DSA3200-PTP

Page (PAGE)

Variable
Valid Values
Default Value
Data Type
Group
Description

Period (PERIOD)

Variable
Valid Values
Default Value
Data Type
Group
Description

QPKTS

Variable
Valid Values
Default Value
Data Type
Group
Description

Data Sample Source (SIM)

Variable
Valid Values
Default Value
Data Type
Group
Description
PAGE
0 or 1
0
integer
Scan variables (List S)
When set to 1, the DSA-PTP will accumulate 10 frames of data before the data is sent over
the network. If FPS is set to a number less than 10, the data will be sent over the network
when FPS is completed. When a STOP command is issued, the frame acquisition will stop on
a 10 frame boundary.
NOTE: This variable is active in UDP mode only.
PERIOD
73 to 65535
500
integer
Scan variables (List S)
Sets the interval between channel samples, in microseconds (μs). Period is related to the
scan rate, or frequency by the formula:
Data Rate = 1÷(Period* × 16 × Average)
*where period is in seconds
QPKTS
0 or 1
0
integer
Scan variables (List S)
This variable no longer functions and was left in place for legacy compatibility. Setting this
will not change behavior or cause an error.
SIM
0 or 1
1
integer
Scan variables (List S)
This variable no longer functions and was left in place for legacy compatibility. Setting this
will not change behavior or cause an error.
41
41
Section 5: Software
