DSA3200-PTP

Pressure Variables (LIST B, LIST H, LIST L and LIST N)

Absolute Enable (ABSn)

Variable
Valid Values
Default Value
Data Type
Group
Description

Maximum Pressure (MAXn)

Variable
Valid Values
Default Value
Data Type
Group
Description

Minimum Pressure (MINn)

Variable
Valid Values
Default Value
Data Type
Group
Description

Negative Calibration Points (NEGPTSn)

Variable
Valid Values
Default Value
Data Type
Group
Description
ABSn (where n = 0-15 for channels 1-16)
0 or 1
determined by module type
integer
Calibration variables (List B)
Sets the mode of operation of the module. .
0 = gauge or differential
1 = absolute
Note: This value will determine the action of a CALZ or CALB being initiated. CALZ will only
initiate on channels with a value of 0. CALB will only initiate on channels with a value of 1.
MAXn (where n = 0-15 for channels 1-16)
0 through 500
15
integer
Calibration variables (List H)
Sets the maximum pressure for channel n. This must be set to zero or to a positive number if
the module is an absolute module.
NOTE: This variable is only used if MODEL is set to 3207.
MINn (where n = 0-15 for channels 1-16)
0 through 500
0
integer
Calibration variables (List L)
Sets the maximum pressure for channel n. This must be set to zero or to a positive number if
the module is an absolute module.
NOTE: This variable is only used if MODEL is set to 3207.
NEGPTSn (where n = 0-15 for channels 1-16)
0 to 8
4
integer
Calibration variables (List N)
Sets the number of negative calibration points for channel n. This must be set to zero or to a
positive number if the module is an absolute module.
NOTE: This variable is only used if MODEL is set to 3207.
51
51
Section 5: Software
