Zero Correction (Zc) - Scanivalve DSA3217-PTP Series Operation And Service Manual

DSA3200-PTP

Zero Correction (ZC)

Variable
Valid Values
Default Value
Data Type
Group
Description
ZC
0 or 1
1
integer
Scan variables (List S)
Sets zero correction on or off.
0 - no correction
1 - zero correction
NOTE 1: ZC must be set to 0 for the following conditions:
1. Model is set to 3207
2. The module has gauge transducers installed.
NOTE 2: ZC must be set to 0 for the following conditions:
1. Model is set to 3207
2. Absolute sensors are installed and the CALB command will not be used.
NOTE 3: ZC must be set to 1 for the following conditions:
1. Model is set to 3217 or 3218
2. Differential transducers are installed
NOTE 4: ZC must be set to 1 for the following conditions:
1. Model is set to 3207
2. Absolute sensors are installed and the CALB command will be used.
43
43
Section 5: Software
