1 Outline and Configuration
1.3

Component Parts

This product is composed of the following parts. When unpacking the product, check the
details and quantity of each item.
No.
1
2
3
4
5
6
7
8
2
IonFocus
Unit
Part Name
Ion focus ESI unit ASSY
Focus unit ASSY
DUIS focus unit ASSY
Plug
Ground plate
Knurled screw, GND
Wrench, hex 1.5
Screwdriver, DS-13
Part No.
Q'ty
S225-19550-43
1
S225-41576-41
1
S225-41576-42
1
-
1
S225-41691
1
S225-41682
1
-
1
-
1
Remarks
High-voltage socket blank
