Section 5: Software

Ethernet Host (HOST)

Variable
Valid Values
Default Value
Data Type
Group
Description

Pressure Deltas (LIST D)

Deltas (DELTAn)

Variable
Valid Values
Default Value
Data Type
Group
Description

Zero Offsets (LIST Z)

Zero Offset (ZEROn)

Variable
Valid Values
Default Value
Data Type
Group
Description
HOST <IP Address> <Port> <Protocol>
IP Address - Any valid IP Address
Port - Any valid port number other than 0
Protocol - U for UDP
T for TCP
IP Address - 0
Port - 0
Protocol - T
varies
Identification variables (List I)
Sets the parameters for binary transmission to a host computer. The default port value is 23
which is the TelNet port. A change to this variable does not take effect until the module has
been rebooted. If PORT is set to zero, communications in Ethernet will be impossible.
DELTAn <value> (where n = 0-15 for channels 1-16)
+/- Full Scale Pressure Range
none
float
Pressure variables (List D)
Delta zero corrections for channels 1 - 16. These values are set when a CALZ is executed.
ZEROn (where n = 0-15 for channels 1-16)
-32768 to 32768
none
integer
Pressure variables (List Z)
The zero correction for channels 0 - 15. These values are set during the original calibration
and fill.
