DSA3200-PTP

Scan RAW/EU with PTP Time (SET TIME 3)

Function Description
Packet Type
Packet Size
Frame Number
Scan Average
Frame Rate
Spare
Units Index
Units Conversion Factor
Scan Start Time (s)
Scan Start Time (ns)
PTP Last Update (ms)
Temperatures
Pressures (RAW/EU)
Frame Time (s)
Frame Time (ns)
External Trigger Time (s)
External Trigger Time (ns)

ASCII Packet

Function Description
ASCII data (the first two bytes must NOT be
1Hex through 1FHex). Refer to the Command
Section of this manual for the proper Com-
mand return formats.
This packet will be transmitted when the host issues one of the following commands:
1. SCAN with BIN set to 0
2. LIST n
3. ERROR
4. STATUS
Bytes Data Type
4 Integer
4 Integer
4 Integer
4 Integer
4 Float
4 Integer
4 Integer
4 Float
4 Integer
4 Integer
4 Integer
32 Integer
32/64 Integer/Float
4 Integer
4 Integer
4 Integer
4 Integer
Bytes Data Type
1 to 1492
59
59
Section 5: Software
Value/Notes
AHex (10 dec)
Size of packet in bytes
Current frame number
Number of samples averaged
Scan Rate in Hz
0 (not used)
Units conversion index
Conversion Factor (PSI to selected units)
Scan start time in seconds
Scan start time in nanoseconds
Time since last update in milliseconds
4 bytes per channel
2/4 bytes per channel
Time the frame occurred in seconds
Time the frame occurred in nanoseconds
0 (not used)
0 (not used)
Value/Notes
Unique to packet.
Each line must be
String
terminated with a <CR>,
<LR>, <CR-LF> or <LF-CR>
