Specifications - Shimadzu IonFocus Instruction Manual

6

Specifications

Ionization unit
(ESI/DUIS)
DL
Heat block
Interface heater
*1 For DUIS, the focus voltage serves as the needle voltage.
Required gas
66
™
IonFocus Unit
Item
Drying gas
Nebulizer gas
Heating gas
Probe voltage
Focus voltage
Sample flow rate
(max.)
Temperature
Voltage
Temperature
Temperature
Item
Nitrogen gas
Supply pressure:
Purity:
Max. flow rate
during use:
Ar gas
Supply pressure:
Purity:
Flow rate during use: Approx. 10 mL/min
Dry air
Supply pressure:
Purity:
Max. flow rate
during use:
Specifications
Max. flow rate 20 L/min
Max. flow rate 3.0 L/min
Max. flow rate 25 L/min
±5 kV max.
±5 kV max. *1
2 mL/min
300 °C max.
±100 V
500 °C max.
400 °C max.
Specifications
690 to 800 kPa
99.5 % or greater
(For nitrogen generator): 97 % or
greater
23.0 L/min
500 to 800 kPa
99.99 % or greater
690 to 800 kPa
Water-free, Oil-free
25 L/min
