Zone Status
continued
8. At the ZONE NO: - prompt, enter the zone number you want to
check and press COMMAND. The zone number and name is
displayed followed by its status. For example, a zone status for
zone 1 might be: BACK DOOR - OKAY.
Below is a list of the zone status displays:
-OKAY
=
the zone is in a normal condition
-BYPAS =
the zone is bypassed
-BAD
=
the zone is in a bad condition
9. After displaying the zone status, ZONE: - returns for you to enter
another zone number.
Browser Feature
If you're unsure of the zone number or description, refer to the
Appendix at the back of this guide for a diagram showing you how
to use the built-in Zone Status browser.
Zone Status
continued
8. At the ZONE NO: - prompt, enter the zone number you want to
check and press COMMAND. The zone number and name is
displayed followed by its status. For example, a zone status for
zone 1 might be: BACK DOOR - OKAY.
Below is a list of the zone status displays:
-OKAY
=
the zone is in a normal condition
-BYPAS =
the zone is bypassed
-BAD
=
the zone is in a bad condition
9. After displaying the zone status, ZONE: - returns for you to enter
another zone number.
Browser Feature
If you're unsure of the zone number or description, refer to the
Appendix at the back of this guide for a diagram showing you how
to use the built-in Zone Status browser.

Bypass Zones

User Code Level: 6 and above.
Function: Allows you to bypass a zone prior to arming.
Bypassing is usually done when a zone cannot be restored to
normal. A zone can be bypassed only while it's disarmed. Since fire,
panic, emergency, and supervisory type zones are always armed,
they can never be bypassed.
Bypass Zones can also be used to reset a zone that has been
bypassed and restore it back into the system. This can only be done
while the zone is disarmed.
When Bypass Zones is selected, a report can be transmitted to your
central station.
Using the Bypass Zones Function
1. Access the User Menu.
2. Press COMMAND until BYPASS ZONES? displays.
3. Press any SELECT key. The keypad displays ZONE: - RST
BYPS.
4. To Bypass a zone, enter the zone number and select BYPS.
The zone number automatically disappears and a new zone
number can be entered. Refer back to step 3.
5. To Reset a zone, enter the zone number and select RST.
Browser Feature
If you're unsure of the zone number or description, refer to the
Appendix at the back of this guide for a diagram showing you how
to use the built-in Bypass Zones browser.
Bypass Zones
User Code Level: 6 and above.
Function: Allows you to bypass a zone prior to arming.
Bypassing is usually done when a zone cannot be restored to
normal. A zone can be bypassed only while it's disarmed. Since fire,
panic, emergency, and supervisory type zones are always armed,
they can never be bypassed.
Bypass Zones can also be used to reset a zone that has been
bypassed and restore it back into the system. This can only be done
while the zone is disarmed.
When Bypass Zones is selected, a report can be transmitted to your
central station.
Using the Bypass Zones Function
1. Access the User Menu.
2. Press COMMAND until BYPASS ZONES? displays.
3. Press any SELECT key. The keypad displays ZONE: - RST
BYPS.
4. To Bypass a zone, enter the zone number and select BYPS.
The zone number automatically disappears and a new zone
number can be entered. Refer back to step 3.
5. To Reset a zone, enter the zone number and select RST.
Browser Feature
If you're unsure of the zone number or description, refer to the
Appendix at the back of this guide for a diagram showing you how
to use the built-in Bypass Zones browser.
17
User Menu
17
User Menu
