Channel 1-8 Minimum Pressure (Pminl); Channel 9-16 Minimum Pressure (Pminh) - Scanivalve DSA3217-PTP Series Operation And Service Manual

DSA3200-PTP

Channel 1-8 Minimum Pressure (PMINL)

Variable
Valid Values
Default Value
Data Type
Group
Description

Channel 9-16 Minimum Pressure (PMINH)

Variable
Valid Values
Default Value
Data Type
Group
Description
PMINL
any real number
determined by module type
float
Calibration Variables (List C)
Sets the minimum pressure for channels 1 - 8. This must be set to zero or to a positive
number if the module is an absolute module.
NOTE: The module will output -999999 if the measured pressure exceeds this value.
PMINH
any real number
determined by module type
float
Calibration Variables (List C)
Sets the minimum pressure for channels 9 -16. This must be set to zero or to a positive
number if the module is an absolute module.
NOTE: The module will output -999999 if the measured pressure exceeds this value.
53
53
Section 4: Hardware
