228-97204A Jun. 2022 Flow Channel Selection Valve For Shimadzu Liquid Chromatograph FCV-S CL Instruction Manual Read this manual thoroughly before you use the product. Keep this manual for future reference.
Page 3
Shimadzu representative to request a replacement. • To ensure safe operation, read all the Safety Guideline, before using this product. • To ensure safe operation, contact your Shimadzu representative if product installation, adjustment, re-installation (after the product is moved), or repair is required.
Page 4
Third-party trademarks and trade names may be used in this publication to refer to either the entities or their products/services, whether or not they are used with trademark symbol "TM" or "®". ã 2020-2022 Shimadzu Corporation. All rights reserved. Original version is approved in English. FCV-S CL...
Indicates the location of related reference information. Electromagnetic Compatibility Descriptions in this section apply only to the following model: • 228-65600-55 FCV-S CL This product complies with European standard EN61326, class A for electromagnetic interference (Emissions) and industrial electromagnetic environment (Immunity).
Page 6
When, for example, analyzing samples that contain complex sample matrices such as serum, plasma or urine, it may be possible to obtain stabilized data by using an appropriate pre-treatment or an internal standard. FCV-S CL...
........3.2.1 Piping the Analysis Flow Line ....3.2.2 Piping the Waste Liquid Flow Line (FCV-S CL) Turning On the Equipment ........Turning Off the Equipment ........ Using the FCV-S CL with Manual Operation ..Remote-Controlling the Equipment from Autosampler SIL-40 CL series ......
Page 8
Prior to Inspection and Maintenance ....5.1.2 List of Periodic Inspection and Maintenance Cleaning the Exterior ..................5.2.1 Usual cleaning ........5.2.2 Decontamination cleaning Technical Specifications ............ Information Maintenance Parts ..................6.2.1 Consumable Parts ..........6.2.2 Replacement Parts Index ............FCV-S CL...
This instrument switches the communicating ports by rotating a rotor component with a channel groove. FCV-S CL is a unit for controlling one flow channel selection valve. The flow line can be switched by using the operation buttons on the front side of the unit.
Not used in CL model. ASSY Use this to remote-control the unit from Autosampler SIL-40 CL series. COMMUNICATION "3.6 Remote-Controlling 228-71807-41 CABLE the Equipment from Autosampler SIL-40 CL series" P.11 TERMINAL, 071-03511-01 Not used in CL model. 177766-1 FCV-S CL...
80 MPa For high speed analysis For ultra high speed FCV-0206H3 228-65624-58 Two-position six-port 130 MPa analysis Six-position FCV-0607H 228-65608-58 80 MPa For high speed analysis seven-port Six-position For ultra high speed FCV-0607H3 228-65625-58 130 MPa seven-port analysis FCV-S CL...
Parts Identification and Function FCV-S CL 2.1.1 Front Name Description Use this panel to view flow line positions and perform operations. Operation panel "2.1.3 Name and Functions of the Operation Panel" When a flow channel selection valve is inserted, a latch is Lock engaged to fix the flow channel selection valve in place.
2.1 FCV-S CL 2.1.2 Back Name Description Power connector This connector is for connecting the power cable. External I/O Not used in CL model. terminal This connector is for controlling this unit from other equipment. OPTION OUT When connecting multiple optional units, connect the slave unit terminal side to the OPTION OUT terminal.
Use this key to clear the error indication and alarm after [CE] key resolving the error condition. Use this key to manually switch the valve flow line in local Flow line mode. switching key "3.5 Using the FCV-S CL with Manual Operation" P.10 FCV-S CL...
When the flow channel selection valve is inserted all the way, the locks on the valve mount of the FCV-S CL engage and keep the valve in place. The illustration below shows the completed FCV-S CL after installing the flow channel selection valve.
"3.8 Relationship of Valve Position and Flow Line" P.20 3.2.2 Piping the Waste Liquid Flow Line (FCV-S CL) This section explains the connection of the flow line for waste liquid from FCV-S CL. Insert the supplied waste liquid tube (A) into the drain port located at the lower right corner on the front side of the equipment.
3.3 Turning On the Equipment Turning On the Equipment Turn on the power switch (A) located on the back side of FCV-S CL. Both LED indicators (Link LED and Error LED) on the operation panel light up, and the home position seeking for the flow channel selection valve starts.
Turn off the power switch located on the back side of FCV-S CL. Using the FCV-S CL with Manual Operation The FCV-S CL can be manually operated using the buttons on the operation panel. This section explains the settings for using the FCV-S CL with manual operation without connecting to other equipment.
The FCV-S CL can both be remotely controlled by autosampler SIL-40 CL series. When the instrument connected to the FCV-S CL is also connected to an CBM-40, a link check error occurs if the link check function is enabled. It is not a problem to clear the error and proceed.
When multiple FCV-S CL units are connected 3.6.3 Controlling the FCV-S CL in Remote Mode This section explains the procedure for controlling the FCV-S CL in remote mode. Turn off the power to the autosampler and to the FCV-S CL.
Page 21
FCV-S CL. To control multiple FCV-S CL units, connect a cable to the OPTION OUT terminal on the back side of the FCV-S CL and connect it with the OPTION IN terminal of the additional FCV-S CL. Turn on the power to the autosampler and to the FCV-S CL.
Valve flow line state can be changed by operating the flow line switching key on the operation Control by short-circuiting Local Manual panel of the FCV-S CL. the external I/O terminal mode operation Valve flow line changes when [<] is not available in local or [>] is pressed, and a number...
Page 23
Press the [Remote/Local switching button] again for one second to turn the link LED indicator back on and switch back to remote mode. Name Link key Link LED indicator Flow line switching key FCV-S CL...
3 Operation 3.6.5 Setting the Control ID To remote-control the FCV-S CL from autosampler SIL-40 CL series, you need to allocate a unique control ID to each driving unit FCV-DR. (Control ID that is not duplicated with another FCV-DR) Before starting control in remote mode, follow the steps below to check and set the control IDs.
Page 25
When setting a control ID, make sure that the number is not already used by another optional unit. Press the [CE] key again. You will hear a beep and see the flow line position on the display panel. FCV-S CL...
3.7.2 Shutting Down the Equipment This section explains how to shut down the FCV-S CL that is remote-controlled by autosampler SIL-40 CL series. Make sure that the FCV-S CL is remotely connected with autosampler SIL-40 CL series.
For the procedure to shut down from autosampler SIL-40 CL series, refer to the instruction manual for the respective instrument controlling the FCV-S CL. The display panel and all LED indicators light up on the FCV-S CL and the home position seeking starts for the flow channel selection valve.
The flow line indicated by the bold line in the figure above is for high-pressure delivery. To ensure a long service life for the rotor seal, connect the flow line with the highest pressure to port 4. FCV-S CL...
Wait about 10 seconds. If a leak is detected, the error LED indicator lights up in red, and error code "3" is displayed on the position display screen. If no leak is detected, there is no display. "4.2 Error Codes" P.33 FCV-S CL...
Page 30
[CE] key. A leak error cannot be cleared while the leak sensor is wet. The leak error is cleared when the leak sensor is dried off. FCV-S CL...
Failure to abide by the above may result in fire, electric shock, and/or product failure. Turn off the power to this product and disconnect the power plug before connecting cables to the terminals. Failure to abide by the above may result in fire, electric shock, and/or product failure. FCV-S CL...
POSITION 1 to 4 terminals. This is the output terminal used for error The rating is 30 V DC ERROR output. The ERROR terminal is short-circuited and 1 A. when an error occurs in the FCV. This GND terminal is for grounding. FCV-S CL...
Use a stranded cable whenever possible in order to prevent wire breakage in the cable. Use the supplied terminal to bundle multiple remote cables. Insert two remote cables (B and C) into terminal (A) and bundle them using pliers. FCV-S CL...
Connect the remote cables to the [VALVE POSITION] terminal 1 as well as the COM terminal. When using a two-position six-port valve, connect the remote cables as shown in the figure below. "3.10 Connection to External Input/Output Terminals" P.23 FCV-S CL...
Page 35
The flow line changes when the VALVE POSITION terminal and COM terminal are short-circuited. VALVE POSITION Flow Line ○ Open - (Not used) - (Not used) - (Not used) ● Short-circuit - (Not used) - (Not used) - (Not used) FCV-S CL...
Remove any optional control cable connected to the OPTION terminal. Turn on the power and set to remote mode. When the FCV is set to remote mode, the link LED indicator is lit. FCV-S CL...
Page 37
- (Not used) ○ Open ● Short-circuit ○ Open - (Not used) ● Short-circuit ● Short-circuit ○ Open - (Not used) ○ Open ○ Open ● Short-circuit - (Not used) ● Short-circuit ○ Open ● Short-circuit - (Not used) FCV-S CL...
Pressing the [CE] key stops the beeping, but does not clear the error. FATAL Remove the cause of the error and restart the system. Pressing the [CE] key clears the error. ERROR The beeping stops and the error LED indicator turns off. FCV-S CL...
Misalignment in Flow the rotation of channel Contact your Shimadzu representative. the flow channel selection selection valve. valve Sealing Fluid leaks from Flow performance in a gap in the...
Page 40
Misalignment in Flow selection valve is the rotation of channel operated. Contact your Shimadzu representative. the flow channel selection selection valve. valve If the link LED indicator is not lit, it means that this equipment is set to local mode.
PCB may selection valve be possible. may be Turn off the power, and contact damaged. your Shimadzu representative. If the flow channel selection valve rotates while the flow line is dry, Flow channel the greater friction generated can selection valve lead to a step-out.
Page 42
However, doing this will also clear the leak sensor adjustment values, Information in Information in etc., which need to be adjusted non-volatile non-volatile again. Contact your Shimadzu memory built ERROR memory built representative. into the FCV-DR into the FCV-DR could not be is corrupt.
Periodic Inspection and Maintenance It is necessary to perform periodic inspections of this instrument to ensure its safe use. It is possible to have these periodic inspections performed by Shimadzu service personnel on a contractual basis. For information regarding the maintenance inspection contract, contact your Shimadzu representative.
Page 44
5 Maintenance • Always stop the pump before starting any inspection or maintenance. • Follow the instructions in the manual when performing inspection or maintenance. FCV-S CL...
Cleaning the Exterior 5.2.1 Usual cleaning If the exterior of the instrument is dirty, clean it with a dry soft cloth or paper wiper. If it is very dirty, clean it as below. FCV-S CL...
Page 46
Wipe off detergent with a cloth soaked in water and wrung tightly and then wipe off water with a dry cloth. Do NOT leave any part wet nor use thinner for cleaning. Doing so may cause rust or discoloration. FCV-S CL...
The gas sensor may defect volatile gas generated from organic solvent. Clean with a cloth soaked in Aqueous ethanol solution (80%) or aqueous sodium hypochlorite solution (0.05%) and wrung tightly. Do not leave metal surfaces wet. This can cause rusting and discoloration. FCV-S CL...
*2 Connect the instrument to a power outlet that is equipped with a circuit breaker that shuts off the current at the described value or less. Installation Installation Category II, Pollution Degree 2, Altitude 2000 m or lower Environment Install inside a room. (IEC) FCV-S CL...
Remarks DRAIN TUBE FOR SYSTEM 228-66695 DRAIN TUBE SI(L1000) 228-25162-03 DRAIN ADAPTER 228-42204 STANDARD OUT DRAIN 228-42205 CTO OUT DRAIN 228-42206 STRAIGHT JOINT 228-28163 FITTING,L-TYPE 1253 035-61561-12 n Other parts Part Name Part No. Remarks COMMUNICATION CABLE 228-71807-41 FCV-S CL...
Page 50
Link key Link LED indicator local mode 10, 14 Manual Operation Number of Controllable Units OPTION IN terminal OPTION OUT terminal Remote Remote Mode 12, 14 Shutting Down Six-position seven-port valve Two-position six-port valve Valve Position Waking Up FCV-S CL...
