DSA3200-PTP

Delete

Command
Command Syntax
Arguments
Description
Returns
Example

Digital Out

Command
Command Syntax
Arguments
Description
Returns
Example

Error

Command
Command Syntax
Arguments
Description
Returns
DELETE
DELETE <start temp> <end temp> [<channel>]
<start temp> - an integer from 0 to 79 that represents the low point of the temperature
planes to be deleted.
<end temp> - an integer from 0 to 79 that represents the high point of the temperature
planes to be deleted.
<channel> - (optional) the channel to be deleted.
Converts all pressure points within temperature planes between the low and high tempera-
ture range.
<nl>
<nl> - end of line.
To delete the master points for all modules in a system using eight 32 channel modules, the
following command would be issued: DELETE 0 79<CR>
To delete the master points for channel 4, the following command would be issued:
DELETE 0 79 4<CR>
To delete the master points for channel 16, the following command would be issued:
DELETE 0 79 16<CR>
DOUT
DOUT 1 <1 or 0>
None
Manual control of the Quick-Zero solenoid.
A "1" will activate the solenoid and allow air to flow from CTL SUPPLY to RTN.
A "0" will deactivate the solenoid and stop the flow.
<nl>
<nl> - end of line
To manually open the Quick-Zero solenoid:
DOUT 1 1
To manually close the Quick- Zero solenoid:
DOUT 1 0
ERROR
ERROR
None
The return format is:
ERROR: error
23
23
Section 5: Software
