Section 5: Software

List Temperature

Command
Command Syntax
Arguments
Description
Example

List Zero

Command
Command Syntax
Arguments
Description
Example

Save

LIST TEMPn
LIST TEMP <channel>
<channel> - channel number 0 through 15
Lists the 11 temperature coefficient terms for a specified channel
To view the current temperature coefficients for a channel, type: LIST TEMP <chan><CR>
The DSA-PTP will return the temperature coefficients for the channel.. They could appear as
follows.
SET TEMP 2 0 0.100000 -17381
SET TEMP 2 1 9.100000 -13551
SET TEMP 2 2 17.900000 -9535
SET TEMP 2 3 27.000000 -5355
SET TEMP 2 4 35.900002 -1040
SET TEMP 2 5 45.099998 3403
SET TEMP 2 6 54.099998 7990
SET TEMP 2 7 63.000000 12625
SET TEMP 2 8 72.000000 17358
SET TEMP 2 9 100.000000 0
SET TEMP 2 10 100.000000 0
SET TEMP 2 11 100.000000 0
NOTE: any temperature value of 100 degrees or greater is discarded and not used. If All chan-
nels are 100 0, the temperature will be shown as 25.00.
LIST ZERO
LIST Z
None
Lists the 16 zero correction values. These are used in the conversion of raw counts to zero
corrected counts.
To view the current zero correction values, type: LIST Z<CR>
The DSA-PTP will return the zero correction values. They could appear as follows.
SET ZERO0 261
SET ZERO1 -86
SET ZERO2 -49
SET ZERO3 -6
SET ZERO4 -20
SET ZERO5 47
SET ZERO6 44
SET ZERO7 23
SET ZERO8 -51
SET ZERO9 47
SET ZERO10 6
SET ZERO11 26
SET ZERO12 53
SET ZERO13 37
SET ZERO14 -57
SET ZERO15 -20
NOTE: The zero values will be updated after a CALZ.
