Scan - Scanivalve DSA3217-PTP Series Operation And Service Manual

DSA3200-PTP
Command
Command Syntax
Arguments
Description
Returns
Example

Scan

Command
Command Syntax
Arguments
Description
Example
SAVE
SAVE
None
Commands the DSA-PTP to save the RAM image of the Non Volatile Memory. Any change to
a configuration variable must be followed by a SAVE command if the change is to be perma-
nent.
<nl>
<nl> - End of line.
To save the current configuration variable settings and conversion coefficients,
Type: SAVE<CR>
SCAN
SCAN
None
Commands the DSA-PTP to scan the pressure sensors and send Scan packets to the client.
A scan command is executed with EU set to 1, BIN set to 0, and FORMAT set to 0. Data are
scrolled and will be displayed as follows:
Frame # <number>
Time <time> <µs or ms>
<chan> <press eu> <temp eu>
" " "
" " "
<chan> <press eu> <temp eu>
A scan command is executed with EU set to 0, BIN set to 0, and FORMAT set to 0. Data are
scrolled and will be displayed as follows:
Frame # <number>
Time <time> <µs or ms>
<chan> <press counts> <temp counts>
" " "
" " "
<chan> <press counts> <temp counts>
A scan command is executed with EU set to 1, BIN set to 0, and FORMAT set to 1. Data are
scrolled and will be displayed as follows:
Frame = <number> Time = <time> <µs or ms>
<chan> <press eu> <chan><press eu> <chan> <press eu> <chan> <press eu>
<chan> <press eu> <chan><press eu> <chan> <press eu> <chan> <press eu>
<chan> <press eu> <chan><press eu> <chan> <press eu> <chan> <press eu>
<chan> <press eu> <chan><press eu> <chan> <press eu> <chan> <press eu>
A scan command is executed with EU set to 0, BIN set to 0, and FORMAT set to 1. Data are
scrolled and will be displayed as follows:
Frame = <number> Time = <time> <µs or ms>
<chan> <press cts> <chan><press cts> <chan> <press cts> <chan> <press cts>
<chan> <press cts> <chan><press cts> <chan> <press cts> <chan> <press cts>
<chan> <press cts> <chan><press cts> <chan> <press cts> <chan> <press cts>
<chan> <press cts> <chan><press cts> <chan> <press cts> <chan> <press cts>
35
35
Section 5: Software
