240.
ERROR: Calb data error
Fatal hardware error - The module did not enter or complete the scan.
ERROR: CALZ period value not valid
The value entered was outside the range of the PERIOD variable.
ERROR: CALZ average value not valid
The value entered was less than 1 or greater than 240.
ERROR: Calz data error
Fatal hardware error - The module did not enter or complete the scan.
ERROR: Zero value not valid
ERROR: Zero channel value invalid
The value for the variable was not entered or is not numeric
ERROR: Zero channel not between 0 and 15
The number entered was negative or greater than 15
ERROR: Delta value not valid
ERROR: Delta channel value invalid
The value for the variable was not entered or is not numeric
ERROR: Delta channel not between 0 and 15
The number entered was negative or greater than 15
ERROR: Dout channel not present
The DOUT channel and condition was not entered
ERROR: Dout channel invalid
The DOUT channel number entered less than 1, greater than 5, or not numeric.
ERROR: Dout data missing
The DOUT condition was not entered
ERROR: Dout data value not valid
The DOUT condition was not 0 or 1

Command Errors

ERROR: Mode ready, invalid command
ERROR: Invalid command
The command entered was not a DSA-PTP command
ERROR: Invalid set parameter
The configuration variable entered was not a DSA-PTP variable
ERROR: Invalid list parameter
The list parameter was not A, B, C, D, G, H, I, L, M, N, O, S, or Z.
ERROR: UPLOAD <S or C> value not found
S or C was not entered or was lower case
ERROR: UPLOAD file name not found
The file name was not entered, does not exist, or has an invalid path
ERROR: Insert's temp value not valid
The temperature values were either not entered, negative, or not numeric
ERROR: Insert's temp above <max temp>
The temperature value entered was greater than 69
ERROR: Insert's chan value not valid
The channel value was not entered or not numeric.
ERROR: Insert's chan above 15
The channel value entered was greater than 15
ERROR: Insert's pressure value not valid
