Section 5: Software
Scan EU Packet
Function Description
Packet Type
Pad bytes (forces quad byte alignment)
Frame Number
Channels 1-16 Pressure
Channels 1-16 Temperature
Scan Raw with Time Packet
Function Description
Packet Type
Pad bytes (forces quad byte alignment)
Frame Number
Channels 1-16 Pressure
Channels 1-16 Temperature
Time in milliseconds or microseconds
Time Units
Scan EU with Time Packet
Function Description
Packet Type
Pad bytes (forces quad byte alignment)
Frame Number
Channels 1-16 Pressure
Channels 1-16 Temperature
Time in milliseconds or microseconds
Time Units
Scan EU Packet with FPT - Floating Point Temperature (SET EU 2)
Function Description
Packet Type
Pad bytes (forces quad byte alignment)
Frame Number
Channels 1-16 Pressure
Channels 1-16 Temperature
Bytes
Data Type
2
Integer
2
Integer
4
Integer
64
Float
32
Integer
Bytes
Data Type
2
Integer
2
Integer
4
Integer
32
Integer
32
Integer
4
Integer
4
Integer
Bytes
Data Type
2
Integer
2
Integer
4
Integer
64
Float
32
Integer
4
Integer
4
Integer
Bytes
Data Type
2
Integer
2
Integer
4
Integer
64
Float
64
Float
58
58
DSA3200-PTP
Value/Notes
5Hex
unidentified
Current Frame Number
4 bytes per channel
2 bytes per channel
Value/Notes
6Hex
unidentified
Current Frame Number
2 bytes per channel
2 bytes per channel
2 bytes
1 = microseconds
2 = milliseconds
Value/Notes
7Hex
unidentified
Current Frame Number
4 bytes per channel
2 bytes per channel
2 bytes
1 = microseconds
2 = milliseconds
Value/Notes
9Hex
unidentified
Current Frame Number
4 bytes per channel
2 bytes per channel
