7.3.1 Ionization Unit

No.
1 CAPILLARY ASSY
2 NEBULIZER NOZZLE
3 COUPLING, 1.6
4 COUPLING
5 PEEK TUBE 5999
6 MALE NUT, PEEK
7 O-RING, 4D-S8
8 NUT, KNURL
9 NUT, RID-6A
10 HEATER ASSY, NX
11 O-RING, 4D-P95
12 FOCUS UNIT ASSY
13 DUIS FOCUS UNIT ASSY
14 SUPPORT PLATE
15 GND PLATE
16 KNURLED SCREW, GND
17 PIN, GND
18 NUT, SUS #1 M2
LOW HEAD SCREW M3×5, NICKEL
19
PLATED
20 WASHER, UUW-0309-10H
21 FOCUS SOCKET CABLE ASSY
22 HEATER CABLE ASSY, NX
23 GND CABLE ASSY
- HEATER,SUPPORT PLATE ASSY ,PM
Part Name Part No.
S225-14948-91 Capillary ASSY consumables
S225-19597
S228-16447-03 SUS
PEEK (for securing capillary
S225-14903
tube)
Use 420 mm (purchase unit:
S228-32999-01
m)
S228-18565-84 5 included
S036-19004-05
For securing the capillary
S225-14914
tube
SUS, for securing the
S228-16034
coupling
S225-19560-46
S036-11267
S225-41576-41
S225-41576-42
S225-41692
S225-41691
S225-41682
S225-41551
S023-04020
S225-14287-44
S023-66210-03
S225-19473-42 HV cable for ion focus
S225-19494-45
S225-41592-41 GND cable for ion focus
Includes No.10, 14, 16, 17,
S225-42245-41
18, 19, 20
