DSA3200-PTP

List All

Command
Command Syntax
Arguments
Description
Returns
Example
LIST ALL
LIST A <Start Temp> <End Temp> [Channel]
<Start Temp> - The lowest temp plane to be returned.
<End Temp> - The highest temp plane to be returned.
[Channel] - (Optional) may be 0 through 15.
Lists all of the master and calculated points in the temperature-pressure correction matrix.
The return format is:
INSERT <temp> <chan> <press> <pressure counts> <M>
INSERT <temp> <channel> <press> <press counts> <M><nl>
INSERT <temp> <channel> <press> <press counts> <M><nl>
: : : :
INSERT <temp> <channel> <press> <press counts> <M><nl>
<temp> - the temperature plane
<channel> - the channel in port notation
<press> - the pressure in EU
<press counts> - the A/D counts of pressure
<nl> - end of line.
To list all of the coefficients from 16 °C to 20 °C for channel 1 in a module calibrated from 17
°C to 40 °C type: LIST A 17 20 1<CR>
The DSA-PTP will return a list of INSERT commands showing the temperature, channel,
applied pressure, counts and the type of plane.
INSERT 17 1 -45.949100 -26184 M
INSERT 17 1 -31.250000 -17763 M
INSERT 17 1 -19.969601 -11302 M
INSERT 17 1 -6.250000 -3425 M
INSERT 17 1 0.000000 162 M
INSERT 17 1 19.984600 11636 M
INSERT 17 1 25.000000 14523 M
INSERT 17 1 35.000000 20281 M
INSERT 17 1 45.949100 26586 M
:: :: :: :: ::
INSERT 20 1 -45.949100 -26166 M
INSERT 20 1 -31.250000 -17750 M
INSERT 20 1 -19.969601 -11292 M
INSERT 20 1-1 -6.250000 -3424 M
INSERT 20 1-1 0.000000 160 M
INSERT 20 1-1 19.984600 11629 M
INSERT 20 1-1 25.000000 14514 M
INSERT 20 1-1 35.000000 20267 M
INSERT 20 1-1 45.949100 26567 M
::
25
25
Section 5: Software
