DSA3200-PTP

Identification Variables (LIST I)

Serial Echo (ECHO)

Variable
Valid Values
Default Value
Data Type
Group
Description

Model (MODEL)

Variable
Valid Values
Default Value
Data Type
Group
Description

Ethernet Port (PORT)

Variable
Valid Values
Default Value
Data Type
Group
Description
ECHO
0 or 1
0
integer
Identification variables (List I)
Determines if characters received from a serial host will be echoed back to the host.
0 - the DSA-PTP will not echo characters
1 - the DSA-PTP will echo characters back to the host
MODEL
3207, 3217, 3218
3217
string
Identification variables (List I)
Determines the module type. When set to 3207, special variables are enabled to permit up
to eight(8) ranges in a module. The recommended setting of ZC depends on the setting of
MODEL. Please refer to the description of ZC for more information.
NOTE: MODEL must be set to 3207 in a 3217 or 3218 with absolute sensors installed if the
CALB function will be used.
PORT
any valid port other than 0
23
integer
Identification variables (List I)
Sets the Ethernet port. The default value is 23 which is the TelNet port. A change to this
variable does not take effect until the module has been rebooted. If PORT is set to zero, com-
munications in Ethernet will be impossible.
55
55
Section 5: Software
