3.

Overview

Front Bezel and Control Panels

Control
panel

Control Panel LED/Button Descriptions

007-5921-001
Chapter 3

MIS NAS Operation and GUI Startup

This chapter covers basic hardware operation and GUI startup for your MIS NAS system.
On the chassis, next to the bezel grille, you can see a control panel (reference Figure 3-1). There
is a control panel for each MIS NAS head server board in an SGI MIS NAS enclosure. There is
also a control panel for each I/O unit on an SGI NAS JBOD expansion enclosure.
sgi
Figure 3-1 MIS NAS Front Panel Example
The following list explains the control panel buttons and LEDs shown in Figure 3-2:
Power LED When this green LED is lit, the power is on.
33
