Section 1: Specifications

DSA3218-PTP

Size (WxHxD)
Weight
Pressure Inputs:
Input Fittings:
Pressure Inputs
Control Inputs
Full Scale Ranges
Differential
Absolute
Accuracy (after calibration)*
Differential
5 inH O
2
10 inH
20 inH
1.0 psid
2.5 psid
5 to 500 psid
501 to 750 psid
Absolute (With CALB performed)
15 psia
30 psia
50 psia
100 psia
250 psia
*Some combinations of pressure ranges in dual-range modules
may dictate a reduction in accuracy
Overpressure Capacity (No damage)
5 inH O
2
10 inH O
2
20 inH O
2
1.0 psid
2.5 to 499 psid
500 psid
750 psid
4.08" x 6.97" x 9.0"
(10.36 cm x 17.70 cm x 22.86 cm)
9.78 lbs
(4.45 kg)
16 (Standard)
8 (True Differential)
1/8" SwageLok®
(1/16" and 1/4" optional)
1/8" SwageLok®
(1/16" and 1/4" optional)
±5"WC, ±10"WC,
±20"WC, 1 , 2.5, 5, 15,
30, 50, 100, 250, 500,
750 psid
(1.25, 2.5, 5, 7, 17, 35,
100, 210, 345, 700, 1725,
3500, 5170 kPa)
15, 30, 50, 100 and
250 psia
(100, 210, 345, 700 and
1725 kPa)
±0.40% FS
O ±0.20% FS
2
O ±0.20% FS
2
±0.12% FS
±0.08% FS
±0.05% FS
±0.08% FS
±0.05% FS
±0.05% FS
±0.05% FS
±0.05% FS
±0.05% FS
2psi
2psi
2psi
5psi
200%
150%
113%
Maximum Reference Pressure
Power Requirements
No Heater
With Heater
I/O and mating connectors
Ethernet 100Base-T
Trigger (
bulkhead
Trigger ( )
mating
Trigger (
bulkhead
Trigger ( )
mating
Power (
bulkhead
Power ( )
mating
Communications Protocol
Typical Data Acquisition Rate*
TCP/IP ASCII
UDP Binary
*Maximum data output depends on network
Typical Communications Rate
Ethernet
RS232
Operating Temperature
Without Heater
With Heater
(Cooling kit recommended above 55 °C)
Compensated Range
Total Thermal Error
Humidity
Operation
Storage
Shock & Vibration
Shock
Vibration
Acceleration
Media
Precision Time Protocol IEEE-1588PTP v2
2
2
DSA3200-PTP
250 psid (1750 kPa) or
sensor overpressure,
which ever is less
20 to 36 Vdc at 8 W
20 to 36 Vdc at 40 W
(Drops to 8 W after
module has reached
temperature)
D-Code M12
) PT02A-8-2P
PT06A-8-2S-SR
) JTP02RE8-6P
JTO1RE8-6S-SR
) PTO2A-8-3P
PTO6A-8-3S-SR
Ethernet
IEEE802.3
50 samples/chan/sec
850 samples/chan/sec
100 Mbits/sec
9600 BAUD
(Configuration only
0 to 60 °C
-55 to 60 °C
0 to 72 °C
Less than ±0.001% FS
5 to 95% RH, Non-Condensing
5 to 95% RH, Non-Condensing
MIL-STD-810D Curve H
10G
10G
10G
Gasses compatible with Silicon,
Silicone, Aluminum and Stainless
Steel
