Section 5: Software

Engineering Units (EU)

Variable
Valid Values
Default Value
Data Type
Group
Description

Data Format (FORMAT)

Variable
Valid Values
Default Value
Data Type
Group
Description

Frames Per Scan (FPS)

Variable
Valid Values
Default Value
Data Type
Group
Description
EU
0 or 1
1
string
Scan variables (List S)
Sets the output format for temperature and pressure units.
0 = raw units
1 = Engineering units
2 = Engineering units with floating point temperature (see DSA-PTP packet definitions)
NOTE:
The module will output 999999 when one or more of the following conditions exist:
1. The EU conversion exceeds the setting of PMAXL or PMAXH
2. The calculated temperature of any sensor is greater than 69 degrees C.
The module will output -999999 when one or more of the following conditions exist:
1. The EU conversion exceeds the setting of PMINL or PMINH
2. The calculated temperature of any sensor is greater than 69 degrees C.
When SET EU 2, time stamp data will not be possible.
FORMAT
0, 1, or 2
0
integer
Scan variables (List S)
Determines if data are to be scrolled on the display. ASCII Output only
0 - data is scrolled
1 - data is displayed in place, formatted for a VT100 terminal.
2 - data is displayed in CSV format
FPS
0 to 2147483648
1
long integer
Scan variables (List S)
Frames Per Scan (FPS) sets the number of averaged frames to send to the host computer
when a scan command is issued. Averaged frames will be sent to the host computer
until the value of FPS is met. At that time the DSA-PTP will exit the scan mode and wait
for another command. If a 0 is entered, the scan will continue until a STOP command is
received.
