List Calibrate; List Delta - Scanivalve DSA3217-PTP Series Operation And Service Manual

DSA3200-PTP

List Calibrate

Command
Command Syntax
Arguments
Description
Returns
Example

List Delta

Command
Command Syntax
Arguments
Description
Returns
Example
LIST CALIBRATE
LIST C
None
Lists the CALIBRATION configuration variables.
SET PMAXL<press>
SET PMAXH <press>
SET PMINL <press>
SET PMINH <press>
SET NEGPTSL <num points>
SET NEGPTSH <num points>
To view the current conversion variable settings, type: LIST C<CR>
The DSA-PTP will return the current conversion settings. They could appear as follows.
SET PMAXL 18.09
SET PMAXH 18.09
SET PMINL -18.09
SET PMINH -18.09
SET NEGPTSL 4
SET NEGPTSH 4
SET ABS 0
LIST DELTA
LIST D
None
Lists the 16 delta zero correction values. These are used in the conversion of raw counts to
Engineering Units(EU).
SET DELTA0 <delta>
SET DELTA1 <delta>
:: :: ::
SET DELTA14 <delta>
SET DELTA15 <delta>
To view the current delta zero correction values, type: LIST D<CR>
The DSA-PTP will return the delta zero correction values. They could appear as follows:
SET DELTA0 0.00000
SET DELTA1 -0.00243
SET DELTA2 0.00019
SET DELTA3 0.00000
:: :: ::
SET DELTA12 -0.00005
SET DELTA13 0.00000
SET DELTA14 0.00009
SET DELTA15 0.00042
NOTE: The delta values will vary as the module ages. These values are the difference
between the current zero offset value obtained in the most recent CALZ and the zero value in
the coefficient table.
27
27
Section 5: Software
