Section 5: Software

List Negative Points

Command
Command Syntax
Arguments
Description
Returns
Example

List Offset

Command
Command Syntax
Arguments
Description
Returns
Example
LIST NEGATIVE POINTS
LIST N
None
Lists the Negative Points settings for each of the 16 channels in a DSA3207. NOTE: This is
active only when MODEL is set to 3207.
SET NEGPTS0 <term>
SET NEGPTS1 <term>
SET NEGPTS2 <term>
:: :: ::
SET NEGPTS13 <term>
SET NEGPTS14 <term>
SET NEGPTS15 <term>
To view the negative points set for the module in the example of List Ranges type:
LIST L<CR>
The DSA-PTP will return the negative points settings. They could appear as follows.
SET NEGPTS0 4
SET NEGPTS1 4
SET NEGPTS2 4
:: :: ::
SET NEGPTS13 4
SET NEGPTS14 4
SET NEGPTS15 4
LIST OFFSET
LIST O
None
This list is no longer used in the DSA-PTP series. The command will still generate information,
however be padded with 0's. This temperature conversion was replaced with TEMP.
Lists the 16 temperature offsets. These are used in the conversion of temperature counts to
degrees Celsius. This is the "B" term in the correction equation:
Counts&TempB Counts&TempB
EC' EC'
TempM TempM
SET TEMPB0 <term>
SET TEMPB1 <term>
:: :: ::
SET TEMPB14 <term>
SET TEMPB15 <term>
To view the temperature offset settings. type: LIST O<CR>
SET TEMPB0 0
SET TEMPB1 0
:: :: ::
SET TEMPB14 0
SET TEMPB15 0
