KEYTEK CTS 2000 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C T
S
2
0 0 0
***************
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTS 2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for KEYTEK CTS 2000

  • Page 1 0 0 0 *************** INSTRUCTION MANUAL...
  • Page 2 INTRODUCTION The CTS 2000 is a programmable digital synthesizer with a dynamic keyboard that is part of a family of professional synthesizers and pianos. This instrument takes its name from a new sound acquisition and reproduction technology called CTS (Cross Table Sampled).
  • Page 3 Tables of content...
  • Page 5 384 bytes of memory compared to the 200,000 bytes required for standard sampling. All this has made it possible to equip the CTS 2000 with a considerable number of in-line sampled sounds that can be used immediately by the musician.
  • Page 6 There are two ways of connecting to the sound system: STEREO In stereo mode, the CTS 2000 sends voice-related signals in two separate audio channels (Left and Right) in a programmable way for each preset by defining for each Zone (octave) of the keyboard the...
  • Page 7 MONO Selecting this mode sends the sound to a single audio output. Once you have chosen the type of connection to be made, proceed as follows: Set the volume of the instrument and amplification or audio mi xer to zero and proceed to one of the following connections : Stereo Connect, via two ¼...

  • Page 8: Control Panel

    They are used both for preset selection and for special programming functions, which we will see later. The CTS 2000 is also equipped with a 2-line by 16-character LCD display that will show the type and number of presets enabled, information needed to edit presets or help messages.
  • Page 9 Interiors Pressing the INTERNAL button in the PRESETS section will enable the instrument's internal presets. In this way the display will show, in the upper row, the type, number and bank of the selected preset while the lower row will repeat the norm that has been assigned by the manufacturer or user to that preset, for example: INT PRESET 1A XXXXXXXXX...
  • Page 10 CARTRIDGE NOT PRESENT If you press the button when the cartridge is inserted, the message appears: CRT PRESET 1A XXXXXXXX In this case you will have recalled cartridge preset no.1, Bank A, named XXXXXXX. Once you press the Cartridge button to recall any cartridge preset, as with internal presets, select the Memory Bank (using the BANK A/B button to select Bank) and then press the button corresponding to the desired voice number (1 to 24) or vice versa.
  • Page 11 Local & Remote PIANOFORTE * _ _ Remote Release Pedal The CTS 2000 comes with a footswitch to control the RELEASE function. This function allows the sound to be maintained and decayed slowly, even after the keys have been released, with a different programmable decay for each preset.

  • Page 12: Edit Mode

    EDIT MODE As we have already said, this mode allows you to MODIFY TEMPORARILY all the parameters indicated in the graphic matrix on the right of the control panel above the preset selectors. For the complete list and explanations of the functions of each parameter, see the PARAMETERS LIST section on page 22.
  • Page 13 Choice of parametric family The individual parameters are grouped into PARAMETRIC FAMILIES with a maximum of 6 parameters per family. Once the EDIT (Parameters) mode has been selected and the ZONE or GLOBAL function has been selected, the selection of the Parametric Family to be edited is made by simply pressing the corresponding Family button.
  • Page 14 ATTACK TIME 1 z OLD xx NEW yy (z) = Zone number (octave) of keyboard xx = memory value of the parameter for that Zone yy = new value assigned to the parameter for that Zone If you now move the potentiometer more widely, you will see the value "yy" change. Using the UP and DOWN buttons in the FINE CONTROL section you can also perform a "fine"...

  • Page 15: Attack Time

    Selection and modification of the parameter in GLOBAL mode. Once a Family has been selected, e.g. DCA 1, the 6 slider potentiometers located on the left of the control panel in the DATA ENTRY section and identified by the letters A, B, C, D, E and F will be automatically associated with the 6 corresponding parameters that make up the Family itself.
  • Page 16 For example, if the Attack Time 1 parameter had the following values: Zone 0 = 10 Zone 1 = 3 Zone 2 = 1 Zone 3 = 20 Zone 4 = 8 By editing in Edit GLOBAL mode and changing the value from 0 to +5, the Attack Time values for each individual Zone will become: Zone 0 = 15 Zone 1 = 8...

  • Page 17: Press Enter

    Initialising and creating a preset If you wish to create a new preset that is not derived from editing an existing one, you can use the INITIALIZE PRESET function. This is an initialization function, which sets up the synthesizer parameters in an elementary way to facilitate the creation of a new tone. The main parameters are, for example, set as follows : Both oscillators (1 and 2) are set up to generate an elementary waveform (sawtooth).

  • Page 18: Record Mode

    For a complete list and explanations of the functions of each parameter, see the PARAMETERS LIST section on page 22. To exit the Edit (Parameters) mode at any time, simply press the PRESETS/PARAMETERS button or the INTERNAL or CARTRIDGE button in the Presets section. The display will return to show the type, number, bank, and name of the preset, indicating that you have returned to Standard (Preset) mode.
  • Page 19 WRITE DISABLE At this point the instrument is enabled to record new programmes and will remain so until it is switched off or deliberately returned (with the same operations) to the WRITE DISABLE position. Then exit the Edit mode by pressing the PRESETS/PARAMETERS button or the INTERNAL or CARTRIDGE button in the Presets section.
  • Page 20 By pressing the ENTER button, you can definitively confirm the recording and the display will show the message for a few seconds: WRITE COMPLETED The instrument will then automatically exit the recording mode and return to the Standard mode by clicking the new registered preset.
  • Page 21 PRESS ENTER Release all the buttons and then press the ENTER button to confirm the recording. The display will briefly show : GLOBAL BACK UPCOMPLETED It will then exit the registration phase and return to Standard mode. ATTENTION If you want to exit recording without completing it, press the WRITE button or any of the 24 preset buttons before pressing the Enter button.

  • Page 22: List Of Parameters

    GLOBAL BACK-UP COMPLETED It will then exit the registration phase and return to Standard mode. ATTENTION If you want to exit recording without completing it, press the WRITE button or any of the 24 preset buttons before pressing the Enter button. The following error message may be displayed during the Global Backup from Cartridge to Internal Memory operation: CARTRIDGE...
  • Page 23 _________________________________________________________ Family no.1 : CROSS WAVE 1 Display Fam. : OSCILLATOR 1 Group : DIGITAL OSCILLATOR 1 CROSS WAVE 1 ________________________________________________________ Parameter : OCTAVE Power meter : A Display Par. OSC1 OCTAVE ( z ) OLD xx NEW yy Value xx/yy : from 0 to 5 Function : Selects the sound pitch, in terms of musical octave, of the waveform (table) selectable from Oscillator 1.
  • Page 24 Parameter : DELAY Power meter : C Display Par. DELAY TIME ( z ) OLD xx NEW yy Value xx/yy : 1 to 15 + inf. Function : Selects for how long the FIRST waveform (table) is to be read, and then determines the delay time at which Cross (mixing) starts between the FIRST and SECOND waveforms.
  • Page 25 Thereafter, mixing will continue with the time set by the Time 2 parameter. If the Break Point value is set to 1, the Time 2 parameter will have no effect. If the Break Point value is set to 16, the Time 1 parameter will have no effect. Parameter : TIME 2 Power meter : F Display Par.
  • Page 26 _________________________________________________________ Family no. 2 : CROSS WAVE 2 Display Fam. : OSCILLATOR 1 Group : DIGITAL OSCILLATOR 1 CROSS WAVE 2 ________________________________________________________ Parameter : TO 2nd WAVE Power meter : A Display Par. TO 2nd WAVE ( z ) OLD xx NEW yy Value xx/yy : from 0 to 61 Function : Selects the SECOND waveform (table) to be read and on which the CROSS ends.
  • Page 27 waveform without ever moving on to the next one. Parameter : TIME 1 Power meter : D Display Par. TIME 1 ( z ) OLD xx NEW yy Value xx/yy : from 1 to 16 Function : Selects the time it takes for the Oscillator to switch from reading the SECOND to reading the first.
  • Page 28 If the value of Time 1 is set to 1 the transition from the Second to the Third form wave is immediate. With values greater than 1, the changeover is gradual and proportional to the value entered. _________________________________________________________ Family no. 3 : CROSS WAVE 1 Display Fam. : OSCILLATOR 2 Group : DIGITAL OSCILLATOR 2 CROSS WAVE 1 ________________________________________________________ Parameter : OCTAVE...
  • Page 29 Value xx/yy : from 0 to 61 Function : Selects the FIRST waveform (table) to be read and from which the CROSS begins. (mixing). For a list of available Waveforms (Tables) see annex WAVEFORMS_TABLES Parameter : DELAY Power meter : C Display Par.
  • Page 30 Display Par. BREAK POINT ( z ) OLD xx NEW yy Value xx/yy : from 1 to 16 Function : Selects the point (Break Point) at which mixing is to be stopped (set by the Parameter Time 1 ) between the First and Second waveforms. From the Break Point Thereafter, mixing will continue with the time set by the Time 2 parameter.
  • Page 31 _________________________________________________________ Family no. 4 : CROSS WAVE 2 Display Fam. : OSCILLATOR 2 Group : DIGITAL OSCILLATOR 2 CROSS WAVE 2 ________________________________________________________ Parameter : TO 2nd WAVE Power meter : A Display Par. TO 2nd WAVE ( z ) OLD xx NEW yy Value xx/yy : from 0 to 61 Function : Selects the SECOND waveform (table) to be read and on which the CROSS ends.
  • Page 32 waveform without ever moving on to the next one. Parameter : TIME 1 Power meter : D Display Par. TIME 1 ( z ) OLD xx NEW yy Value xx/yy : from 1 to 16 Function : Selects the time it takes for the Oscillator to switch from reading the SECOND to reading the first.
  • Page 33 If the value of Time 1 is set to 1 the transition from the Second to the Third form wave is immediate. With values greater than 1, the changeover is gradual and proportional to the value entered.
  • Page 34 _______________________________________________________ Family No. 5 : OSC. 1 Display Fam. : OSCILLATOR 1 Group : TUNE & FREQUENCY E.G TUNE - FREQ EG ________________________________________________________ Parameter : SEMITON Power meter : A Display Par. OSC 1 SEMITON ( z ) OLD xx NEW yy Value xx/yy : from - 5 to + 5 Function : Selects the tuning, in semitones, of the First Oscillator with respect to the tuning General (Tune) of the instrument.
  • Page 35 Function : Selects the time by which the frequency of Oscillator 1 tends to the set frequency. From E.G. Level. Parameter : DECAY Power meter : E Display Par. DECAY TIME 1 ( z ) OLD xx NEW yy Value xx/yy : from 1 to 16 Function : Selects the time by which the frequency of Oscillator 1 will return from the value reached After the Attack time, to the normal tuning value.
  • Page 36 _________________________________________________________ Family No. 6 : OSC. 2 Display Fam. : OSCILLATOR 2 Group : TUNE & FREQUENCY E.G TUNE - FREQ EG ________________________________________________________ Parameter : SEMITON Power meter : A Display Par. OSC 2 SEMITON ( z ) OLD xx NEW yy Value xx/yy : from - 5 to + 5 Function : Selects the tuning, in semitones, of the Second Oscillator with respect to tuning General (Tune) of the instrument.
  • Page 37 From E.G. Level. Parameter : DECAY Power meter : E Display Par. DECAY TIME 2 ( z ) OLD xx NEW yy Value xx/yy : from 1 to 16 Function : Selects the time by which the frequency of Oscillator 2 will return from the value reached After the Attack time, to the normal tuning value.
  • Page 38 _________________________________________________________ Family No. 7 : OSC. LEVELS Display Fam. : OSCILLATORS Group : OSC. LEVELS LEVELS ________________________________________________________ Parameter : OSC 1 Power meter : A Display Par. OSC 1 LEVEL ( z ) OLD xx NEW yy Value xx/yy : from 0 to 3 Function: Selects the volume level of Oscillator 1.
  • Page 39 _________________________________________________________ Family No. 8 : DCA 1 Display Fam. DCA 1 ENVELOPE Group : DCA & DCF ENVELOPE GENERATORS ________________________________________________________ Parameter : ATTACK Power meter : A Display Par. ATTACK TIME 1 ( z ) OLD xx NEW yy Value xx/yy : from 1 to 32 Function : Determines the time that the amplifier of each Oscillator 1 item takes to Reach a maximum level from a level of 0 (from the moment of pressing the key).
  • Page 40 Function : Determines the level at which the decay function of the amplifier of each voice Oscillator 1 must stop. The Break Point is a level adjustment and not a time such as Attack, Decay and Release. Parameter : SLOPE Power meter : D Display Par.
  • Page 41 OLD xx NEW yy Value xx/yy : 1 to 31 + inf. Function : Determines the time that the amplifier of each Oscillator 1 item takes to return, from the level determined by the Sustain parameter, to 0 after release of the key, the Release time also applies if the key is released before you have Complete the Attack, Decay and Slope phases.
  • Page 42 _________________________________________________________ Family No. 9 : DCA 2 Display Fam. DCA 2 ENVELOPE Group : DCA & DCF ENVELOPE GENERATORS ________________________________________________________ Parameter : ATTACK Power meter : A Display Par. ATTACK TIME 2 ( z ) OLD xx NEW yy Value xx/yy : from 1 to 32 Function : Determines the time that the amplifier of each Oscillator 2 voice takes to reach a maximum level from a level of 0 (from the moment of pressing the key).
  • Page 43 Function : Determines the level at which the decay function of the amplifier of each voice Oscillator 2 must stop. The Break Point is a level adjustment and not a time such as Attack, Decay and Release. Parameter : SLOPE Power meter : D Display Par.
  • Page 44 OLD xx NEW yy Value xx/yy : 1 to 31 + inf. Function : Determines the time that the amplifier of each Oscillator 2 voice takes to return, from the level determined by the Sustain parameter, to 0 after release of the key, the Release time also applies if the key is released before you have Complete the Attack, Decay and Slope phases.
  • Page 45 _________________________________________________________ Family No. 10 : DCF Display Fam. DCF ENVELOPE Group : DCA & DCF ENVELOPE GENERATORS ________________________________________________________ ATTENTION : the functions of the DCF ENVELOPE GENERATOR family are closely linked to the CUTOff and E.G. LEVEL parameters of the FILTER family , in fact : if CUTOFF = 120 and/or E.G.
  • Page 46 Break Point, Slope and Sustain functions will be enabled. Parameter : BREAK POINT Power meter : C Display Par. BREAK POINT F ( z ) OLD xx NEW yy Value xx/yy : from 1 to 64 Function : Determines the cutoff frequency at which the filter decay function of each item must stop.
  • Page 47 Function : Determines the cutoff frequency at which the filter of each item is to be brought up from previous Break Point cut-off frequency value in the time set by the Slope parameter. If the Sustain value is equal to the Break Point value, the slope function will be ineffective.
  • Page 48 Normally, a value greater than that determined for the pedal is selected. for the keyboard.
  • Page 49 _________________________________________________________ Family no. 11 : FILTER Display Fam. : FILTER Group : FILTER ________________________________________________________ ATTENTION: : The functions of the DCF ENVELOPE GENERATOR family are closely linked to the CUTOff and E.G. LEVEL parameters of the FILTER family, in fact : if CUTOFF = 128 and E.G.LEVEL greater than 0 or CUTOFF = 0 and E.G.LEVEL less than 0 or only E.G.LEVEL = 0...
  • Page 50 Cutoff, thus raising the harmonic content. The higher the resonance value, the more 'nasal' the sound becomes. Parameter : E.G. LEVEL Power meter : C Display Par. ENVELOPE LEVEL ( z ) OLD xx NEW yy Value xx/yy : -63 to +63 Function : Sets the frequency cutoff at which the filter should tend with the envelope defined by the Parameters of the DCF ENVELOPE GENERATOR Family.
  • Page 51 _________________________________________________________ Family No. 12 : PAN POT & LEVEL Display Fam. : MASTERS Group : MASTERS PANPOT-LEVEL ________________________________________________________ Parameter : STEREO PAN POT Power meter : A Display Par. STEREO PAN POT ( z ) OLD xx NEW yy Value xx/yyy : 7L (Left) to 7R (Right) Function :Adjusts the amount of audio signal to be sent to Left and Right outputs in the Stereo connection mode.
  • Page 52 _________________________________________________________ Family no. 13 : LFO 1 to OSC.1 Display Fam. : LOW FREQUENCY Group : LOW FREQUENCY OSCILLATORS OSCILLATOR 1 ________________________________________________________ Parameter : WAVE Power meter : A Display Par. LFO WAVE ( z ) OLD xx NEW yy Value xx/yy : tri (triangular wave) saw (saw tooth wave) squ (square wave)
  • Page 53 Display Par. FINAL LEVEL ( z ) OLD xx NEW yy Value xx/yy : from 0 to 15 Function : Adjusts the final modulation level, i.e. the level to which the modulation, starting from the initial level, after a delay time set by the Delay parameter.
  • Page 54 _________________________________________________________ Family No. 14 : LFO 2 to OSC.2 Display Fam. : LOW FREQUENCY Group : LOW FREQUENCY OSCILLATORS OSCILLATOR 2 ________________________________________________________ Parameter : WAVE Power meter : A Display Par. LFO 2 WAVE ( z ) OLD xx NEW yy Value xx/yy : tri (triangular wave) saw (saw tooth wave) squ (square wave)
  • Page 55 Display Par. FINAL LEVEL ( z ) OLD xx NEW yy Value xx/yy : from 0 to 15 Function : Adjusts the final modulation level, i.e. the level to which the modulation, starting from the initial level, after a delay time set by the Delay parameter.
  • Page 56 _________________________________________________________ Family no. 15 : LFO 3 to DCA/DCF Display Fam. : LOW FREQUENCY Group : LOW FREQUENCY OSCILLATORS OSCILLATOR 3 ________________________________________________________ Parameter : WAVE Power meter : A Display Par. LFO3 WAVE ( z ) OLD xx NEW yy Value xx/yy : tri (triangular wave) saw (saw tooth wave) squ (square wave)
  • Page 57 Display Par. FINAL LEVEL ( z ) OLD xx NEW yy Value xx/yy : from 0 to 15 Function : Adjusts the final modulation level, i.e. the level to which the modulation, starting from the initial level, after a delay time set by the Delay parameter.
  • Page 58 _________________________________________________________ Family No. 16 : WHEELS Display Fam. : WHEELS Group : WHEELS PITCH- MODULATION ________________________________________________________ Parameter : PITCH 1 Power meter : A Display Par. OSC 1 PITCH WH. ( z ) OLD xx NEW yy Value xx/yy : from 1 to 3 Function : Adjusts the amount of PITCH wheel intervention on the frequency of the PITCH.
  • Page 59 Parameter : LFO 3 Power meter : E Display Par. : LFO 3 MOD WH. ( z ) OLD xx NEW yy Value xx/yy : off -- on Function : Enables the MODULATION wheel to increase the amount of modulation of LFO 3.
  • Page 60 _________________________________________________________ Family no. 17 : VELOCITY Display Fam. : KYBD VELOCITY Group : VELOCITY RESPONSE ________________________________________________________ Parameter : DCA 1 INIT. LEVEL Power meter : A Display Par. DCA1 INIT. LEVEL ( z ) OLD xx NEW yy Value xx/yy : from 1 to 32 Function : Adjusts the amount of level of the DCA 1 amplifier playing at minimum dynamics.
  • Page 61 Display Par. DCF INIT. LEVEL ( z ) OLD xx NEW yy Value xx/yy : from 1 to 32 Function : Defines the value of the cutoff frequency of the Cutoff and the amount of E.G.Level a minimum dynamics. Depending on the value of DCF INIT.LEVEL we have for example: 1.If you play softly, both the cut-off frequency and the amount of E.G.Level will be minimums, while playing loudly will be those set by the Cutoff and E.G.Level.
  • Page 62 sound of Oscillator 2 , is activated. Depending on the value of DCA2 TRHS ON we will have, for example: 1. DCA 2 is always active. 16. DCA 2 is triggered if you exceed, during execution, half a level of dynamics.
  • Page 63 _________________________________________________________ Family no. 18 : K.MODE & PORT. Display Fam. : KEYBOARD MODE Group : K.M. & PORT. PORTAMENTO ________________________________________________________ Parameter : MONOPHONIC Power meter : A Display Par. MONOPHONIC MODE ( z ) OLD xx NEW yy Value xx/yy : off -- on Function : Disables Polyphony by selecting the Monophonic mode for the current Zone.
  • Page 64 Value xx/yy : from 1 to 16 Function : Adjusts gait speed.
  • Page 65 _________________________________________________________ Family No. 19 : MIDI Display Fam. : MIDI FUNCTIONS Group : MIDI ________________________________________________________ Parameter : OMNI ON/OFF Power meter : A Display Par. OMNI MODE ( z ) OLD xx NEW yy Value xx/yy : off -- on Function : Enables OMNI mode for Midi reception.
  • Page 66 Value xx/yy : from 0 to 127 Function : Selects the number of programme changes to be sent via Midi, on the channel of Transmit selected by the parameter Transmit Ch. whenever the preset. ATTENTION Program Change will only be received and executed if the following conditions are on the Midi channel assigned to Zone 0.
  • Page 67 _________________________________________________________ Family no. 20 : TR. & D. ALLOC Display Fam. : TRANSPOSE Group : TR & D. ALL. DYN. ALLOCATION ________________________________________________________ Parameter : GLOBAL TRANSP. Power meter : A Display Par. : GLOBAL TRANSPOSE OLD xx NEW yy Value xx/yy : G (G) to F sharp Function: Transposes the playing tone of the entire keyboard.
  • Page 68 _________________________________________________________ Family no. 21 : WRITE & COPY Display Fam. : WRITE & COPY Group : WRITE & C. ________________________________________________________ Parameter : ENABLE / DISABLE Power meter : A Display Par. WRITE or WRITE DISABLE ENABLE Value xx/yyy : write disable - write enable Function : Enables (Write Enbable) and disables (Write Disable) the WRITE in memory of new preset and therefore also the Global Back-up, Copy, and Zone Copy functions.
  • Page 69 Parameter : E.G. DCA1 < > 2 Power meter : C Display Par. COPY: DCA1 EG ( z ) or COPY: DCA2 EG ( z ) TO DCA2 EG TO DCA1 EG Value xx/yy : 1 to 2 or 2 to 1 Function : Allows you to select the function of complete copying of the parameters of the Families Parameters.
  • Page 70 After pressing the Enter key, the display will show the following message for a few seconds: FRQ EG COPY COMPLETED and then display again: WRITE/COPY Parameter : LFO 1 < > 2 Power meter : E Display Par. COPY: LFO1 ( z ) or COPY: LFO2 ( z ) TO LFO2 TO LFO1 Value xx/yy : 1 to 2 or 2 to 1 Function : Allows you to select the function of complete copying of the parameters of the Families...
  • Page 71 _________________________________________________________ Family no. 22 : ZONE COPY Display Fam. : ZONE COPY Group : ZONE COPY ________________________________________________________ This Parametric Family allows ALL PARAMETERS of a Keyboard Zone to be copied from a Preset in any other Zone of any Preset, within the same Bank (A or B). ATTENTION Unlike all other Parametric Families, copying the contents of one Zone to another behaves like a WRITE operation and therefore permanently modifies the Presets that have been copied.

  • Page 72: Preset Name

    Potentiometer C : Defines the number (nn) of the preset to be copied. Potentiometer D : Defines the Zone (y) of the destination preset to be copied to. Once all the necessary parameters have been defined, the operation must be completed by pressing the ENTER button.
  • Page 73 _________________________________________________________ Family No. 24 : EDIT/COMPARE Display Fam. : EDIT/COMPARE Group : EDIT/COMPARE ________________________________________________________ This Parametric Family allows you to compare the sound of the current preset with any other within the same bank (A or B). As soon as potentiometer B is moved after selecting the EDIT/COMPARE parameter family, the display will show the message: COMPARE WITH OLD = yyyy...
  • Page 74 MIDI Your instrument has a universal interface system between musical instruments called MIDI (Musical Intrsument Digital Interface). IMPORTANT The information that follows does not concern a particular instrument or device but illustrates the possibilities that the Midi system makes available to individual manufacturers. To find out which of these functions have been activated on your instrument, please refer to the instruction manual by reading the section on MIDI on your instrument.
  • Page 75 Midi presses Each Midi-compatible instrument is usually equipped with 3 sockets: THRU This socket outputs the Midi signals generated by the instrument and should therefore be used when you want the instrument to become the controller (Master) of the system. In this case, connect the Midi OUT socket to the Midi IN of the first instrument or device to be controlled.

  • Page 76: Channel Messages

    intended and this is done by selecting the Midi channel on the Slave itself, assigning it, for example, Midi channel 1 to the first Slave, Midi channel 2 to the second and so on. If several Slaves are assigned the same conversation channel (e.g. Midi channel 1) they will receive the same Midi signals and thus play what was recorded on track 1.

  • Page 77: System Messages

    It communicates information on the position of the lever or wheel of P.B.; thanks to this information all the P.B. variations made on the Master keyboard will also be performed by the Slaves to whom it has been sent this type of signal. After Touch If your instrument has a keypad that allows you to detect a change in pressure of the key pressed (After Touch), the Midi system allows you to send all the information related to...
  • Page 78 OMNI Mode ON/OFF This mode only has an effect on reception; in fact, all instruments or slave devices that use it will play all the MIDI information transmitted by the Master instrument or device, regardless of the channel number to which it may have been sent. Obviously, the slave units will only perform the operations for which they have been enabled, so if you send dynamic signals, they will only be performed by devices equipped with dynamics and this type of message will be ignored by the others.
  • Page 79 If you wish your instrument to transmit and receive Midi notes from C 1 to C 6, you must switch on the CTS 2000 by pressing and holding down button 19 for the Midi family, this mode will remain enabled until the instrument is switched off.
  • Page 80 Midi reception channel. In transmission, each octave of the CTS 2000 can transmit MIDI signals to a different slave, while in reception you can use the five octaves of your instrument as five completely independent slave units.

  • Page 81: Implementation Chart

    By pressing one or more times this button, located next to the Control Display, you can select the mode of transmission and/or reception of programme changes as follows: If LOCAL mode is selected, the instrument will not transmit or receive program changes via MIDI, but will only be able to change its own internal presets.
