Shimadzu IonFocus Instruction Manual page 91

Part Name
TEMPERATURE SENSOR
MESH, NX, 1
MESH, NX, 2
MESH, NX, 3
MESH, NX, 4
MESH KIT
NEBULIZER NOZZLE
SUS COUPLING
COUPLING
MALE NUT, PEEK
O-RING, 4D P10
O-RING, 4D S3
O-RING, 4D S6
O-RING, 4D S8
O-RING, 4D S50
O-RING, 4D S53
O-RING, 4D S105
O-RING, 4D S2
HALF UNION, KQB2L23-M5
JOINT, KQ2B2L23-M5
HALF UNION, GWJS3-M3
INSULATOR HEATER
INSULATOR
AG INSULATOR, LONG
SUPPORT PLATE
GND PLATE
KNURLED SCREW, GND
PIN, GND
NUT, SUS #1 M2
LOW HEAD SCREW M3×5,
NICKEL PLATED
WASHER, UUW-0309-10H
HEATER CABLE ASSY, NX
FOCUS UNIT ASSY
FOCUS ELECTRODE 1
FOCUS ELECTRODE 2
KNURLED NUT 1
KNURLED NUT 2
Part No.
S225-19560-42
S225-41669
S225-41670
S225-41671
S225-41672
S225-42246-41
S225-19597
S228-16447-03
S225-14903
S228-18565-84 5 included
S036-11208
S036-19004-00
S036-19004-03
S036-19004-05
S036-19004-38
S036-19004-39
S036-19004-54
S036-19004-66
S035-65477-11
S035-65477-01
S225-65478-01
S225-19491
S225-19559
S225-19589
S225-41692
S225-41691
S225-41682
S225-41551
S023-04020
S225-14287-44 For securing the SUPPORT PLATE
S023-66210-03
S225-19494-45
-
S225-41561
S225-41574
S225-41563
S225-41558
7.2 Spare Parts
Remarks
™
IonFocus Unit
7
69
