1: Introduction

Next Steps

Un-Racked NAS System Setup

Pre-Racked NAS System Setup

4
Caution: Floor loading has a maximum weight allowance of 250 lbs per square foot, not
including the service area. Floor loading must be less than 250 lbs per square foot, including the
service area. For maximum efficiency and performance, it is recommended that the maximum
number of enclosures in a single D-Rack is one MIS NAS enclosure with 4 JBODs.
Important: Be sure to read the additional safety information related to your SGI MIS NAS
system prior to completing the setup of the hardware, reference
If you need to install and configure the MIS NAS hardware components and cables, go to
Chapter 2, "MIS NAS System Hardware Installation."
using the subsections that follow in Chapter 2. Finish the system setup using the information in
Chapter 3, "MIS NAS Operation and GUI Startup."
If the system chassis is pre-installed in a rack, locate the drive modules and install them using the
information in "Installing Drives in the MIS or JBOD Enclosure" on page
be confirmed using the information in
system is ready to be plugged in and booted, go to
Startup."
Continue the drive and cable installation
"Cable Guide & Chassis Location" on page
Chapter 3, "MIS NAS Operation and GUI
Chapter 4, "System Safety."
25. System cabling can
28. When the
007-5921-001
