3: MIS NAS Operation and GUI Startup
34
If the system is off, push this button to power on the system. If the operating system
Power button
is running, push this button to shut down the operating system and power down gracefully.
Power LED
Status LED
Locator LED
Network Activity LED
Figure 3-2
MIS NAS Control Panel Buttons, Icons and LEDs
Tip: If the operating system is hung, you can hold the power button down continuously for 10
seconds or more to power off the system. This is a hard reset.
Power button
Reset button
Locator button
Boot Drive
Activity LED
NMI Reset
button
