5 Maintenance

5.2.3 Cleaning the Spray Unit

Parts used
Holder
Guide
Screw M3 × 5
Drain mesh
If soiling cannot be removed, replace the part.
1
Remove the ionization unit.
2
Remove the ground plate and the focus unit ASSY or the DUIS focus unit ASSY.
46
™
IonFocus Unit
Part Name
"3.1.6 Removing the Ionization Unit" P.21
The inside of the ionization unit reaches a high temperature. Wait until the
temperature decreases sufficiently before handling or servicing the area.
The inside of the ionization unit and the area around the DL and heat block
reach high temperatures. Do not access the areas before the temperature
decreases sufficiently. Failure to observe this instruction may result in burn
injury.
"3.1.4 Removing the Focus Unit ASSY" P.15
"3.2.2 Removing the DUIS Focus Unit ASSY" P.28
Part No.
S225-41572
S225-41573
S225-14287-46
-
