2: MIS NAS System Hardware Installation
Check all Cable Connections and Airflow
Check the Airflow
Supply Power to the System
32
Make sure all power and data cables are properly connected and not blocking the system airflow.
The system component layout was carefully designed to direct sufficient cooling airflow to the
components that generate the most heat.
Note: Make sure that all power and data cables have been routed in such a way that they do not
block the airflow generated by the enclosure fans.
Connect the power cords from all the power supply modules (located at the rear of each enclosure)
into a power strip or power distribution unit (PDU). An optionally available uninterruptible power
supply (UPS) can ensure power availability if primary power fails.
007-5921-001
