Section 5: Software

List Master

Command
Command Syntax
Arguments
Description
Returns
Example
LIST MASTER
LIST M <Start Temp> <End Temp> [Channel]
<Start Temp> - The lowest temp plane to be returned.
<End Temp> - The highest temp plane to be returned.
[Channel] - (Optional) may be 0 through 15.
Lists all of the MASTER POINTS in the temperature-pressure correction matrix. The return
format is: INSERT <temp> <clear> <pressure> <pressure counts> M
INSERT <temp> <channel> <press> <press counts> M<nl>
: : : :
INSERT <temp> <channel> <press> <press counts> M<nl>
<temp> - the temperature plane
<channel> - The channel in module-port or serial number-port notation
<press> - the pressure in EU
<press counts> - the A/D counts of pressure
<nl> - end of line
To view the Master Points between 10 °C and 40 °C for channel 1 of the module, type:
List m 10 40 1<CR>
The DSA-PTP will return:
INSERT 14 1 -5.958100 -21594 M
INSERT 14 1 -4.476100 -15127 M
INSERT 14 1 -2.994200 -8646 M
INSERT 14 1 -1.470100 -1973 M
INSERT 14 1 0.000000 4467 M
INSERT 14 1 1.470100 10917 M
INSERT 14 1 2.994200 17594 M
INSERT 14 1 4.476100 24098 M
INSERT 14 1 5.958100 30603 M
INSERT 23 1 -5.958100 -21601 M
INSERT 23 1 -4.476100 -15161 M
INSERT 23 1 -2.994300 -8714 M
INSERT 23 1 -1.470100 -2077 M
INSERT 23 1 0.000000 4332 M
INSERT 23 1 1.470100 10746 M
INSERT 23 1 2.994200 17397 M
INSERT 23 1 4.476100 23863 M
INSERT 23 1 5.958100 30333 M
INSERT 32 1 -5.958100 -21636 M
INSERT 32 1 -4.476100 -15214 M
INSERT 32 1 -2.994200 -8784 M
INSERT 32 1 -1.470100 -2162 M
INSERT 32 1 0.000000 4228 M
INSERT 32 1 1.470100 10615 M
INSERT 32 1 2.994200 17246 M
INSERT 32 1 4.476100 23691 M
INSERT 32 1 5.958100 30136 M
