Section 5: Software

Error Limit Variables (LIST LIMIT)

CAUTION! Changes to the LIST LIMIT variables can produce
scan readings that exceed the safe working max tem-
perature and max pressure ranges of the scanner and its
sensors. This could ultimately lead to damage in the unit. It
is not recommended to alter these variables unless advised.

High Temperature Error Limit (THI)

Variable
Valid Values
Default Value
Data Type
Group
Description

Low Temperature Error Limit (TLOW)

Variable
Valid Values
Default Value
Data Type
Group
Description

High Pressure Error Limit (PHI)

Variable
Valid Values
Default Value
Data Type
Group
Description

Low Pressure Error Limit (PLOW)

Variable
Valid Values
Default Value
Data Type
Group
Description
THI <degrees C>
any integer (see caution above)
0
integer
Limit Settings (List Limit)
Sets the amount of degrees (in Celsius) above high temperature allowed during a scan,
before returning with 999999 error.
TLOW <degrees C>
any integer (see caution above)
-10
integer
Limit Settings (List Limit)
Sets the amount of degrees (in Celsius) below low temperature allowed during a scan, before
returning with -999999 error.
PHI <percent of max pressure>
any integer (See caution above)
0
integer
Limit Settings (List Limit)
Sets the percent above the maximum high pressure allowed during a scan before returning
with 999999 error.
PLOW <percent of max pressure>
any integer (see caution above)
0
integer
Limit Settings (List Limit)
Sets the precent below the maximum low pressure allowed during a scan before returning
with -999999 error.
54
54
DSA3200-PTP
