Step 1: Unpack & Inventory
When you first unpack the DSA5000, begin by inspecting
and inventorying the contents of the package. If any visible
damage is immediately noticed or if any contents are miss-
ing, contact Scanivalve before proceeding. Modules ship
standard with:
1) DSA5000 Module
2) DSA5000 Accessory Kit
3) Certificate of Calibration
4) DSA Resource Disk (USB Drive)
There may be other cabling or accessories included with
your order. Fittings may or may not be installed on the
module at time of shipment.
Step 2: Connect Ethernet Cable
Connect a DSA Ethernet cable to the DSA Ethernet port. The
cable will thread into the connector.
If no DSA5000 Ethernet cable was purchased, the DSA5000
accessory kit will include a Ethernet mating connector that
can be used to fabricate an Ethernet cable and connection.
Step 3: Connect Ethernet Cable
Connect a DSA power cable to the DSA power port. The
cable will thread into the connector.
If an AC to DC power supply is provided (PDM series), con-
nect the power cable before powering on the power supply.
If no power supply or power cable is supplied, the DSA5000
accessory kit will include a power mating connector that can
be used to fabricate a power connection. This cable can be
connected to a compatible DC power supply (9 to 36VDC @
12W). See the wiring diagram on the right for lead connec-
tions (Red and Black).
CAUTION! Do not make or
break the power connector
with power applied! Doing so
risks damage to the module.
Once all connections are made, apply power to the DSA and
allow the module enough time to boot. The Power, Link and
Status lights should all light.
Step 4: Setup the Host Computer
DSA5000 Quick Start Guide
DSA5000 and Standard Accessories
to Ethernet
DSA5000 Cable Connections
P
N I
2
P
N I
3
P
N I
4
DSA Ethernet Mating Connections
Serial RX (BLUE)
Serial TX (YLW)
T +
I R
G
(
G
R
N
)
T -
I R
G
(
G
R
) Y
+
V
N I
R (
E
D
)
+
V
N I
(
W
H
) T
G
N
D
(
O
R
G
)
G
N
D
(
L B
) K
C
H
A
S S
S I
G
N
D
DSA Power Mating Connections
to DC Power
P
N I
1
P
N I
8
P
N I
7
P
N I
6
P
N I
5
M12
1
2
3
4
5
6
7
8
B (
A
R
) E

Advertisement

loading
Need help?

Need help?

Do you have a question about the DSA5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Scanivalve DSA5000

  • Page 1 If an AC to DC power supply is provided (PDM series), con- nect the power cable before powering on the power supply. If no power supply or power cable is supplied, the DSA5000 accessory kit will include a power mating connector that can be used to fabricate a power connection.
  • Page 2 Please consult your computer or operating system for steps on how to configure your computer’s IP address. Step 5: Access the DSA’s Web Server The DSA5000 has a single user web server which provides a simple method for communication, configuration and data collection from virtually any host computer.
