2023 RAM 2500/3500

OWNER'S MANUAL

Table of Contents

Need help?

Do you have a question about the 2500 2023 and is the answer not in the manual?

Questions and answers

Summary of Contents for RAM 2500 2023

Page 1 2023 RAM 2500/3500 OWNER’S MANUAL...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this manual that are not on this vehicle.
Page 3 TABLE OF CONTENTS INTRODUCTION ..........................9 GETTING TO KNOW YOUR VEHICLE ..................17 GETTING TO KNOW YOUR INSTRUMENT PANEL ............92 STARTING AND OPERATING ....................125 MULTIMEDIA ..........................225 SAFETY ............................295 IN CASE OF EMERGENCY ....................349 SERVICING AND MAINTENANCE ..................369 TECHNICAL SPECIFICATIONS ....................438 CUSTOMER ASSISTANCE ....................
Page 4: Table Of Contents
INTRODUCTION DOORS ................25 DRIVER ADJUSTABLE PEDALS — Manual Door Locks............25 IF EQUIPPED ..............38 SYMBOLS KEY ..............10 Power Door Locks — If Equipped .......26 MIRRORS ................38 VAN CONVERSIONS/CAMPERS ........10 Inside Rearview Mirror ..........38 Power Side Steps — If Equipped ........26 CONSUMER INFORMATION —...
Page 5 EXTERIOR LIGHTS...............49 CLIMATE CONTROLS ............56 TAILGATE ................76 Headlight Switch ............49 Automatic Climate Control Descriptions And Opening................ 76 Multifunction Lever ............. 49 Functions..............56 Closing................76 Manual Climate Control Descriptions And Tailgate Removal............76 Daytime Running Lights (DRLs) — If Equipped ..............
Page 6 STARTING AND OPERATING MIDLINE INSTRUMENT CLUSTER — DIESEL ENGINE ..98 Programmable Maximum Vehicle Speed ....136 Midline Instrument Cluster Descriptions — Operating Precautions ..........136 STARTING THE ENGINE — GASOLINE ENGINE .... 125 Diesel Engine............... 99 Cooling System Tips ..........136 Automatic Transmission........... 125 HIGHLINE INSTRUMENT CLUSTER —...
Page 7 AXLE LOCKER SYSTEM —IF EQUIPPED......156 PARKSENSE FRONT/REAR PARK ASSIST — VEHICLE LOADING ............203 STABILIZER/SWAY BAR SYSTEM — IF EQUIPPED..............183 Gross Vehicle Weight Rating (GVWR) ......203 POWER WAGON ONLY ............ 157 ParkSense Sensors ..........183 Payload ..............203 ParkSense Warning Display........183 Gross Axle Weight Rating (GAWR) ......204 SAFE OFF-ROAD DRIVING —...
Page 8 SAFETY DRIVING TIPS ..............223 CONNECTED SERVICES FAQS ........284 Driving On Slippery Surfaces ........223 Connected Services SOS FAQs — SAFETY FEATURES ............295 Driving Through Water ..........223 If Equipped ............... 284 Anti-Lock Brake System (ABS) .........295 Off-Road Driving Tips ..........224 Connected Services Remote Door Lock/Unlock Rear Seat Reminder Alert (RSRA) ......296 FAQs ................
Page 9 IN CASE OF EMERGENCY SERVICING AND MAINTENANCE Windshield Wiper Blades..........391 Exhaust System ............393 HAZARD WARNING FLASHERS ........349 SCHEDULED SERVICING ..........369 Cooling System ............394 ASSIST AND SOS SYSTEM — IF EQUIPPED ....349 Maintenance Plan — Gasoline Engine..... 371 Charge Air Cooler —...
Page 10 INTERIORS ............... 435 Methylcyclopentadienyl Manganese Mexico................451 Seats And Fabric Parts ..........435 Tricarbonyl (MMT) In Gasoline ......... 441 Puerto Rico And US Virgin Islands......451 Plastic And Coated Parts .......... 436 Fuel System Cautions..........441 Customer Assistance For The Hearing Or Leather Surfaces............
Page 11 FCA US LLC aims at a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Ram best, have factory-trained technicians, genuine Mopar® parts, and care about your satisfaction.
Page 12: Symbols Key
SYMBOLS KEY VAN CONVERSIONS/CAMPERS The New Vehicle Limited Warranty does not apply to body modifications or special These statements apply to operating procedures that WARNING! equipment installed by van conversion/camper manufacturers/body builders. could result in a collision, bodily injury and/or death. US residents refer to the Warranty Information, Section 2.1.C.
Page 13 Figure 1 illustrates the dimensions describing the forward and rearward limits of the zone in which the Center of Gravity (CG) of a slide-in camper must be located, to provide satisfactory vehicle handling and to prevent overload of the front and rear axles. Figure 2 illustrates a proper match between truck and camper.
Page 14: Vehicle Modifications/Alterations
When the truck is used to carry a slide-in camper, the total cargo load of the truck consists NOTE: of the manufacturer’s camper weight figure, the weight of installed additional camper Warning and Indicator lights are different based upon equipment options and current equipment not included in the manufacturer’s camper weight figure, the weight of camper vehicle status.
Page 15 Red Warning Lights Yellow Warning Lights Oil Pressure Warning Light Air Suspension Fault Warning Light page 117 page 117 Ú Ú Oil Temperature Warning Light Anti-Lock Brake System (ABS) Warning Light page 117 page 118 Ú Ú Seat Belt Reminder Warning Light Cruise Control Fault Warning Light page 117 page 119...
Page 16 Yellow Warning Lights Yellow Warning Lights Low Fuel Warning Light Tire Pressure Monitoring System (TPMS) Warning Light page 118 page 119 Ú Ú Low Coolant Level Warning Light Yellow Indicator Lights Ú page 118 Air Suspension Payload Protection Indicator Light Loose Fuel Filler Cap Warning Light page 120 Ú...
Page 17 Yellow Indicator Lights Yellow Indicator Lights Cold Ambient Derate Mode Indicator Light NEUTRAL Indicator Light page 121 page 121 Ú Ú Diesel Exhaust Brake Indicator Light Rear Axle Lock Indicator Light page 121 page 121 Ú Ú Forward Collision Warning (FCW) or Pedestrian Emergency Braking (PEB) Snowplow Mode Indicator Light Off Indicator Light page 121...
Page 18 Green Indicator Lights Green Indicator Lights Adaptive Cruise Control (ACC) Set With Target Indicator Light Turn Signal Indicator Lights page 122 Ú page 122 Ú Adaptive Cruise Control (ACC) Set With No Target Detected Indicator Light White Indicator Lights page 122 Ú...
Page 19: Keys
GETTING TO KNOW YOUR VEHICLE KEYS In case the ignition switch does not change with the push of a button, the key fob may have a low or fully depleted battery. A low key fob battery can be verified by referring to the instrument cluster, which will display directions to follow.
Page 20 GETTING TO KNOW YOUR VEHICLE Using The Panic Feature The vehicle’s horn will rapidly chirp three times along with Remove the emergency key (1) by pushing the a single flash of the vehicle’s exterior lights. emergency key release button (2) on the side of the To turn the Panic feature on or off, push the Panic button key fob, and pulling the emergency key out with your NOTE:...
Page 21 GETTING TO KNOW YOUR VEHICLE Next, locate the gap on the right side of the key fob, Replace the battery by using your thumb to push WARNING! which is positioned farther to the edge than the left down and slide the battery under the small lip on the side gap.
Page 22: Sentry Key
GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH After placing the ignition in the ON/RUN position, the WARNING! Vehicle Security Light will turn on for three seconds for a bulb check. If the light remains on after the bulb check, it ...
Page 23 GETTING TO KNOW YOUR VEHICLE The push button ignition can be placed in the following WARNING! modes:  Do not leave children or animals inside parked vehi- cles in hot weather. Interior heat buildup may cause  The engine is stopped serious injury or death.
Page 24: Remote Start - If Equipped (Gasoline)
GETTING TO KNOW YOUR VEHICLE REMOTE START — IF EQUIPPED (if programmed). Then, the engine will start, and the  Brake switch inactive (brake pedal not pressed) vehicle will remain in the Remote Start mode for a  Battery at an acceptable charge level (GASOLINE) 15 minute cycle.
Page 25: Remote Start Front Defrost Activation
GETTING TO KNOW YOUR VEHICLE NOTE: the Comfort menu screen. The vehicle will adjust the EMOTE TART INDSHIELD IPER climate control settings depending on the outside ambient  For vehicles equipped with the Keyless Enter ‘n Go™ — — I CTIVATION QUIPPED temperature.
Page 26: Remote Start- If Equipped (Diesel)
GETTING TO KNOW YOUR VEHICLE REMOTE START— IF EQUIPPED (DIESEL) VEHICLE SECURITY SYSTEM — IF EQUIPPED All of the following conditions must be met before the engine will remote start: This system uses the key fob to start the engine The Vehicle Security system monitors the vehicle doors, ...
Page 27: To Disarm The System
GETTING TO KNOW YOUR VEHICLE If the Vehicle Security system is armed and the battery ISARM YSTEM becomes disconnected, the Vehicle Security system will The Vehicle Security system can be disarmed using any of remain armed when the battery is reconnected; the the following methods: exterior lights will flash, and the horn will sound.
Page 28: Power Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE ‘ ™ — P The driver’s door will unlock automatically if the key fob is EYLESS NTER ASSIVE WARNING! detected inside the vehicle when the door lock button on NTRY QUIPPED the front door panel is used to lock the door. ...
Page 29 GETTING TO KNOW YOUR VEHICLE To Unlock From The Driver Or Passenger Side There are five situations that trigger a FOBIK-Safe search To Lock The Vehicle’s Doors And Tailgate: in any Passive Entry vehicle: With a valid Passive Entry key fob within 5 ft (1.5 m) of the With one of the vehicle’s Passive Entry key fobs within 5 ft door handle, grab the handle to unlock the vehicle.
Page 30: Automatic Unlock Doors On Exit - If Equipped
GETTING TO KNOW YOUR VEHICLE — NOTE: NOTE: UTOMATIC OCKS  After pushing the door handle button, you must wait  After disengaging the Child-Protection Door Lock QUIPPED two seconds before you can lock or unlock the doors, system, always test the door from the inside to make using either Passive Entry door handle.
Page 31: Steering Wheel
GETTING TO KNOW YOUR VEHICLE STEERING WHEEL  Press the heated steering wheel button once to turn WARNING! the heating element on. Do not adjust the steering column while driving.  Press the heated steering wheel button a second time TEERING OLUMN Adjusting the steering column while driving or driving...
Page 32: Uconnect Voice Recognition
ECOGNITION Push the VR button or for the Uconnect 5/5 NAV, say include “Hey, Uconnect” or “Hey Ram”. the vehicle’s “Wake Up” word, “Hey Uconnect”. Start using Uconnect Voice Recognition with these helpful You can interrupt the help message or system After the beep, say: quick tips.
Page 33: Additional Information
GETTING TO KNOW YOUR VEHICLE  Side mirrors DDITIONAL NFORMATION ROGRAMMING EMORY EATURE  A set of desired radio station presets © 2022 FCA US LLC. All rights reserved. Mopar and To create a new memory profile, perform the following: NOTE: Uconnect are registered trademarks, and Mopar Owner NOTE:...
Page 34: Linking And Unlinking The Remote
GETTING TO KNOW YOUR VEHICLE — INKING NLINKING EMOTE EMORY OSITION ECALL ANUAL RONT DJUSTMENT EYLESS NTRY EMORY QUIPPED NOTE: If a recall is attempted when the vehicle is not in PARK, a Manual Front Seat Forward/Rearward Your key fob can be programmed to recall one of two message will display in the instrument cluster display.
Page 35: Power Driver Seat Adjustment - If Equipped
GETTING TO KNOW YOUR VEHICLE WARNING! WARNING!  Adjusting a seat while driving may be dangerous.  Do not stand or lean in front of the seat while actu- Moving a seat while driving could result in loss of ating the handle. The seatback may swing forward control which could cause a collision and serious and hit you causing injury.
Page 36: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE Reclining The Seatback seat. Push the switch forward to increase the lumbar position is between 0.9 inches and 2.7 inches support. Push the switch rearward to decrease the lumbar (2.27 cm and 6.77 cm) forward of the rear stop. The The angle of the seatback can be adjusted forward or support.
Page 37: Ventilated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE — I For information on use with the Remote Start system, see ENTILATED EATS QUIPPED WARNING! page 23. Ú Front Ventilated Seats  Do not place anything on the seat or seatback that Rear Heated Seats insulates against heat, such as a blanket or cushion.
Page 38: Head Restraints
GETTING TO KNOW YOUR VEHICLE To adjust the head restraint forward, pull the top of the ESTRAINTS head restraint toward the front of the vehicle as desired Head restraints are designed to reduce the risk of injury by and release. To adjust the head restraint rearward, pull restricting head movement in the event of a rear impact.
Page 39 GETTING TO KNOW YOUR VEHICLE Front Head Restraint Removal Rear Head Restraint Removal To lower the head restraint, push the adjustment button located on the base of the head restraint and push Two-Way Head Restraints — If Equipped To remove the head restraint, push the adjustment button downward on the head restraint.
Page 40: Driver Adjustable Pedals
GETTING TO KNOW YOUR VEHICLE DRIVER ADJUSTABLE PEDALS — NOTE: Headlight glare from vehicles behind you can be reduced by moving the small control under the mirror to the night  Always adjust the pedals to a position that allows full IF EQUIPPED position (toward the rear of the vehicle).
Page 41 GETTING TO KNOW YOUR VEHICLE Tri-View Tow Mode (if equipped) The Tri-View Tow Mode will display the left and right sides of the back of the vehicle using the outside mirror cameras and the back of the trailer using an auxiliary camera. Tow Mode - Back of trailer (if equipped) The Tow Mode will display a wide screen view of the back of the trailer using an auxiliary camera.
Page 42: Illuminated Vanity Mirror
GETTING TO KNOW YOUR VEHICLE — Tow Mode Camera Signal Lost - Single View LLUMINATED ANITY IRROR Your vehicle may be equipped with an additional auxiliary This indication will appear when the Rearview QUIPPED trailer camera to be mounted on the rear of a trailer. Camera has lost its signal.
Page 43: Outside Mirrors
GETTING TO KNOW YOUR VEHICLE WARNING! Vehicles and other objects seen in the driver or passenger side convex mirror will look smaller and farther away than they really are. Relying only on the convex mirror could cause you to collide with another vehicle or other object.
Page 44: Outside Automatic Dimming
GETTING TO KNOW YOUR VEHICLE Manual Telescoping Mirrors UTSIDE UTOMATIC IMMING To extend the Manual Telescoping Mirrors pull the mirror — I IRROR QUIPPED outward to desired position. To return to normal position, push the mirror inward all the way. The exterior mirrors will automatically adjust for glare from vehicles behind you.
Page 45: Power Folding Outside Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE The power mirror controls consist of mirror select buttons If the mirror is manually folded after a powered cycle, a UTOMATIC OWER OLDING and a four-way mirror control switch. potential extra button push is required to get the mirrors —...
Page 46: Tilt Side Mirrors In Reverse
GETTING TO KNOW YOUR VEHICLE — NOTE: IRRORS EVERSE If the Power Convex Mirror Switch is not pushed a second QUIPPED time, the switch will automatically default back to the larger portion of the outside mirrors after a period of time. This feature provides automatic outside mirror positioning which will assist with the driver’s ground visibility.
Page 47: Heated Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE The rear guidance lights will also illuminate when the Use this QR code to access your digital cargo light switch is pressed on the headlight switch experience. panel. This feature is programmable through the Uconnect ...
Page 48: Before You Begin Programming Homelink
GETTING TO KNOW YOUR VEHICLE NOTE: EFORE EGIN ROGRAMMING DENTIFYING HETHER All HomeLink® buttons are programmed using this ® OLLING OLLING procedure. You do not need to erase all channels when programming additional buttons. EVICE For efficient programming and accurate transmission of Place the ignition switch in the ON/RUN position.
Page 49: Programming Homelink® To A Miscellaneous Device
GETTING TO KNOW YOUR VEHICLE ® T Return to the vehicle and push the programmed Without releasing the button, proceed with Step 2 in ROGRAMMING HomeLink® button three times (holding the button “Programming HomeLink® To A Garage Door ISCELLANEOUS EVICE for two seconds each time).
Page 50: Security
GETTING TO KNOW YOUR VEHICLE Continue to push and hold the HomeLink® button Reprogramming A Single HomeLink® Button (Canadian/ ROUBLESHOOTING while you push and release (cycle) your hand-held Gate Operator) transmitter every two seconds until HomeLink® has If you are having trouble programming HomeLink®, here To reprogram a channel that has been previously trained, successfully accepted the frequency signal.
Page 51: Exterior Lights
GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS To turn on the headlights, rotate the headlight switch clockwise. When the headlight switch is on, the parking lights, taillights, license plate light and instrument panel EADLIGHT WITCH lights are also turned on. To turn off the headlights, rotate the headlight switch back to the O (off) position.
Page 52: Daytime Running Lights (Drls)
GETTING TO KNOW YOUR VEHICLE (DRL ) —  The Automatic High Beams will not activate until the AYTIME UNNING IGHTS UTOMATIC EADLAMP vehicle is at or above 15 mph (24 km/h). To opt out of — I QUIPPED ONTROL QUIPPED the Automatic High-Beam Sensitivity Control (default) and enter Reduced High-Beam Sensitivity Control (not...
Page 53: Directional Led Headlamp
GETTING TO KNOW YOUR VEHICLE LED H  Vehicles sold in Canada are equipped with a headlight IRECTIONAL EADLAMP EADLIGHT LLUMINATION switch with an AUTO and ON detent but without an — I YSTEM QUIPPED PPROACH OFF detent. Headlights will be deactivated when the headlight switch is placed in the parking lights position.
Page 54: Front Fog Lights - If Equipped
GETTING TO KNOW YOUR VEHICLE — I RONT IGHTS QUIPPED IGNALS To activate the front fog lights, turn on the parking lights or Move the multifunction lever up or down to activate the low beam headlights and push the fog light switch located turn signals.
Page 55: Battery Saver
GETTING TO KNOW YOUR VEHICLE INTERIOR LIGHTS When the vehicle is stationary, these lights can also be NOTE: turned on using the switch located just inside the pickup For vehicles shipped to or sold in the states of California box, on the lower part of the bed light lens. A telltale will or Mississippi, the cargo, bed, and mirror spotter lights will OURTESY IGHTS...
Page 56 GETTING TO KNOW YOUR VEHICLE NOTE: The rear courtesy/reading lights will remain on until the switch is pushed a second time, so be sure they have been turned off before exiting the vehicle. If the interior lights are left on after the ignition is placed in the OFF position, they will automatically turn off after 10 minutes.
Page 57: Illuminated Entry
GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS NOTE: The delay interval decreases as you rotate the knob until it enters the low continual speed position. The delay can The brightness of the Uconnect touchscreen cannot be be regulated from a maximum of about 18 seconds adjusted when the instrument panel dimmer control is The windshield wiper/washer controls are located on the rotated to the upper most detent, even when Display...
Page 58: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE Mist NOTE:  Remote Start Mode Inhibit — On vehicles equipped with the Remote Start system, Rain Sensing wipers are not When a single wipe to clear off road mist or spray from a  The Rain Sensing feature will not operate when the operational when the vehicle is in the Remote Start passing vehicle is needed, push the washer knob, located wiper switch is in the low or high-speed position.
Page 59 GETTING TO KNOW YOUR VEHICLE A/C Button Auto Button Press and release this button on the Set your desired temperature and press AUTO. touchscreen, or push the button on the AUTO will achieve and maintain your desired faceplate to change the current setting. temperature by automatically adjusting the The A/C indicator illuminates when A/C is on.
Page 60 GETTING TO KNOW YOUR VEHICLE Rear Defrost Button the red arrow button on the touchscreen for warmer Faceplate temperature settings. The blower speed increases as you turn the blower control Press and release the Rear Defrost button on Push the blue button (or rotate knob if knob clockwise from the lowest blower setting.
Page 61: Manual Climate Control Descriptions And
GETTING TO KNOW YOUR VEHICLE Panel Mode Mix Mode Air comes from the outlets in the instrument Air is directed through the floor, defrost, and panel. Each of these outlets can be individually side window demister outlets. This setting adjusted to direct the flow of air. The air vanes works best in cold or snowy conditions that of the center outlets and outboard outlets can require extra heat to the windshield.
Page 62 GETTING TO KNOW YOUR VEHICLE Recirculation Button Rear Defrost Button The temperature increases as you turn the temperature control knob clockwise. Push the Recirculation button to change the Push and release the Rear Defrost Control system between recirculation mode and button to turn on the rear window defroster and outside air mode.
Page 63: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE — Bi-Level Mode Next, adjust the temperature you would like the LIMATE OICE ECOGNITION system to maintain by adjusting the driver and Air comes from the instrument panel outlets QUIPPED passenger temperature control buttons. Once the and floor outlets.
Page 64: Interior Storage And Equipment
GETTING TO KNOW YOUR VEHICLE INTERIOR STORAGE AND EQUIPMENT Vacation/Storage Operating Tips Chart For information on maintaining the Climate Control system WEATHER CONTROL SETTINGS TORAGE when the vehicle is being stored for an extended period of time, see page 433. Ú...
Page 65 GETTING TO KNOW YOUR VEHICLE If equipped with a covered upper glove compartment, Pull the upper handle on the front of the armrest to raise push the release button to open. the cover. To open the lower glove compartment, pull the release handle.
Page 66 GETTING TO KNOW YOUR VEHICLE With the upper lid closed, pull the lower handle to open the Premium Center Console — If Equipped lower storage bin. The lower bin contains a power inverter. The premium center console is equipped with two front There is also a fill line located along the rear inside wall of storage bins located in front of the center storage the lower bin.
Page 67 GETTING TO KNOW YOUR VEHICLE Overhead Sunglass Storage Front Bench Seat Storage — If Equipped Seatback Storage — If Equipped At the front of the overhead console, a compartment is If your vehicle is equipped with a front bench seat, storage Located in the back of both the driver and passenger front provided for the storage of one pair of sunglasses.
Page 68 GETTING TO KNOW YOUR VEHICLE Second Row In-Floor Storage Bin — Fold Flat Load Floor — If Equipped If Equipped Crew Cab models with a 60/40 rear seat may be equipped with a folding load floor. In-floor storage bins are located in front of the second row seats and can be used for extra storage.
Page 69 GETTING TO KNOW YOUR VEHICLE Unfold both the legs using the straps. Positioning The Load Floor For Storage Access Under The Reverse the procedure to put the load floor back in Seat the secured down position before you operate the vehicle.
Page 70: Usb/Aux Control
GETTING TO KNOW YOUR VEHICLE USB/AUX C ONTROL Located on the center stack, just below the instrument panel, is the main media hub. There are four total USB ports: Two Mini-USBs (Type C) and two Standard USBs (Type A). There is also an AUX port located in the middle of the USB ports.
Page 71: Electrical Power Outlets
GETTING TO KNOW YOUR VEHICLE NOTE: If equipped, two Mini-USB ports (Type C), two Standard LECTRICAL OWER UTLETS USB ports (Type A), and one AUX port may be located to the Charge unsupported devices with the Charge Only USB left of the center stack, just below the climate controls. The auxiliary 12 Volt (13 Amp) power outlet can provide ports.
Page 72: Power Inverter - If Equipped
GETTING TO KNOW YOUR VEHICLE — I An auxiliary power outlet can be found in the tray on top of OWER NVERTER QUIPPED WARNING! the center stack. This power outlet works when the ignition is in the ON/RUN, ACC, or OFF position. Interior Power Inverters To avoid serious injury or death: If equipped, 115 Volt (400 W maximum) power inverters...
Page 73 GETTING TO KNOW YOUR VEHICLE Exterior Power Inverter — If Equipped Vehicles not equipped with a RamBox may be equipped with a 115 Volt (400 W maximum) power inverter located just inside the truck bed. Rear Center Console Power Inverter Outlet (If Equipped) Instrument Panel Power Inverter Switch NOTE: For information on the outlet found inside the RamBox,...
Page 74: Wireless Charging Pad
GETTING TO KNOW YOUR VEHICLE — LED Indicator Status: instances, the device may shut down for a brief period IRELESS HARGING of time (when the device reaches a certain tempera-  No Light: Charging pad is idle or searching for a device. QUIPPED ture).
Page 75: Automatic Window Features
GETTING TO KNOW YOUR VEHICLE The passenger door windows can also be operated by To stop the window from going all the way down during the ESET using the single window controls on the passenger door Auto-Down operation, pull up or push down on the switch trim panel.
Page 76: Power Sliding Rear Window
GETTING TO KNOW YOUR VEHICLE — This is a normal occurrence and can be minimized. If the OWER LIDING INDOW WARNING! buffeting occurs with the rear windows open, open the QUIPPED front and rear windows together to minimize the buffeting. ...
Page 77: Hood
GETTING TO KNOW YOUR VEHICLE Sunshade Operation During Express Open or Express Close operation, any other actuation of the sunroof switch will stop the sunroof. The sunshade can be opened manually. However, the Manual Open/Close sunshade will open automatically as the sunroof opens. To open the sunroof, push and hold OPEN on the sunroof NOTE: switch.
Page 78: To Close The Hood
GETTING TO KNOW YOUR VEHICLE TAILGATE NOTE: AILGATE EMOVAL  Vehicle must be at a stop and the gear selector must NOTE: be in PARK. PENING Removing the tailgate will disable the rearview camera  While lifting the hood, use both hands. function.
Page 79 GETTING TO KNOW YOUR VEHICLE Slide the entire tailgate to the right to free the left side Remove the connector bracket from the sill by Connect the chassis plug and bracket (provided in the pivot. pushing inward in the locking tab. glove compartment) to the chassis wiring harness and insert the bracket back into the sill.
Page 80: Bed Step - If Equipped
GETTING TO KNOW YOUR VEHICLE Connect the tailgate plug (provided in the glove compartment) to the tailgate wiring harness to ensure that the terminals do not corrode. Taped Tailgate Harness Bed Step Components — I 1 — Bed Step QUIPPED 2 —...
Page 81: Pickup Box
GETTING TO KNOW YOUR VEHICLE PICKUP BOX NOTE: WARNING! Once the spring load is overcome, the bed step will extend out quickly, so be sure to stand in a position that will avoid The pickup box has many features designed for utility and ...
Page 82: Cargo Camera - If Equipped
GETTING TO KNOW YOUR VEHICLE — I Cargo Camera With Dynamic Centerline (Available With Deactivation ARGO AMERA QUIPPED Surround View Camera Only) — If Equipped The Dynamic Centerline feature will automatically be Your vehicle may be equipped with the Cargo Camera that The Dynamic Centerline feature provides an overlay on the deactivated whenever the Cargo Camera display is allows you to see an image of the inside of the pickup box.
Page 83: Bed Rail Tie-Down System
GETTING TO KNOW YOUR VEHICLE — Each cleat must be located and tightened down in one of Cleat Removal (With Tonneau Cover) YSTEM the detents, along either rail, in order to keep cargo To remove the cleats from the utility rail, remove the end QUIPPED properly secure.
Page 84: Rambox - If Equipped
GETTING TO KNOW YOUR VEHICLE RAMBOX — IF EQUIPPED Cleat Removal (Without Tonneau Cover) ARGO TORAGE Remove the end cap by pushing upward on the release Cargo storage bins are located on both sides of the pickup The RamBox system is an integrated pickup box storage button located beneath the end cap while pulling the cap box.
Page 85 GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: The RamBox will not open when the button is pushed if the Provisions are provided in the bins for cargo dividers and RamBox is locked. shelf supports. These accessories (in addition to other RamBox accessories) are available from Mopar®.
Page 86: Rambox Safety Warning
GETTING TO KNOW YOUR VEHICLE RamBox Emergency Release Lever The Instrument Panel Power Inverter switch is only found AFETY ARNING on vehicles equipped with an exterior power inverter As a security measure, an Emergency Release Lever is inside the RamBox or truck bed. The switch only controls Carefully follow these warnings to help prevent personal built into the storage bin cover latching mechanism.
Page 87: Bed Divider - If Equipped
GETTING TO KNOW YOUR VEHICLE — I IVIDER QUIPPED The bed divider has two functional positions:  Divider Position  Storage Position Divider Position The divider position is intended for managing your cargo and assisting in keeping cargo from moving around the bed.
Page 88: Tri-Fold Tonneau Cover - If Equipped
GETTING TO KNOW YOUR VEHICLE Storage Position The storage position for the bed divider is at the front of the truck bed which maximizes the bed cargo area when not in use. To install the bed divider into the storage position, perform the same steps as you would for the divider position, except position the divider fully forward in the bed against the front panel.
Page 89 GETTING TO KNOW YOUR VEHICLE From the Released Position, send the clamps to the Stowed Position by pushing from the yellow bumper upward. Listen for a “clicking” sound to confirm the clamp has been stowed properly. Folded Rear Panel (Intermediate Position) Incorrect Folding —...
Page 90: Tri-Fold Tonneau Cover Installation
GETTING TO KNOW YOUR VEHICLE Clip both stowage straps to prevent the Tonneau NOTE: Cover panels from unfolding. Be sure the Tonneau Cover has been folded completely, and the stowage straps are engaged, before removing the CAUTION! cover from the vehicle. The folded Tonneau Cover must be latched by both ONNEAU OVER...
Page 91 GETTING TO KNOW YOUR VEHICLE Pull down on the first set of clamp handles to release Push clamp handles upward to the clamped position Disengage the stowage straps. the clamps from the Stowed Position. to properly engage the clamps. Unfold the center and rear panels to the Intermediate Position.
Page 92 GETTING TO KNOW YOUR VEHICLE Pull the rear clamp handles down into the Released Position. Correct Folding — Hold Panels Together Semi Clamped Position Completely unfold the Tonneau Cover. 10. Push clamp handles upward to the clamped position to properly engage the clamps. Stowed Position Push clamp wires up and under the flange of box (or flange of RamBox rail, if equipped) to the Semi...
Page 93: Tri-Fold Tonneau Cover Cleaning
GETTING TO KNOW YOUR VEHICLE ONNEAU OVER LEANING WARNING! For proper cleaning of the Tonneau Cover, use Mopar® You must ensure the Tonneau Cover is properly Whitewall & Vinyl Top Cleaner and Mopar® Leather & Vinyl installed on the vehicle before driving. An unsecured Conditioner/Protectant.
Page 94: Midline Instrument Cluster - Gas Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL MIDLINE INSTRUMENT CLUSTER — GAS ENGINE...
Page 95: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL Oil Pressure Gauge IDLINE NSTRUMENT LUSTER WARNING!  The pointer should always indicate the oil pres- — G ESCRIPTIONS NGINE A hot engine cooling system is dangerous. You or others sure when the engine is running. A continuous could be badly burned by steam or boiling coolant.
Page 96: Highline Instrument Cluster - Gas Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL HIGHLINE INSTRUMENT CLUSTER — GAS ENGINE...
Page 97: Highline Instrument Cluster Descriptions - Gas Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL Temperature Gauge IGHLINE NSTRUMENT LUSTER CAUTION!  The gauge pointer shows engine coolant tempera- — G ESCRIPTIONS NGINE Driving with a hot engine cooling system could damage ture. The pointer positioned within the normal your vehicle.
Page 98: Premium Instrument Cluster - Gasoline
GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER — GASOLINE Holding the OK button on the Instrument Cluster Display controls located on the steering wheel will allow you to change your display from Digital to Analog.
Page 99: Premium Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL Tachometer REMIUM NSTRUMENT LUSTER CAUTION!  Indicates the engine speed in revolutions per — G ESCRIPTIONS ASOLINE Driving with a hot engine cooling system could damage minute (RPM x 1000). your vehicle. If the temperature gauge reads “H,” pull Temperature Gauge Instrument Cluster Display over and stop the vehicle.
Page 100: Midline Instrument Cluster - Diesel Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL MIDLINE INSTRUMENT CLUSTER — DIESEL ENGINE...
Page 101: Midline Instrument Cluster Descriptions - Diesel Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL Diesel Exhaust Fluid (DEF) Gauge IDLINE NSTRUMENT LUSTER CAUTION!  The DEF Gauge displays the actual level of Diesel — D ESCRIPTIONS IESEL NGINE Driving with a hot engine cooling system could damage Exhaust Fluid in the DEF tank. DEF is required to your vehicle.
Page 102: Highline Instrument Cluster - Diesel Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL HIGHLINE INSTRUMENT CLUSTER — DIESEL ENGINE...
Page 103: Highline Instrument Cluster Descriptions - Diesel Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL Diesel Exhaust Fluid (DEF) Gauge • The gauge may take up to five seconds to IGHLINE NSTRUMENT LUSTER update after adding a gallon or more of DEF to  The DEF Gauge displays the actual level of Diesel —...
Page 104: Premium Instrument Cluster - Diesel
GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER — DIESEL...
Page 105 GETTING TO KNOW YOUR INSTRUMENT PANEL Holding the OK button on the Instrument Cluster Display controls located on the steering wheel will allow you to change your display from Analog to Digital.
Page 106: Diesel
GETTING TO KNOW YOUR INSTRUMENT PANEL Under very cold conditions, it is possible that Using a driver interactive display located on the REMIUM NSTRUMENT LUSTER the gauge may not reflect the new fill level for instrument panel, your instrument cluster display can —...
Page 107 GETTING TO KNOW YOUR INSTRUMENT PANEL The system allows the driver to select information by NOTE: pushing the following instrument cluster display control  Holding the up / down or left / right arrow buttons located on the left side of the steering wheel. button will loop the user through the currently selected menu or options presented on the screen.
Page 108 GETTING TO KNOW YOUR INSTRUMENT PANEL For Screen Setup:  The main menu options of the home screen are Driver  Oil Pressure Info, Vehicle Info, Navigation — If Equipped, Audio, and  OK button allows user to enter menu and submenus. ...
Page 109: Oil Life Reset
GETTING TO KNOW YOUR INSTRUMENT PANEL Speedometer ESET Push and hold the right arrow button to select “Reset”. Push and release the up or down arrow button until Use this QR code to access your digital the speedometer menu item is highlighted in the experience.
Page 110 GETTING TO KNOW YOUR INSTRUMENT PANEL MIDLINE OR HIGHLINE CLUSTER ACC SET  Gauge Summary When ACC is set, the set speed will display in the  Coolant Temperature — If Equipped  Tire Pressure Monitor System instrument cluster page 117. Ú...
Page 111 GETTING TO KNOW YOUR INSTRUMENT PANEL  Axle Lock And Sway Bar Status (If Equipped):  Elapsed Time value will be displayed in red, and the affected low tire displays front and rear or rear only axle locker will have a red glow. “Trailer Tire Low“ will be displayed Push and hold the right arrow button to reset all graphic, and sway bar connection graphic with text...
Page 112 GETTING TO KNOW YOUR INSTRUMENT PANEL Settings — If Equipped Upper Center Favorite Menus Personal Settings allows the driver to set and recall None Compass Outside Temp Speedometer Vehicle Info Driver Assist features when the transmission is in PARK. Time Range To Empty Average Econ Trailer Tow –...
Page 113: Diesel Messages And Warnings - 6.7L Cummins® Diesel Engine
GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM CLUSTER Fuel Gauge NOTE: If the vehicle’s PIN is forgotten or not known, see an autho-  Hide Range Display Style rized dealer to have the PIN reset. If the PIN is known, you ...
Page 114 GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has the ability to alert you to additional By simply driving your vehicle at highway speeds for as  Exhaust Filter Full — Power Reduced See Dealer — This maintenance required on your vehicle or engine. The little as 45 minutes, you can remedy the condition in message indicates the PCM has derated the engine to following messages may display in your instrument cluster...
Page 115 GETTING TO KNOW YOUR INSTRUMENT PANEL Cold Ambient Derate Mode Messages Diesel Exhaust Fluid (DEF) Warning  5 MPH Max Speed on Restart, Long Idle or Refuel Refill DEF — This message will continuously display when the Messages The vehicle will display messages when a derate (engine counter reaches zero, and will be accompanied by a power reduction) is activated to protect the engine during There are four different messages which are displayed if...
Page 116: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Diesel Exhaust Fluid (DEF) Fault Warning of less than 40 hours, the counter may restart at the value ATTERY AVER ATTERY AVER where it stopped when a previous fault was temporarily Messages — E ESSAGE LECTRICAL remedied, or at a minimum of 50 miles (80 km).
Page 117: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES The following are electrical loads that may be switched off  The battery was discharged by an electrical load left on (if equipped), and vehicle functions which can be affected when the vehicle was parked.
Page 118 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Throttle Control (ETC) Warning If the light remains on when the parking brake has been Vehicles equipped with the Anti-Lock Brake System (ABS) disengaged, and the fluid level is at the full mark on the are also equipped with Electronic Brake Force Distribution Light master cylinder reservoir, it indicates a possible brake...
Page 119: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Seat Belt Reminder Warning Light If the light turns on while driving, safely pull over and stop CAUTION! the vehicle. If the Air Conditioning (A/C) system is on, turn This warning light indicates when the driver or it off.
Page 120 GETTING TO KNOW YOUR INSTRUMENT PANEL Anti-Lock Brake System (ABS) Warning Low Washer Fluid Warning Light  The ESC OFF Indicator Light and the ESC Indicator Light come on momentarily each time the ignition is placed Light This warning light will illuminate when the in the ON/RUN or ACC/ON/RUN position.
Page 121 GETTING TO KNOW YOUR INSTRUMENT PANEL Rear Axle Locker Fault Warning Light — Cruise Control Fault Warning Light If the bulb does not come on when turning the ignition switch from OFF to ON/RUN, have the condition checked If Equipped This warning light will illuminate to indicate the promptly.
Page 122: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Air Suspension Bed Lowering Mode Each tire, including the spare (if provided), should be intended. TPMS malfunctions may occur for a variety of checked monthly when cold and inflated to the inflation reasons, including the installation of replacement or Indicator Light —...
Page 123 GETTING TO KNOW YOUR INSTRUMENT PANEL Cargo Indicator Light — If Equipped Low Diesel Exhaust Fluid (DEF) Indicator 4WD High Indicator Light — If Equipped Light — If Equipped This indicator light will illuminate when the This light alerts the driver that the vehicle is in cargo light is activated by pushing the cargo the 4WD High mode.
Page 124: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Water In Fuel Indicator Light — Adaptive Cruise Control (ACC) Set With Front Fog Indicator Light — If Equipped No Target Detected Indicator Light — If Equipped If Equipped The Water In Fuel Indicator Light will illuminate This indicator light will illuminate when the when there is water detected in the fuel filter.
Page 125: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL ONBOARD DIAGNOSTIC SYSTEM — OBD II Hill Descent Control (HDC) Indicator NOTE: Light — If Equipped  A continuous chime will sound if the vehicle is driven Your vehicle is equipped with a sophisticated Onboard more than 1 mile (1.6 km) with either turn signal on.
Page 126: Onboard Diagnostic System (Obd Ii)
GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND (OBD II) As soon as you cycle the ignition switch to the NBOARD IAGNOSTIC YSTEM ON position, you will see the Malfunction Indicator YBERSECURITY MAINTENANCE PROGRAMS Light (MIL) symbol come on as part of a normal bulb check.
Page 127: Starting The Engine - Gasoline Engine
STARTING AND OPERATING STARTING THE ENGINE — GASOLINE ‘ ™ — I EYLESS NTER GNITION WARNING! ENGINE This feature allows the driver to operate the ignition switch  Do not leave children or animals inside parked vehi- with the push of a button, as long as the Remote Start/ cles in hot weather.
Page 128: Autopark - Rotary Shifter And 8-Speed Transmission Only
STARTING AND OPERATING To Turn Off The Engine Using The ENGINE START/STOP ENGINE START/STOP Button Functions — With Driver’s WARNING! Button Foot Off The Brake Pedal (In PARK Or NEUTRAL Position)  Driver inattention could lead to failure to place the Place the gear selector in PARK, then push and The ENGINE START/STOP button operates similar to an vehicle in PARK.
Page 129: Starting And Operating
STARTING AND OPERATING If the vehicle is not in PARK and the driver exits the vehicle XTENDED TARTING WARNING! with the engine running, the vehicle may AutoPark. NOTE: If vehicle speed is above 1.2 mph (1.9 km/h), the AutoPark will engage when all of these conditions are met: Extended Park condition occurs when the vehicle has not transmission will default to NEUTRAL until the vehicle ...
Page 130: If Engine Fails To Start
STARTING AND OPERATING STARTING THE ENGINE — DIESEL ENGINE NGINE AILS TART CAUTION! If the engine fails to start after you have followed the Before starting your vehicle, adjust your seat, adjust both To prevent damage to the starter, do not crank the “Normal Starting”...
Page 131: Automatic Transmission
STARTING AND OPERATING If you wish to stop the cranking of the engine prior to If the vehicle speed is above 5 mph (8 km/h), the UTOMATIC RANSMISSION the engine starting, remove your foot from the brake ENGINE START/STOP button must be held for two Start the engine with the transmission in the NEUTRAL or pedal and push the ENGINE START/STOP button seconds (or three short pushes in a row) to turn the...
Page 132: Extreme Cold Weather
STARTING AND OPERATING Keyless Enter ‘n Go™ Starting Procedure — After the engine Wait To Start Indicator Light goes off, XTREME EATHER the engine will automatically crank. Engine Manifold Air Temperature 0° F To The Cummins® Turbo Diesel engine is equipped with 66°...
Page 133: Starting Procedure - Engine Manifold Air Temperature 0°F To 66°F (-18°C To 19°C)
STARTING AND OPERATING Follow the steps in the “Normal Starting” procedure After engine start-up, check that the Oil Pressure CAUTION! except: Warning Light has turned off. If the Water in Fuel Indicator Light remains on, DO NOT The Wait To Start Indicator Light will remain on for a Release the parking brake and drive.
Page 134: Starting Procedure - Engine Manifold Air Temperature Below 0°F (-18°C)
STARTING AND OPERATING — E Heat generated by the intake air heater dissipates TARTING ROCEDURE NGINE TARTING LUIDS rapidly in a cold engine. If more than two minutes ANIFOLD EMPERATURE ELOW pass between the time the Wait To Start Indicator WARNING! 0°F (-18°C) Light turns off and the engine is started, recycle the...
Page 135: Normal Operation - Diesel Engine
STARTING AND OPERATING NOTE: EATHER RECAUTIONS WARNING!  Use of Climatized Ultra Low Sulfur Diesel Fuel or Operation in ambient temperature below 32°F (0°C) may  Do not leave the key fob in or near the vehicle, or in Number 1 Ultra Low Sulfur Diesel Fuel results in a require special considerations.
Page 136: Engine Idling
STARTING AND OPERATING Engine Oil Usage NOTE: NGINE DLING High-speed, no-load running of a cold engine can result in For the correct engine oil viscosity page 381. Ú Avoid prolonged idling. Long periods of idling may be excessive white smoke and poor engine performance. Winter Front Cover Usage No-load engine speeds should be kept under 1,000 RPM harmful to your engine because combustion chamber...
Page 137: Noise
STARTING AND OPERATING NOTE: To decrease the RPM, push and hold the SET (-) 10% which is a normal condition of the fuel system and button and the idle speed will decrease to approxi- controls strategy. Diesel equipped vehicles also have an For instrument cluster display messages related to the mately 1,100 RPM.
Page 138: Idle Shutdown
STARTING AND OPERATING Avoid Low Coolant Temperature Operation HUTDOWN CAUTION! Continual operation at low engine coolant (antifreeze) This feature can be enabled so that the truck will If oil pressure falls to less than normal readings, shut temperature below the normal range on the gauge 140°F automatically shutdown when the truck has been idling for the engine off immediately.
Page 139: Engine Block Heater - If Equipped
STARTING AND OPERATING ENGINE BLOCK HEATER — IF EQUIPPED ENGINE BREAK-IN RECOMMENDATIONS — ENGINE BREAK-IN RECOMMENDATIONS — GASOLINE ENGINE DIESEL ENGINE The engine block heater warms the engine, and permits quicker starts in cold weather. Connect the cord to a A long break-in period is not required for the engine and The Cummins®...
Page 140: Parking Brake
STARTING AND OPERATING PARKING BRAKE NOTE: WARNING!  When the parking brake is applied and the transmis- Before leaving the vehicle, make sure that the parking  Do not leave the key fob in or near the vehicle, or in sion is placed in gear, the Brake Warning Light will flash brake is fully applied.
Page 141: Diesel Exhaust Brake - Engine Braking (If Equipped)
STARTING AND OPERATING DIESEL EXHAUST BRAKE — ENGINE CAUTION! BRAKING (IF EQUIPPED) Use of aftermarket exhaust brakes is not recommended and could lead to engine damage. The purpose of the exhaust brake (engine braking) feature is to supply negative (braking) torque from the engine. NOTE: Typically, the engine braking is used for, but not limited to, For optimum braking power it is recommended to use the...
Page 142: Automatic Transmission
STARTING AND OPERATING AUTOMATIC TRANSMISSION CAUTION! WARNING! You must press and hold the brake pedal while shifting out Damage to the transmission may occur if the following  Unintended movement of a vehicle could injure of PARK. precautions are not observed: those in or near the vehicle.
Page 143: Brake/Transmission Shift Interlock (Btsi) System
STARTING AND OPERATING Gear Ranges The electronically controlled transmission adapts its shift RAKE RANSMISSION HIFT schedule based on driver inputs, along with environmental (BTSI) S Do not press the accelerator pedal when shifting from NTERLOCK YSTEM and road conditions. The transmission electronics are PARK or NEUTRAL into another gear range.
Page 144 STARTING AND OPERATING NEUTRAL (N) When frequent transmission shifting occurs (such as CAUTION! when operating the vehicle under heavy loading Use this range when the vehicle is standing for prolonged conditions, in hilly terrain, traveling into strong head  DO NOT race the engine when shifting from PARK or periods with the engine running.
Page 145 STARTING AND OPERATING In the event of a momentary problem, the transmission You can switch between DRIVE and ERS mode at any WARNING! can be reset to regain all forward gears by performing the vehicle speed. When the transmission gear selector is in following steps: DRIVE, the transmission will operate automatically, Do not downshift for additional engine braking on a...
Page 146: 6-Speed Automatic Transmission - If Equipped
STARTING AND OPERATING Normal operation is always the default at engine start-up. Only shift from DRIVE to PARK or REVERSE when the When parking on a hill, apply the parking brake before If TOW/HAUL mode is desired, the switch must be pushed accelerator pedal is released and the vehicle is stopped.
Page 147 STARTING AND OPERATING The following indicators should be used to ensure that you If the transmission becomes extremely hot or is in danger CAUTION! have properly engaged the transmission into the PARK of overheating, the Transmission Temperature Warning position: Light may illuminate and the transmission may operate Towing the vehicle, coasting, or driving for any other differently until the transmission cools down.
Page 148 STARTING AND OPERATING Transmission Limp Home Mode If the transmission cannot be reset, authorized dealer To exit ERS mode, simply push and hold the GEAR “+” service is required. switch until the gear limit display disappears from the Transmission function is monitored electronically for instrument cluster.
Page 149 STARTING AND OPERATING Overdrive Operation Torque Converter Clutch The automatic transmission includes an electronically A feature designed to improve fuel economy has been controlled Overdrive (FIFTH and SIXTH gears). The included in the automatic transmission on your vehicle. A transmission will automatically shift into Overdrive if the clutch within the torque converter engages automatically following conditions are present: at calibrated speeds.
Page 150: Auxiliary Switches - If Equipped
For further information on using the auxiliary switches, road surfaces only. Switch), which is located on the instrument panel. please refer to the Ram Body Builder’s Guide by accessing 4WD LOW https://www.ramtrucks.com/ram-commercial/ Four-Wheel Drive Low Range — This range provides low body-builders-guide.html and choosing the appropriate...
Page 151 STARTING AND OPERATING N (Neutral) When additional traction is required, the transfer case If One Or More Of The Following Shift Conditions Are Not 4WD HIGH and 4WD LOW positions can be used to Met: N (Neutral) — This range disengages both the front and maximize torque to the front driveshaft, forcing the front rear driveshafts from the powertrain.
Page 152 STARTING AND OPERATING 2WD TO 4WD HIGH When operating your vehicle in 4WD LOW, the engine Preferred Procedure speed is approximately three times that of the two-wheel With the engine running, slow the vehicle to 2 to Push the desired position on the four-wheel drive control drive or 4WD HIGH positions at a given road speed.
Page 153: Case (6-Speed Transmission)
STARTING AND OPERATING For additional information on the appropriate use of each This electronically shifted transfer case is designed to be LECTRONICALLY HIFTED RANSFER transfer case position, see the following information: driven in the two-wheel drive position (two-wheel drive) for (6-S ) —...
Page 154 STARTING AND OPERATING Shifting Procedure If All Of The Following Shift Conditions Are Met: WARNING! The current position indicator light will turn OFF. NOTE: Always engage the parking brake when powering down The selected position indicator light will flash until the ...
Page 155: Manually Shifted Transfer Case - If Equipped
STARTING AND OPERATING NOTE: Push the desired position on the transfer case control For additional information on the appropriate use of each switch. transfer case position, see the following information: The four-wheel drive system will not allow shifts between 2WD/4WD HIGH if the front and/or rear wheels are After the desired position indicator light is on (not spinning (no traction).
Page 156 STARTING AND OPERATING 2H OR 4H TO 4L When additional traction is required, the 4H and 4L Because four-wheel drive provides improved traction, positions can be used to lock the front and rear there is a tendency to exceed safe turning and stopping NOTE: driveshafts together and force the front and rear wheels to speeds.
Page 157: Air Suspension System - If Equipped
STARTING AND OPERATING Transfer Case Position Indicator Light Standard Ride Height (SRH) – This is the standard position NOTE: of the suspension and is meant for normal driving. It will  Most 3500 models will not lower to Alternate Trailer The Transfer Case Position Indicator Light in the automatically adjust to maintain the rear ride height as Height (ATH) when unloaded.
Page 158: Instrument Cluster Display Messages
STARTING AND OPERATING Transport Mode  Transport Mode – No indicator lamps will be illumi- NSTRUMENT LUSTER ISPLAY nated. Transport Mode is disabled by driving the For towing your vehicle with four wheels off the road, the ESSAGES vehicle, or deselecting the mode via the interface. air suspension system has a feature which will put the vehicle into Bed Lowering Mode and disable the automatic ...
Page 159: Stabilizer/Sway Bar System - Power Wagon Only
STARTING AND OPERATING The locking axles are controlled by the axle lock buttons. To lock the front axle, if equipped, push the FRONT/REAR LOCK button while traveling less than 10 mph (16 km/h) Under normal driving conditions, the vehicle should be left in 4WD LOW.
Page 160: Safe Off-Road Driving - Power Wagon
STARTING AND OPERATING Due to the use of taller springs, this vehicle has an WARNING! WARNING! increased ride height of approximately 1.9 inches (48.3 mm) in the front and 1.5 inches (38.1 mm) in the Do not disconnect the stabilizer bar and drive on hard If the stabilizer/sway bar will not return to On-Road rear.
Page 161: Driving In Snow, Mud And Sand
STARTING AND OPERATING Skid Plates And Underbody Protection CAUTION! WARNING! Steel skid plates protect the major driveline components The door sill height is 25 inches (63.5 cm). Water may Always wear your seat belt and firmly tie down cargo. of the truck including the fuel tank, transfer case and intrude into the interior of the vehicle at greater depths.
Page 162: Crossing Obstacles (Rocks And Other High Points)
STARTING AND OPERATING  Snow – In heavy snow or for additional control and trac-  Sand – Soft sand is very difficult to travel through with Apply the throttle lightly while holding a light brake tion at slower speeds, shift the transmission to a low full tire pressure.
Page 163: Hill Climbing
STARTING AND OPERATING Crossing A Ravine, Gully, Ditch, Washout  Before Climbing A Steep Hill – As you approach a hill CAUTION! consider its grade or steepness. Determine if it is too Or Rut steep. Look to see what the traction is on the hill side Do not attempt to cross a log with a greater diameter When crossing a ravine, gully, ditch, washout or a large rut, trail.
Page 164: Driving Through Water
STARTING AND OPERATING  Driving Across An Incline – If at all possible avoid RIVING HROUGH ATER WARNING! driving across an incline. If it is necessary, know your vehicle's abilities. Driving across an incline places Extreme care should be taken crossing any type of water. Never attempt to climb a hill at an angle or turn around more weight on the downhill wheels, which increases Water crossings should be avoided if possible and only be...
Page 165: Airing Down For Off-Road Driving
STARTING AND OPERATING  Before You Cross Any Type Of Water – As you approach  Crossing Ditches, Streams, Shallow Rivers Or Other IRING RIVING any type of water you need to determine if you can Flowing Water – Flowing water can be extremely cross it safely and responsibly.
Page 166: Vehicle Recovery
STARTING AND OPERATING  Using The Tow Hooks With A Tow Strap – Tow straps EHICLE ECOVERY CAUTION! are a quick and easy way to recover your vehicle from If you drive off-road, you may encounter a situation where minor situations if you have a secondary vehicle which Pulling the vehicle off an obstacle, without first clearing is not stuck.
Page 167: After Driving Off-Road
STARTING AND OPERATING then place that vehicle in PARK and block the front FTER RIVING WARNING! tires. If you cannot find an anchor point within reach try using your spare tire by burying it. Once you have deter- Off-road operation puts more stress on your vehicle than Never use tow straps with end hooks or link two straps mined an anchor point hook up the cable, ensuring does most on-road driving.
Page 168: Limited-Slip Differential
STARTING AND OPERATING Tensioning The Winch Rope WARNING! WARNING! The winch rope must be properly tensioned before use. Abrasive material in any part of the brakes may cause On vehicles equipped with a limited-slip differential Follow the instructions listed to tension the rope: excessive wear or unpredictable braking.
Page 169: Understanding The Features Of Your Winch
STARTING AND OPERATING Remote Socket: The remote socket (which will be NDERSTANDING EATURES INCH CCESSORIES located on the bumper assembly) allows the remote INCH control to be attached to the control pack to allow the The following accessories are necessary to attach the winch to function.
Page 170: Operating Your Winch
STARTING AND OPERATING Vehicle Recovery Using The Winch PERATING INCH WARNING! CAUTION!  Never attempt to tow a vehicle with the recovery WARNING! strap attached directly to the winch hook.  Always know your winch: Take the time to fully read Failure to observe any of these warnings regarding ...
Page 171 STARTING AND OPERATING Inspect the winch, winch mount, and synthetic rope for Free the winch hook and attach the hook strap. Free damage. Do not use the winch if the mount is loose or the winch hook from its anchor point. Attach the hook rope shows excessive wear, frays, or damage.
Page 172 STARTING AND OPERATING NOTE: Lock the clutch. Lock the winch drum by rotating the clutch lever on the winch to engage. How to choose an anchor point: A secure anchor is critical to winching operations. An anchor must be strong enough NOTE: to hold while winching.
Page 173 STARTING AND OPERATING NOTE:  Avoid overheating the winch motor. For extended winching, stop at reasonable intervals to allow the winch motor to cool down.  What to look for under load: The synthetic rope must always spool onto the drum as indicated by the drum rotation decal on the winch.
Page 174: Rigging Techniques
STARTING AND OPERATING 16. Disconnect the synthetic rope, and disconnect from Stop frequently to tighten and straighten the layers as IGGING ECHNIQUES the anchor. necessary. Repeat this process until the winch hook is the same distance as the full length of the remote control from Various winching situations will require application of 17.
Page 175: Hydraulic Power Steering
STARTING AND OPERATING HYDRAULIC POWER STEERING Increasing Pulling Power YDRAULIC OWER TEERING LUID In some cases, you may find yourself needing more pulling HECK The standard power steering system will provide power. The use of snatch blocks increases mechanical increased vehicle response and maneuverability in tight Checking the power steering fluid level at a defined advantage and that increases your pulling power.
Page 176: Cruise Control Systems - If Equipped
STARTING AND OPERATING CRUISE CONTROL SYSTEMS — IF EQUIPPED WARNING! Your vehicle may be equipped with the Cruise Control Leaving the Cruise Control system on when not in use is system, or the Adaptive Cruise Control (ACC) system: dangerous. You could accidentally set the system or cause it to go faster than you want.
Page 177: Adaptive Cruise Control (Acc)
STARTING AND OPERATING To Resume Speed Metric Speed (km/h) NOTE:  Pushing the SET (+), or SET (-) button once will result in  If the ACC sensor detects a vehicle ahead, ACC will To resume a previously set speed, push the RES button a 1 km/h speed adjustment.
Page 178 STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation Adaptive Cruise Control Ready WARNING! When ACC is activated, but the vehicle speed setting has The buttons on the right side of the steering wheel operate  Cannot take street, traffic, and weather condi- not been selected, the display will read “Adaptive Cruise the Adaptive Cruise Control system.
Page 179 STARTING AND OPERATING NOTE: If ACC is set when the vehicle speed is below 20 mph WARNING! (32 km/h), the set speed will default to 20 mph You cannot engage ACC under the following conditions: (32 km/h). Leaving the Adaptive Cruise Control (ACC) system on ...
Page 180 STARTING AND OPERATING  The vehicle parking brake is applied NOTE: Metric Speed (km/h)  The Trailer Sway Control (TSC) activates  Pushing the SET (+), or SET (-) button once will result in  While in ACC mode, when the vehicle comes to a a 1 km/h speed adjustment.
Page 181 STARTING AND OPERATING Setting The Following Distance In ACC To decrease the distance setting, push the Distance NOTE: Decrease button and release. Each time the button is The “BRAKE!” screen in the instrument cluster display is a The specified following distance for Adaptive Cruise pushed, the distance setting decreases by one bar warning for the driver to take action and does not mean Control (ACC) can be set by varying the distance setting...
Page 182 STARTING AND OPERATING “CLEAN FRONT WINDSHIELD” WARNING If weather conditions are not a factor, the driver should WARNING! examine the sensor. It may require cleaning or removal of The “ACC/FCW Limited Functionality Clean Front an obstruction. The sensor is located in the camera in the When the ACC system is resumed, the driver must Windshield”...
Page 183 STARTING AND OPERATING SERVICE ACC/FCW WARNING TOWING A TRAILER TURNS AND BENDS If the system turns off, and the instrument cluster displays ACC while towing a trailer is recommended only with an When driving on a curve with ACC engaged, the system “ACC/FCW Unavailable Service Required”...
Page 184 STARTING AND OPERATING LANE CHANGING NARROW VEHICLES STATIONARY OBJECTS AND VEHICLES ACC may not detect a vehicle until it is completely in the Some narrow vehicles traveling near the outer edges of ACC does not react to stationary objects or vehicles. For lane in which you are traveling.
Page 185: Parksense Front/Rear Park Assist - If Equipped
STARTING AND OPERATING PARKSENSE FRONT/REAR PARK ASSIST — ENSE ENSORS ENSE ARNING ISPLAY IF EQUIPPED The four ParkSense sensors, located in the rear fascia/ The ParkSense Warning screen is located within the bumper, monitor the area behind the vehicle that is within instrument cluster display.
Page 186 STARTING AND OPERATING Front/Rear ParkSense Arcs 1 — No Tone/Solid Arc 6 — Fast Tone/Flashing Arc 2 — No Tone/Flashing Arc 7 — Fast Tone/Flashing Arc 3 — Fast Tone/Flashing Arc 8 — Slow Tone/Solid Arc 4 — Continuous Tone/Flashing Arc 9 —...
Page 187 STARTING AND OPERATING If an obstacle is detected in the left and/or right rear region, the display will show a single arc in the left and/or right rear region and the system will produce a tone. As the vehicle moves closer to the obstacle, the display will show the single arc moving closer to the vehicle and the tone will change from a single 1/2 second tone to slow, to fast, to continuous. The vehicle is close to the obstacle when the display shows one flashing arc and sounds a continuous tone.
Page 188: Enabling And Disabling Front And/Or Rear Parksense
STARTING AND OPERATING ParkSense Camera Activation This vehicle graphic will be displayed for as long as the LEANING ENSE YSTEM vehicle is in REVERSE. If the ParkSense system detects an obstacle, a camera Clean the ParkSense sensors with water, car wash soap image will display in the radio.
Page 189: Lanesense - If Equipped
STARTING AND OPERATING  Use the ParkSense switch to turn the ParkSense The driver may manually override the haptic warning by CAUTION! system off if obstacles such as bicycle carriers, trailer applying torque to the steering wheel at any time. hitches, etc.
Page 190: Lanesense Warning Message
STARTING AND OPERATING To turn the LaneSense system off, push the LaneSense Left Lane Departure — Only Left Lane Detected NOTE: button again (LED turns on). The LaneSense system operates with similar behavior for  When the LaneSense system is on, the LaneSense a right lane departure when only the right lane marking NOTE: Telltale...
Page 191: Changing Lanesense Status
STARTING AND OPERATING  When the LaneSense system senses a lane drift situa- For example: If approaching the left side of the lane the NOTE: tion, the left lane line turns solid yellow. The LaneSense steering wheel will turn to the right. ...
Page 192: Parkview Rear Back Up Camera
STARTING AND OPERATING PARKVIEW REAR BACK UP CAMERA When the vehicle is shifted out of REVERSE with Camera Cargo Camera Icons — If Equipped delay turned on, the rear Camera image will be displayed for up to 10 seconds after shifting to another gear, unless The ParkView Rear Back Up Camera allows you to see an Back Up Camera Touchscreen Button the vehicle speed exceeds 8 mph (13 km/h), the...
Page 193: Surround View Camera System
STARTING AND OPERATING A dashed centerline overlay indicates the center of the If the vehicle is in PARK, Zoom View is available until the CAUTION! vehicle to assist with parking or aligning to a hitch/ gear selector is placed in DRIVE or REVERSE. receiver.
Page 194 STARTING AND OPERATING Press this button on the touchscreen to enter Modes Of Operation NOTE: the Surround View Camera menu in the Standard Rear View can be manually activated by  Front tires will display on the image when the tires are Uconnect system.
Page 195 STARTING AND OPERATING Back Up Camera View Trailer Reverse Guidance Shifting to NEUTRAL from any gear will maintain the selected view (Zoom or Standard) as long as the vehicle is The Back Up Camera will provide a full screen The Trailer Reverse Guidance will provide below 8 mph (13 km/h).
Page 196 STARTING AND OPERATING The system is deactivated in the following conditions if it Activation Cargo Camera Zoom View was activated manually from the Uconnect controls menu The Dynamic Centerline feature can be activated through When the Cargo Camera image is being via the Surround View button, Back Up Camera button, the Uconnect settings by pressing the Cargo Camera displayed, and the vehicle speed is below...
Page 197 STARTING AND OPERATING Forward Facing Camera With Tire Lines — If Equipped Trailer Reverse Guidance — If Equipped Blind Spot Assist Cameras — If Equipped The Forward Facing Camera displays a front view image of The Trailer Reverse Guidance feature assists the driver in There are cameras located in the exterior mirrors to assist the road ahead, along with tire lines to guide the driver backing up a trailer by providing adjustable camera views...
Page 198: Trailer Cameras - If Equipped
STARTING AND OPERATING TRAILER CAMERAS — IF EQUIPPED Set Up CAUTION! The Trailer Surround View Camera system includes an  To avoid vehicle damage, Surround View should only installation kit with a Trailer Surround View Module and RAILER URROUND AMERA be used as a parking aid.
Page 199 STARTING AND OPERATING For Gooseneck trailers, the connection from the rear can be accessed through Uconnect Settings by pressing Activation fascia goes to the rear chassis inline. the Trailer button in the Trailer Settings or the Camera The Trailer Surround Camera can be activated through the Settings.
Page 200 STARTING AND OPERATING Top View Left View vehicle is shifted into PARK or the ignition is placed in the OFF position. There is a touchscreen X button to The Trailer Top View will show in the Uconnect system with Pressing the Left View button will give the driver disable the display of the camera image.
Page 201: Aux Camera
STARTING AND OPERATING Activation The screen can be exited out by pressing the touch- WARNING! screen X button in the upper right hand corner. This will The AUX Camera is activated by first pressing the Back Up return the display back to the previously displayed Drivers must be careful when backing up even when Camera or Cargo Camera (if equipped) button on the screen.
Page 202: Refueling The Vehicle - Gasoline Engine
STARTING AND OPERATING REFUELING THE VEHICLE — GASOLINE  Tighten the gas cap until you hear a “clicking” sound. CAUTION! This is an indication that the gas cap is tightened prop- ENGINE erly. The MIL in the instrument cluster may turn on if ...
Page 203: Refueling The Vehicle - Diesel Engine
STARTING AND OPERATING REFUELING THE VEHICLE — DIESEL ENGINE NOTE: The purpose of the SCR system is to reduce levels of NOx (oxides of nitrogen emitted from engines) that are harmful In the event that you run the vehicle out of fuel, once to our health and the environment to a near-zero level.
Page 204 STARTING AND OPERATING Adding Diesel Exhaust Fluid NOTE:  Your vehicle is equipped with a DEF injection system. The DEF gauge (located on the instrument cluster) will You may occasionally hear an audible clicking noise. display the level of DEF remaining in the tank This is normal operation.
Page 205: Vehicle Loading
STARTING AND OPERATING  At 40°F (4°C) you could see some increase in the DEF Filling The Def Tank In Cold Climates CAUTION! gauge due to the tank thawing. The gauge and level Since DEF will begin to freeze at 12°F (-11°C), your sensor are working properly and are just updating with ...
Page 206: Gross Axle Weight Rating (Gawr)
STARTING AND OPERATING TRAILER TOWING (GAWR) ROSS EIGHT ATING OADING The GAWR is the maximum permissible load on the front The actual total weight and the weight of the front and rear In this section you will find safety tips and information on and rear axles.
Page 207 STARTING AND OPERATING Tongue Weight (TW) Weight-Distributing Hitch WARNING! The TW is the downward force exerted on the hitch ball by A weight-distributing system works by applying leverage If the gross trailer weight is 5,000 lb (2,267 kg) or the trailer. You must consider this as part of the load on through spring (load) bars.
Page 208 STARTING AND OPERATING Measure the height from the top of the front wheel opening on the fender to the ground, this is height H1. With Weight-Distributing Hitch (Correct) Improper Adjustment Of Weight-Distributing Hitch (Incorrect) RECOMMENDED DISTRIBUTION HITCH Measuring Height (H) ADJUSTMENT Attach the trailer to the vehicle without the weight Towing With 2500/3500 Air Suspension...
Page 209 STARTING AND OPERATING Perform a visual inspection of the trailer and weight Attach the trailer to the vehicle without the weight NOTE: distributing hitch to confirm manufacturer’s distribution bars connected. For all towing conditions, we recommend towing with recommendations have been met. TOW/HAUL mode engaged.
Page 210: Trailer Hitch Type And Maximum Trailer Weight
STARTING AND OPERATING RAILER ITCH YPE AND AXIMUM RAILER EIGHT The following chart provides the maximum trailer weight a given factory equipped trailer hitch type can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition.
Page 211: Trailer Reverse Steering Control - If Equipped
STARTING AND OPERATING connecting a trailer, you will see a “Calibrate Trailer” RAILER EVERSE TEERING 0 — When the vehicle is not in Reverse, press the TRSC message in the instrument cluster when pressing the button while at a standstill. A “Calibrate Trailer” message —...
Page 212 STARTING AND OPERATING Using TRSC Continue to control the accelerator and brake while Instrument Cluster Messages: backing the trailer up. The following graphics will display  “Calibrate Trailer” will display when a trailer is not cali- CAUTION! on the radio screen to warn the user if the trailer is brated and the vehicle is at a standstill while the button approaching a jackknife angle.
Page 213 STARTING AND OPERATING  “Trailer Steering Unavailable Trailer Angle Too Steep” NOTE: The following are guidelines for attaching the stickers to will display when trailer is calibrated, the TRSC button your trailer:  If the trailer is not identified, drive forward to align the is pressed and the trailer is at a jackknife angle.
Page 214: Towing Requirements
STARTING AND OPERATING POST APPLICATION: Do not power wash decal area for WARNING! 72 hours.  When hauling cargo or towing a trailer, do not over- OWING EQUIREMENTS load your vehicle or trailer. Overloading can cause a loss of control, poor performance or damage to To promote proper break-in of your new vehicle drivetrain brakes, axle, engine, transmission, steering, suspen- components, the following guidelines are recommended.
Page 215 STARTING AND OPERATING Towing Requirements — Tires WARNING!  Do not attempt to tow a trailer while using a compact  Do not connect trailer brakes to your vehicle's spare tire. hydraulic brake lines. It can overload your brake  Do not drive more than 50 mph (80 km/h) when towing system and cause it to fail.
Page 216 STARTING AND OPERATING Trailer Brake Status Indicator Light Adjusting GAIN Push the RIGHT arrow on the steering wheel to enter “TRAILER TOW”. This light indicates the trailer electrical connection status. NOTE: Push the UP or DOWN buttons until the Trailer Brake This should only be performed in a traffic free environment If no electrical connection is detected after the ignition is at speeds of approximately 20–25 mph (30–40 km/h).
Page 217 STARTING AND OPERATING Display Messages NOTE: The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. The trailer brake control interacts with the instrument  An aftermarket controller may be available for use with Refer to the following illustrations.
Page 218 STARTING AND OPERATING When activated the feature will enable all of the exterior The sequence will only activate if the following conditions lights sequentially for up to five minutes for time to walk are met: around and verify functionality. The following exterior ...
Page 219: Towing Tips
STARTING AND OPERATING Cruise Control — If Equipped There are unique electrical systems that must be OWING connected to properly ensure operator safety and prevent  Do not use on hilly terrain or with heavy loads. Before setting out on a trip, practice turning, stopping, and overloading vehicle systems.
Page 220: Snowplow Prep Package Model Availability
STARTING AND OPERATING The blade should be lowered whenever the vehicle is NOWPLOW ACKAGE ODEL ENERAL AINTENANCE parked. VAILABILITY Snowplows should be maintained in accordance with the Maintain and operate your vehicle and snowplow plow manufacturer's instructions. equipment following the recommendations provided by For Information about snowplow applications visit the specific snowplow manufacturer.
Page 221: Recreational Towing (Behind Motorhome)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE Towing Condition Wheels OFF The Ground Two-Wheel Drive Models Four-Wheel Drive Models See Instructions  Automatic transmission in PARK Flat Tow NONE NOT ALLOWED  Transfer case in N (Neutral) ...
Page 222: Recreational Towing - Two-Wheel Drive Models
STARTING AND OPERATING — T ECREATIONAL OWING HEEL CAUTION! CAUTION! RIVE ODELS  Do not disconnect the driveshaft because fluid may  Before recreational towing, the transfer case must leak from the transmission, causing damage to be in N (Neutral). To be certain the transfer case is DO NOT flat tow this vehicle.
Page 223 STARTING AND OPERATING Shifting Into N (Neutral) Shift the transfer case into N (Neutral): 11. Turn the ignition to the OFF mode, then cycle the ignition to the RUN mode and back to the OFF mode.  With manual shift transfer case, shift the transfer Use the following procedure to prepare your vehicle for Remove the key fob from the ignition.
Page 224 STARTING AND OPERATING Shifting Out Of N (Neutral) NOTE: NOTE: When shifting out of transfer case N (Neutral), turning the With electronic shift transfer case: Use the following procedure to prepare your vehicle for engine off is not required, but may be helpful to avoid gear ...
Page 225: Driving Tips
STARTING AND OPERATING DRIVING TIPS Shallow Standing Water RIVING HROUGH ATER Although your vehicle is capable of driving through shallow Driving through water more than a few inches/ RIVING LIPPERY URFACES standing water, consider the following Cautions and centimeters deep will require extra caution to ensure Warnings before doing so.
Page 226: Off-Road Driving Tips
STARTING AND OPERATING  Check threaded fasteners for looseness, particularly RIVING CAUTION! on the chassis, drivetrain components, steering, and Care should be taken when attempting to climb steep hills suspension. Retighten them, if required, and torque to  Always check the depth of the standing water before or driving diagonally across a hill or slope.
Page 227: Uconnect Systems
MULTIMEDIA UCONNECT SYSTEMS Your vehicle may be equipped with certain security WARNING! features to reduce the risk of unauthorized and unlawful access to vehicle systems and wireless communications. For detailed information about your Uconnect 5/5 NAV  ONLY insert trusted media devices/components into Vehicle software technology continues to evolve over time With 8.4-inch Display system or your Uconnect 5 NAV With your vehicle.
Page 228: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS USTOMER ROGRAMMABLE EATURES 1 — Uconnect Buttons On The Touchscreen 2 — Uconnect Buttons On The Faceplate The Uconnect system uses a combination of buttons on the touchscreen and buttons on the faceplate located on For The Uconnect 3 With 5-inch Display, The Uconnect the center of the instrument panel.
Page 229 MULTIMEDIA Display When the Display button is pressed on the touchscreen, the system will display the options related to the theme (if equipped), brightness, and color of the touchscreen. The available settings are: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will change the language of the Uconnect system and Instrument Cluster...
Page 230 MULTIMEDIA Setting Name Description This setting will allow you to adjust the brightness of your theme. Setting options are Theme Mode “Light”, “Dark” and “Auto”. Select to show themes in Light or Dark mode. “Auto” changes the theme with the headlights. Touchscreen Beep This setting will allow you to turn the touchscreen beep on or off.
Page 231 This setting will allow you to change the voice options for the radio to “Male” or “Female”. This setting will allow you to set the system “Wake Up” word. The available options are “Wake Up” Word “Off”, “Hey, Uconnect”, and “Hey, Ram”. Voice Barge-in This setting will allow Voice Barge-in to be turned on or off.
Page 232 MULTIMEDIA Setting Name Description This setting will activate the vehicle’s comfort system and heated seats or heated steering wheel when the vehicle is remote started or ignition is started. The “Off” setting Auto-On Driver Heated/Ventilated Seat & Heated Steering Wheel will not activate the comfort systems.
Page 233 MULTIMEDIA Safety/Driving Assistance When the Safety/Driving Assistance button is selected on the touchscreen, the system displays the options related to the vehicle’s safety settings. These options will differ depending on the features equipped on the vehicle. The settings may display in list form or within subfolders on the screen. To access a subfolder, select the desired folder; the available options related to that feature will then display on the screen.
Page 234 MULTIMEDIA Setting Name Description This setting will change the type of alert provided when an object is detected in a vehicle’s blind spot. The “Off” setting will turn off Blind Spot Alert. The “Lights” setting will Blind Spot Alert activate the Blind Spot Alert lights on the outside mirrors. The “Lights & Chime” setting will activate both the lights on the outside mirrors and an audible chime.
Page 235 MULTIMEDIA Clock & Date When the Clock & Date button is pressed on the touchscreen, the system displays the different options related to the vehicle’s internal clock. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will sync the time to the GPS receiver in the system.
Page 236 MULTIMEDIA Phone/Bluetooth® When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smartphone. The list of paired audio devices or smartphones can be accessed from this menu. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 237 This setting will allow you to set the system’s “Wake Up” word. The available options are Wake Up Word “Off”, “Hey, Uconnect”, and “Hey, Ram”. This setting allows you to respond to a Voice Response before the statement is Voice Barge-In completed by the system.
Page 238 MULTIMEDIA Navigation — If Equipped When the Navigation button is pressed on the touchscreen, the system displays options related to the vehicle’s built-in Navigation system. These settings can change which icons display on the map, how “time to arrival is calculated”, and route types. For more information on Navigation and settings, refer to your Uconnect Radio Instruction Manual.
Page 239 MULTIMEDIA Setting Name Description Options for each trailer are “Use This Trailer”, “Braking” (Light Electric, Heavy Electric, Light Electric Over Hydraulic, and Heavy Electric Over Hydraulic), “Trailer Name”, and Trailer 3 “Tire Pressure” (Setup All Tires, Replace Single Tire, Set Target Tire Pressure, and Delete Tire Settings).
Page 240 MULTIMEDIA Camera When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will add a timed delay to the Surround View Camera when shifting out of Surround View Camera Delay REVERSE.
Page 241 MULTIMEDIA Mirrors & Wipers When the Mirrors & Wipers button is pressed on the touchscreen, the system displays the options related to the vehicle’s mirrors and wipers. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will tilt the outside side-view mirrors when the ignition is in the ON/RUN position and the transmission gear selector is in the REVERSE position.
Page 242 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE:  When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchase. ...
Page 243 MULTIMEDIA Brakes After pressing the Brakes button on the touchscreen, the following setting will be available: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Brake Service This setting will allow you to retract the brakes for servicing. Doors &...
Page 244 MULTIMEDIA Setting Name Description This setting will change how many pushes of the Unlock button on the key fob are needed to unlock all the doors. The “Driver Door” setting will only unlock the driver door on the Remote Door Unlock, Door Lock/1st Press Of Key Fob Unlocks first push on the Unlock button.
Page 245 MULTIMEDIA Key Off Options/Engine Off Options When the Key Off Options/Engine Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is set to OFF. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 246 MULTIMEDIA Suspension/Air Suspension When the Suspension/Air Suspension button is pressed on the touchscreen, the system will display settings related to the vehicle’s air suspension. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will display suspension messages in the Instrument Cluster Display. The “All” Display Suspension Messages setting will display all available messages.
Page 247 MULTIMEDIA Audio When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 248 MULTIMEDIA Notifications When the Notifications button is pressed on the touchscreen, the system displays the options related to Notifications for the system. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will turn off the Notification chime that plays when a new notification is sent. Notification Sounds The options are “On”...
Page 249 MULTIMEDIA SiriusXM® Setup When the SiriusXM® Setup button is pressed on the touchscreen, the system displays options related to SiriusXM® satellite radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning. NOTE: ...
Page 250 MULTIMEDIA Software Updates — If Equipped When the Software Updates button is pressed on the touchscreen, the system will display the setting related to updating the Uconnect software. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will allow software updates to happen over Wi-Fi.
Page 251 MULTIMEDIA Reset When the Reset button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can clear personal data and reset selected settings from other menus. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 252: Uconnect Introduction
MULTIMEDIA UCONNECT INTRODUCTION YSTEM VERVIEW Uconnect 3 With 5-inch Display 1 — RADIO Button 6 — COMPASS Button 2 — MEDIA Button 7 — SETTINGS Button 3 — PHONE Button 8 — MORE Button 4 — VOLUME & On/Off Button 9 —...
Page 253 MULTIMEDIA NOTE: Uconnect screen images are for illustration purposes only and may not reflect exact software for your vehicle. Feature Description Press/Push the Radio button or Media button to enter Radio Mode/Media Mode and Radio/Media access the radio functions and external audio sources page 253.
Page 254: Safety And General Information
MULTIMEDIA Feature Description COMPASS Push the COMPASS button on the faceplate to access the vehicle’s compass. MORE Push the MORE button on the faceplate to access additional options.  Become familiar with the Uconnect features and appli-  Keep drinks, rain and other sources of moisture away AFETY ENERAL NFORMATION...
Page 255: Uconnect Modes
MULTIMEDIA UCONNECT MODES Pushing the right-hand control’s center button will make ADIO the radio switch between the various modes available Radio Controls (AM/FM/SXM or Media, etc.). TEERING HEEL UDIO ONTROLS The left-hand control is a rocker-type switch with a push The remote sound system controls are located on the rear button in the center.
Page 256 MULTIMEDIA The radio is equipped with the following modes: Tune/Scroll Control NOTE:  AM Turn the rotary TUNE/SCROLL control knob clockwise to Pressing and holding either the Seek Up increase or counterclockwise to decrease the radio station  FM Seek Down button will scan the different frequency frequency.
Page 257 MULTIMEDIA SiriusXM® Satellite Radio Mode — Undo SiriusXM® services require subscriptions, sold separately after the trial included with the new vehicle purchase. If If Equipped You can backspace an entry by pressing you decide to continue your service at the end of your trial Back button on the touchscreen.
Page 258 MULTIMEDIA No Subscription When in Satellite Mode: Radios equipped with a Satellite receiver require a  The SXM button on the touchscreen is highlighted. subscription to the SiriusXM® Service. When the radio  The SiriusXM® Presets are displayed at the top of the does not have the necessary subscription, the radio is screen.
Page 259 MULTIMEDIA REPLAY Replay provides a means to store and replay up to 22 minutes of music audio and 48 minutes of talk radio. Once the channel is switched, content in replay memory is lost. Press the Replay button on the touchscreen. The Play/Pause, Rewind/Forward and Live buttons will display at the top of the screen, along with the replay time.
Page 260 MULTIMEDIA FAVORITES Remove Favorites Press the All button on the Browse Screen. When pressing Press the Remove Favorites tab at the top of the screen. Press the Favorites button on the touchscreen to activate the All button, the following categories become available: Press the Delete All button on the touchscreen to delete the favorites menu, which will time out within 20 seconds all of the Favorites or press the Trash Can icon next to the...
Page 261 MULTIMEDIA Setting Presets Audio Settings Add/Delete — If Equipped Press the Add/Delete button on the touchscreen to Press the Audio button within the settings main menu to activate the League Scroll list. Press the chosen league activate the Audio Settings screen. and a scroll list of all teams within the league will appear, then you can select a team by pressing the corresponding box.
Page 262 MULTIMEDIA Audio Setting Description Press the Balance/Fade button on the touchscreen to balance audio between the front Balance/Fade speakers or fade the audio between the rear and front speakers. Press the Front, Rear, Left or Right button or press and drag the red Speaker icon to adjust the Balance/Fade. Press the + or - button or press and drag the level bar to increase or decrease each of the Equalizer equalizer bands.
Page 263: Media Mode
MULTIMEDIA Audio Source Selection BLUETOOTH® MODE EDIA Once in Media Mode, press the Source or Source Select Overview Operating Media Mode button on the touchscreen and the desired mode button Bluetooth® Streaming Audio or Bluetooth® Mode is on the touchscreen. USB, AUX, and Bluetooth® are the entered by pairing a Bluetooth®...
Page 264 MULTIMEDIA Controlling The Auxiliary Device Browse Repeat Auxiliary Mode (AUX) is entered by inserting an AUX device In USB Mode, press the Browse button on the touchscreen In USB Mode, press the Repeat button on the touchscreen using a cable with a 3.5 mm audio jack into the AUX port. to display the browse window.
Page 265: Phone Mode
MULTIMEDIA Tracks  Calling Back the last incoming call number Push the VR button located on the steering wheel. (“Call Back”). In USB Mode, press the Tracks button on the touchscreen After the beep, say one of the following commands and to display a pop-up with the Song List.
Page 266 MULTIMEDIA Uconnect Phone allows you to transfer calls between the Voice Command Button  For each feature explanation in this section, only the system and your mobile phone as you enter or exit your compound command form of the voice command is The Voice Command button on your steering vehicle and enables you to mute the system's microphone given.
Page 267 MULTIMEDIA HELP COMMAND To complete the pairing process, you will need to NOTE: reference your mobile phone’s manual. Please visit  If there are no phones currently connected with If you need assistance at any prompt, or if you want to UconnectPhone.com for complete mobile phone the system, a pop-up will appear asking if you know your options at any prompt, say “Help”...
Page 268 MULTIMEDIA If “No” is selected, and you still would like to pair a NOTE: Press to select the particular phone or the particular mobile phone, press the Phone Pairing or Settings audio device. A pop-up menu will appear; press For phones which are not made a favorite, the phone button from the Uconnect Phone main screen.
Page 269 MULTIMEDIA MANAGING YOUR FAVORITES — IF EQUIPPED The option’s pop-up will be displayed. See the Uconnect website, UconnectPhone.com, for supported phones. Press the Disconnect Device or the Delete Device There are two ways you can add an entry to your favorites: button on the touchscreen.
Page 270 MULTIMEDIA Phone Call Features KEY PAD NUMBER ENTRY The following features can be accessed through the Press the Phone button. Uconnect Phone if the feature(s) are available and Press the Dial/Keypad button on the touchscreen. supported by Bluetooth® on your mobile service plan. For The Touch-Tone screen will be displayed.
Page 271 MULTIMEDIA DO NOT DISTURB PLACE/RETRIEVE A CALL FROM HOLD With Do Not Disturb, you can disable notifications from During an active call, press the Hold or Call On Hold button incoming calls and texts, allowing you to keep your eyes on on the Phone main screen.
Page 272 MULTIMEDIA JOIN CALLS Advanced Phone Connectivity WARNING! When two calls are in progress (one active and one on TRANSFER CALL TO AND FROM MOBILE ALWAYS drive safely with your hands on the wheel. hold), press the Join/Merge Calls button on the Phone You have full responsibility and assume all risks related PHONE main screen to combine all calls into a conference call.
Page 273 MULTIMEDIA Performance such as audio clarity, echo, and loudness to Voice Text Reply — If Equipped NOTE: a large degree rely on the phone and network, and not the Only use the numbering listed in the provided table. Uconnect can announce incoming text messages. Push Uconnect Phone.
Page 274: Connected Vehicle Services - If Equipped
MULTIMEDIA BLUETOOTH® COMMUNICATION LINK What Is SiriusXM Guardian™? NTRODUCTION ONNECTED EHICLE Mobile phones may lose connection to the Uconnect ERVICES SiriusXM Guardian™ uses an embedded device in the Phone. When this happens, the connection can generally Uconnect system installed in your vehicle, which receives One of the many benefits of your vehicle’s Uconnect be re-established by restarting the mobile phone.
Page 275: Services
MULTIMEDIA Activation — If Equipped Features And Packages Not all SiriusXM Guardian™ features are available for all models. To unlock the full potential of SiriusXM Guardian™ in your After the trial period, you must purchase a subscription to SiriusXM Guardian™ provides: vehicle, you must activate your SiriusXM Guardian™...
Page 276 MULTIMEDIA  Once on the Remote screen and you have set up For customers in Canada, press the My Vehicle button. your four-digit PIN, you can begin using Remote Door Select from “Dashboard”, “Vehicle Health Report”, and Lock/Unlock, Remote Vehicle Start, and activate your “Recalls”.
Page 277: Using Siriusxm Guardian
MULTIMEDIA Log on to your Owner’s Account at https:// SiriusXM Guardian™ In-Vehicle Assistance Features How It Works www.mopar.com/en-us.html (US Residents) and With SiriusXM Guardian™, your vehicle has onboard Push the SOS Call button; the indicator light will turn select “Dashboard”, or www.mopar.ca (Canadian assistance features located on the rearview mirror or green indicating a call has been placed.
Page 278 MULTIMEDIA SOS Call System Limitations  LTE (voice/data) or 4G (data) coverage and/or GPS WARNING! signals are unavailable or obstructed. Vehicles that have been purchased in the US and that travel into Mexico and Canada may have limited services.  Network congestion. ...
Page 279 MULTIMEDIA Remote Commands After a crash where the airbags deploy: WARNING! Automatic SOS will initiate a call with an agent. On the Remote Commands screen, you have access to  Ignoring the Rearview Mirror Light could mean you several vehicle features that can be controlled remotely An agent will receive the call and confirm the location will not have SOS Call services if needed.
Page 280 MULTIMEDIA Using A Remote Command Through Your Mobile Device A message will appear on the screen to let you know Requirements And The Vehicle Branded App if the command was received by your vehicle.  Vehicle must be properly equipped with SiriusXM Press the desired Remote Command icon on your Guardian™.
Page 281 MULTIMEDIA Assist — If Equipped You can also send a command to turn off an engine that NOTE: has been started using Remote Vehicle Start. After The SiriusXM Guardian™ Customer Care agents are not Description 15 minutes, if you have not entered your vehicle with the authorized for Remote Vehicle Start services.
Page 282 MULTIMEDIA How It Works You acknowledge, agree and consent to any recording, Requirements monitoring or sharing of information obtained through any Simply push the ASSIST button in the vehicle and you will  Vehicle must have an operable LTE (voice/data) or 4G such call recordings.
Page 283 MULTIMEDIA 4G Wi-Fi Hotspot — If Equipped Create A 4G Wi-Fi Hotspot For Use In Your Vehicle Once the 4G Wi-Fi Hotspot is purchased, you can change its name and the password by selecting the Wi-Fi Hotspot How It Works Description App and pressing the Setup Wi-Fi Hotspot button.
Page 284 MULTIMEDIA Stolen Vehicle Assistance — If Equipped Requirements This data collection and transmission begins when you enroll in SiriusXM Guardian™ and will continue even if you  Vehicle must be properly equipped with the Uconnect Description cancel your SiriusXM Guardian™ subscription unless you system.
Page 285 MULTIMEDIA In-Vehicle Notifications — If Equipped Family Drive Alerts — If Equipped Here are a few of the many questions you can ask Alexa:  “Alexa, ask <vehicle brand> to start my <vehicle Description Description name> with your Voice Code.” Your vehicle will send you notifications to remind you when Family Drive Alerts help promote safer driving and give you ...
Page 286: Manage M Y Sirius Xm Guardian Account
MULTIMEDIA XM G ™ SOS FAQ — SmartWatch Integration — If Equipped ANAGE IRIUS UARDIAN ONNECTED ERVICES Description CCOUNT QUIPPED SmartWatch Integration puts the Vehicle Branded App To manage your SiriusXM Guardian™ account, press the What happens if I accidentally push the SOS Call right on your Apple®...
Page 287: Connected Services Roadside Assistance Faqs
MULTIMEDIA Will my vehicle be safe if I lose my device? People Can I select a different route than the most recent ONNECTED ERVICES OADSIDE sometimes lose their mobile devices, which is why one I sent to my vehicle? Yes, once you enter the SSISTANCE security measures have been engineered into the vehicle, and start the engine, the pop-up message...
Page 288: Connected Services Stolen Vehicle Assistance Faqs - If Equipped
MULTIMEDIA Why can’t all mobile devices use the Vehicle Branded ONNECTED ERVICES TOLEN EHICLE ONNECTED ERVICES EMOTE EHICLE App? The Vehicle Branded App has been designed to — I SSISTANCE QUIPPED TART work on most devices with the Apple® and Android™ operating systems.
Page 289: Connected Services Account
MULTIMEDIA How do I create a SiriusXM Guardian™ security PIN? Can I access every App and service while driving? No, ONNECTED ERVICES CCOUNT Set up your SiriusXM Guardian™ Security PIN during some applications and services are not available — I QUIPPED the registration process.
Page 290: Data Collection & Privacy
MULTIMEDIA 13. How do I find out how much longer I have on my 17. What if I forgot to remove my account information Even if you cancel your SiriusXM Guardian™ subscription, subscription? Contact SiriusXM Guardian™ Customer before I returned my lease vehicle or sold it? Contact this vehicle diagnostic health information, including Care.
Page 291: Regulatory And Safety Information
MULTIMEDIA The radio manufacturer believes the internal wireless EGULATORY AFETY radio is safe for use by consumers. The level of energy NFORMATION emitted is far less than the electromagnetic energy emitted by wireless devices such as mobile phones. US/CANADA However, the use of wireless radios may be restricted in Exposure to Radio Frequency Radiation some situations or environments, such as aboard airplanes.
Page 292: Off-Road Pages Status Bar
MULTIMEDIA AGES TATUS 1 — Transfer Case Status 2 — Latitude/Longitude The Off-Road Pages Status Bar is located along the bottom 3 — Altitude of Off-Road Pages and is present in each of the selectable 4 — Hill Descent Control Status And Target Speed page options.
Page 293: Vehicle Dynamics
MULTIMEDIA EHICLE YNAMICS 1 — Steering Angle 2 — Transfer Case Status The Vehicle Dynamics page displays information 3 — Rear Axle concerning the vehicle’s transfer case and steering angle. 4 — Rear Axle Locker Status The following information is displayed: Status of Transfer Case Status of Front Axles Status of the Rear Axles...
Page 294: Accessory Gauge
MULTIMEDIA CCESSORY AUGE 1 — Coolant Temperature 2 — Oil Temperature The Accessory Gauge page displays the current status of 3 — Oil Pressure the vehicle’s Coolant Temperature, Oil Temperature, Oil 4 — Battery Voltage Pressure, Transmission Temperature, and Battery 5 —...
Page 295: Pitch & Roll
MULTIMEDIA & R NOTE: ITCH Pitch & Roll values may show upon startup. These The Pitch & Roll page displays the vehicle’s current pitch numbers will update once the vehicle is driven. (angle up and down) and roll (angle side to side) in degrees.
Page 296: Suspension
MULTIMEDIA USPENSION ORWARD ACING AMERA The Suspension page displays the current status of the Your vehicle may be equipped with a Forward Facing vehicle’s suspension system and the current ride height of Camera that allows you to see an on-screen image of the the vehicle.
Page 297: Safety Features
SAFETY SAFETY FEATURES The ABS is designed to function with the Original WARNING! Equipment Manufacturer (OEM) tires. Modification may result in degraded ABS performance. (ABS)  The capabilities of an ABS equipped vehicle must RAKE YSTEM never be exploited in a reckless or dangerous WARNING! manner that could jeopardize the user’s safety or the The ABS provides increased vehicle stability and brake...
Page 298: Rear Seat Reminder Alert (Rsra)
SAFETY (RSRA) (EBC) EMINDER LERT LECTRONIC RAKE ONTROL WARNING! YSTEM RSRA alerts you of the possible presence of an object, The Brake Assist System (BAS) cannot prevent the passenger, or pet in the rear seats through a visual and natural laws of physics from acting on the vehicle, nor Your vehicle is equipped with an advanced Electronic auditory notification.
Page 299 SAFETY Electronic Roll Mitigation (ERM) Electronic Stability Control (ESC) WARNING! ERM anticipates the potential for wheel lift by monitoring ESC enhances directional control and stability of the  Electronic Stability Control (ESC) cannot prevent the the driver’s steering wheel input and the speed of the vehicle under various driving conditions.
Page 300 SAFETY ESC Operating Modes WARNING! WARNING! Depending upon model and mode of operation, the ESC  In the ESC “Full Off” mode, the engine torque reduc-  When in “Partial Off” mode, the TCS functionality of system may have multiple operating modes. tion and stability features are disabled.
Page 301 SAFETY The ESC Activation/Malfunction Indicator Light (located in HDC Has Three States:  3rd = 1.8 mph (3 km/h) the instrument cluster) starts to flash as soon as the tires Off (feature is not enabled and will not activate).  4th = 2.5 mph (4 km/h) lose traction and the ESC system becomes active.
Page 302 SAFETY Disabling HDC  The cluster icon and switch light will flash when HDC  HSA will work in REVERSE gear and all forward gears. deactivates due to overheated brakes. The flashing will The system will not activate if the transmission is in HDC will be deactivated and disabled if any of the stop and HDC will activate again once the brakes have PARK or NEUTRAL.
Page 303: Auxiliary Driving Systems
SAFETY Towing With HSA Traction Control System (TCS) WARNING! HSA will also provide assistance to mitigate roll back while The TCS monitors the amount of wheel spin of each of the If TSC activates while driving, slow the vehicle down, towing a trailer.
Page 304 SAFETY When the vehicle is started, the BSM Warning Light will The system may also detect blockage if the vehicle is If the blockage message is still present after cycling the momentarily illuminate in both outside rearview mirrors to operated in areas with extremely low radar returns such as ignition and driving in traffic, check again for a blockage.
Page 305 SAFETY Entering From The Side Overtaking Traffic The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, Vehicles that move into your adjacent lanes from either If you pass another vehicle slowly with a relative speed berms, snow banks, car washes, etc.
Page 306 SAFETY Rear Cross Path (RCP) NOTE: Blind Spot Alert Lights/Chime In a parking lot situation, oncoming vehicles can be When operating in Blind Spot Alert Lights/Chime mode, RCP is intended to aid the driver when backing out of blocked by vehicles parked on either side. If the sensors the BSM system will provide a visual alert in the parking spaces where their vision of oncoming vehicles are blocked by other structures or vehicles, the system will...
Page 307 SAFETY Blind Spot Assist Cameras  Maximum Mode — When “Max Mode” is selected, the system will default to the maximum blind spot zone There are cameras located in the exterior mirrors to assist regardless of what size trailer is attached in blind spot detection.
Page 308: Forward Collision Warning (Fcw) With Mitigation - If Equipped
SAFETY NOTE: NOTE: WARNING! Fifth wheel or gooseneck trailers are not supported by Trailer length is determined within +/- 3 ft (1 m) of actual Trailer Merge Assist. length. Trailers that are the same size as the category The Blind Spot Monitoring system is only an aid to help limit, 10/20/30 ft (3/6/9 m), could be subject to being detect objects in the blind spot zones.
Page 309 SAFETY If the driver does not take action based upon these When the system determines a collision with the vehicle in WARNING! progressive warnings, then the system will provide a front of you is no longer probable, the warning message limited level of active braking to help slow the vehicle and will be deactivated Ú...
Page 310 SAFETY FCW Limited Warning  When FCW status is set to “Only Warning”, this By changing the FCW status setting to "Near", the system prevents the system from providing limited Active provides possible collision warnings on objects closer to If the instrument cluster displays “ACC/FCW Limited Braking, or additional brake support if the driver is not the vehicle.
Page 311: Tire Pressure Monitoring System (Tpms)
SAFETY If a PEB event begins at a speed below 39 mph (62 km/h), Changing the PEB status to “Off” deactivates the system, The cold tire inflation pressure must not exceed the the system may provide maximum braking to mitigate the so no warning or active braking will be available in case of maximum inflation pressure molded into the tire sidewall.
Page 312 SAFETY For example, your vehicle may have a recommended cold NOTE: The TPMS uses wireless technology with wheel rim (parked for more than three hours) placard pressure of mounted electronic sensors to monitor tire pressure  The TPMS is not intended to replace normal tire care 30 psi (207 kPa).
Page 313 SAFETY Service TPMS Warning A system fault may occur due to an incorrect TPMS sensor location condition. When a system fault occurs due to an If a system fault is detected, the TPMS Warning Light will incorrect TPMS sensor location, the TPMS Warning Light flash on and off for 75 seconds and then remain on solid.
Page 314 15 mph (24 km/h), the TPMS Warning Light will flash the driver through the instrument cluster, when either a connected to your Ram truck, initiate the pairing process on and off for 75 seconds and then remain on solid. In...
Page 315 SAFETY NOTE: Service TTPMS Warning If the pairing process times out after three minutes of no If a system fault is detected, the instrument cluster will communication with a sensor, a double horn chip will display a “Trailer Tire Pressure System Service Required” occur indicating the pairing has failed and a message will message for a minimum of five seconds.
Page 316 SAFETY System Limitations If the Hazard Warning Flashers do not come on while In the Selectable Tire Fill Alert application, which is located inflating the tire, the TPMS sensor may be in an in the apps menu of the Uconnect system, the customer The TTPMS may have difficulty transmitting through inoperative position, preventing the TPMS sensor signal will be able to select a pressure setting for both the front...
Page 317: Occupant Restraint Systems
SAFETY Tire Pressure Information System (TPIS) The system will be activated when the TPMS receiver If the ignition switch is cycled, this sequence will repeat, module detects a change in tire pressure. The ignition providing the system fault still exists. If the system fault no 3500 Series Trucks must be in the RUN mode, with the transmission in longer exists, the "SERVICE TPM SYSTEM"...
Page 318: Important Safety Precautions
SAFETY The driver and front passenger seats should be Research has shown that seat belts save lives, and they MPORTANT AFETY RECAUTIONS moved back as far as practical to allow the front air can reduce the seriousness of injuries in a collision. Some Please pay close attention to the information in this bags room to inflate.
Page 319 SAFETY BeltAlert Warning Sequence NOTE: WARNING! If BeltAlert has been deactivated and the driver or The BeltAlert warning sequence is activated when the outboard front seat passenger (if equipped with outboard  It is dangerous to ride in a cargo area, inside or vehicle is moving above a specified vehicle speed range front passenger seat BeltAlert) is unbuckled the Seat Belt and the driver or outboard front seat passenger is...
Page 320 SAFETY WARNING! WARNING!  A lap belt worn too high can increase the risk of injury  A shoulder belt placed behind you will not protect you in a collision. The seat belt forces won’t be at the from injury during a collision. You are more likely to strong hip and pelvic bones, but across your hit your head in a collision if you do not wear your abdomen.
Page 321 SAFETY Lap/Shoulder Belt Untwisting Procedure Position the lap belt so that it is snug and lies low across your hips, below your abdomen. To remove Use the following procedure to untwist a twisted lap/ slack in the lap belt portion, pull up on the shoulder shoulder belt.
Page 322 SAFETY When the seat belt is long enough to fit, insert the WARNING! mini-latch plate into the mini-buckle until you hear a “click.”  Wearing your seat belt incorrectly could make your injuries in a collision much worse. You might suffer Sit back in seat.
Page 323 SAFETY First Row Center Lap Belt Operating WARNING! Instructions — If Equipped  Using a Seat Belt Extender when not needed can The center seating position for the Mega Cab and Crew increase the risk of serious injury or death in a colli- Cab front seat has a lap belt only.
Page 324 SAFETY Seat Belt Pretensioner If the passenger seating position is equipped with an ALR and is being used for normal usage, only pull the seat belt The front outboard seat belt system is equipped with webbing out far enough to comfortably wrap around the pretensioning devices that are designed to remove slack occupant’s mid-section so as to not activate the ALR.
Page 325: Supplemental Restraint Systems (Srs)
SAFETY How To Engage The Automatic Locking Mode  Supplemental Side Air Bags UPPLEMENTAL ESTRAINT YSTEMS Buckle the combination lap and shoulder belt.  Front and Side Impact Sensors — If Equipped (SRS) Grab the shoulder portion and pull downward until ...
Page 326 SAFETY Redundant Air Bag Warning Light The ORC also includes diagnostics that will illuminate the instrument panel Air Bag Warning Light if a malfunction is If a fault with the Air Bag Warning Light is detected that could affect the air bag system. The detected, which could affect the Supplemental diagnostics also record the nature of the malfunction.
Page 327 SAFETY 3500 Series Truck WARNING! WARNING! The Advanced Front Air Bag system has multistage driver  Never install a rear-facing child restraint in the front  Relying on the air bags alone could lead to more and front passenger air bags. This system provides output seat of a vehicle.
Page 328 SAFETY The steering wheel hub trim cover and the upper Supplemental Side Air Bag Inflatable Curtains (SABICs) passenger side of the instrument panel separate and fold This vehicle is equipped with Supplemental Side Air Bag out of the way as the air bags inflate to their full size. The Inflatable Curtains (SABICs).
Page 329 SAFETY The SABICs may help reduce the risk of partial or complete Vehicle damage by itself is not a good indicator of whether WARNING! ejection of vehicle occupants through side windows in or not Side Air Bags should have deployed. certain side impact events.
Page 330 SAFETY If A Deployment Occurs The Side Air Bags and seat belt pretensioners will not Do not drive your vehicle after the air bags have deployed. deploy in all rollover events. The rollover sensing system If you are involved in another collision, the air bags will not The front air bags are designed to deflate immediately determines if a rollover event may be in progress and be in place to protect you.
Page 331 SAFETY Maintaining Your Air Bag System Enhanced Accident Response System perform the NOTE: following functions: After an accident, remember to cycle the ignition to the STOP (OFF/LOCK) position and remove the key from the WARNING!  Cut off fuel to the engine (if equipped) ignition switch to avoid draining the battery.
Page 332: Child Restraints
SAFETY Event Data Recorder (EDR) To read data recorded by an EDR, special equipment is There are different sizes and types of restraints for required, and access to the vehicle or the EDR is needed. children from newborn size to the child almost large This vehicle is equipped with an event data recorder In addition to the vehicle manufacturer, other parties, enough for an adult safety belt.
Page 333 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and who have Either an Infant Carrier or a Convertible Child Restraint, Infants and Toddlers not reached the height or weight limits of their child facing rearward in a rear seat of the vehicle...
Page 334 SAFETY Older Children And Child Restraints WARNING! WARNING! Children who are two years old or who have outgrown their Do not install a rear-facing car seat using a rear support  Improper installation can lead to failure of an infant rear-facing convertible child seat can ride forward-facing leg in this vehicle.
Page 335 SAFETY Children Too Large For Booster Seats Does the shoulder belt cross the child’s shoulder If the answer to any of these questions was “no,” then the between the neck and arm? child still needs to use a booster seat in this vehicle. If the Children who are large enough to wear the shoulder belt child is using the lap/shoulder belt, check seat belt fit Is the lap part of the belt as low as possible, touching...
Page 336 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight of the Restraint Type LATCH – Lower Anchors LATCH – Lower Anchors + Seat Belt + Top Tether Child + Child Restraint Seat Belt Only Only Top Tether Anchor Anchor...
Page 337 SAFETY Crew Cab 60/40 Split Bench LATCH Positions Mega Cab LATCH Positions Crew Cab Full Bench LATCH Positions Top Tether Anchorage Symbol Top Tether Anchorage Symbol Top Tether Anchorage Symbol Lower Anchorage Symbol Lower Anchorage Symbol Lower Anchorage Symbol (2 Anchorages Per Seating Position) (2 Anchorages Per Seating Position) (2 Anchorages Per Seating Position) Frequently Asked Questions About Installing Child Restraints With LATCH...
Page 338 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Regular Cab Front / Crew Cab with full bench rear seat: Use the seat belt and tether anchor to install a child seat Can a child seat be installed in the center position using N/A –...
Page 339 SAFETY Locating The LATCH Anchorages Locating The Upper Tether Anchorages The lower anchorages are round bars that are Regular Cab models have tether strap found at the rear of the seat cushion where it anchorages behind the front center and right meets the seatback.
Page 340 SAFETY Center Seat LATCH WARNING! Regular Cab Or Crew Cab Full Bench Rear Seat: No Lower Never use the same lower anchorage to attach more Center LATCH Anchorages Available than one child restraint. For typical installation instructions, see page 338. Ú...
Page 341 SAFETY Installing Child Restraints Using The Attach the lower hooks or connectors of the child If the buckled seat belt interferes with the child restraint restraint to the lower anchorages in the selected installation, instead of buckling it behind the child Vehicle Seat Belt seating position.
Page 342 SAFETY Lap/Shoulder Belt Systems For Installing Crew Cab And Mega Cab Child Restraints In This Vehicle The seat belts in the passenger seating positions are equipped with either a Switchable Automatic Locking Retractor (ALR) or a cinching latch plate or both. Both types of seat belts are designed to keep the lap portion of the seat belt tight around the child restraint so that it is not necessary to use a locking clip.
Page 343 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts The head restraints can be removed in every rear seating position if they interfere Can the rear head restraints be removed? with the installation of the child restraint page 36. Ú...
Page 344 SAFETY If the child restraint has a top tether strap and the Place the child seat in the center of the seating If the buckle or the cinching latch plate is too close to the seating position has a top tether anchorage, connect position.
Page 345 SAFETY Regular And Mega Cab Trucks: Route the tether strap to provide the most direct path Right Or Left Outboard Seats: between the anchorage and the child seat. The tether In the regular cab truck, the top tether Raise the head restraint and reach between the rear strap should go between the head restraint posts anchorages are located behind the center and seat and rear glass to access the tether strap loop.
Page 346 SAFETY Place a child restraint on the seat and adjust the Attach the hook to the center tether strap loop (see Center Seat: tether strap so that it will reach over the seat back, diagram). Tighten the tether strap according to the Raise the head restraint and reach between the rear under the head restraint, through the tether strap child seat manufacturer’s instructions.
Page 347 SAFETY Pass the tether strap hook under the head restraint Tighten the tether straps according to the child seat behind the child seat, through the tether strap loop manufacturer’s instructions, tightening the right and behind the seat and over to the right or left outboard left tether straps before the center tether strap.
Page 348: Safety Tips
SAFETY SAFETY TIPS Air Bag Warning Light ONNECTED EHICLES The Air Bag Warning Light will turn on for four to Privacy of any wireless and wired communications cannot RANSPORTING ASSENGERS eight seconds as a bulb check when the be assured. Third parties may unlawfully intercept ignition switch is first placed in the ON/RUN information and private communications without your NEVER TRANSPORT PASSENGERS IN THE CARGO AREA.
Page 349: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY WARNING! WARNING! WARNING! An improperly attached, damaged, folded, or stacked  ONLY use the driver’s side floor mat on the driver’s  If the vehicle carpet has been removed and floor mat, or damaged floor mat fasteners may cause side floor area.
Page 350: Exhaust Gas
SAFETY Lights ARBON ONOXIDE ARNINGS WARNING! Have someone observe the operation of brake lights and  If you are required to drive with the trunk/liftgate/ exterior lights while you work the controls. Check turn WARNING! rear doors open, make sure that all windows are signal and high beam indicator lights on the instrument Carbon monoxide (CO) in exhaust gases is deadly.
Page 351: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS NOTE: When you must leave the vehicle to seek assistance, the If your vehicle is equipped with a 12–inch Uconnect Hazard Warning Flashers will continue to operate even though the ignition is placed in the OFF position. display, the Hazard Warning Flashers button is located The Hazard Warning Flashers button is located on the upper switch bank just below the radio.
Page 352  The vehicle brand. wheel. You have full responsibility and assume all risks  Ram Connect Customer Care (if equipped) – Total  The last known GPS coordinates of the vehicle. related to the use of the features and applications in support for Radio, Phone and NAV issues.
Page 353 REASON (INCLUDING DURING OR AFTER AN ACCI- ator until the SOS operator terminates the connec-  The Occupant Restraint Control module turns on the DENT), THE UCONNECT OR RAM CONNECT tion. Air Bag Warning Light on the instrument panel if a...
Page 354: Jacking And Tire Changing
IN CASE OF EMERGENCY Even if the SOS Call system is fully functional, factors NOTE: WARNING! beyond FCA US LLC’s control may prevent or stop the SOS  Your vehicle may be transmitting data as authorized by Call system operation. These include, but are not limited ...
Page 355: Preparations For Jacking
IN CASE OF EMERGENCY NOTE: Remove the jack and tools by turning the wing bolt REPARATIONS ACKING counterclockwise, remove the wing bolt and then slide the Passengers should not remain in the vehicle when the Park the vehicle on a firm, level surface. Avoid ice or assembly out from under the seat.
Page 356: Removing The Spare Tire
IN CASE OF EMERGENCY CAUTION! WARNING!  The lug wrench can only be attached to extension After using the jack and tools, always reinstall them in two (2). the original carrier and location. While driving you may experience abrupt stopping, rapid acceleration or sharp ...
Page 357: Jacking Instructions
IN CASE OF EMERGENCY Pull the spare tire out from under the vehicle to gain ACKING NSTRUCTIONS access to the spare tire retainer. Lift the spare tire with one hand to give clearance to WARNING! tilt the retainer at the end of the cable. Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: ...
Page 358 IN CASE OF EMERGENCY See the following steps for proper jacking and tire removal: Remove the spare wheel, jack, and tools from storage. Using the lug wrench, loosen, but do not remove, the wheel nuts by turning them counterclockwise one turn while the wheel is still on the ground.
Page 359 IN CASE OF EMERGENCY CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. Front Jacking Location When changing the front wheel, assemble the jack driver to the jack and connect the jack driver to the extension tubes.
Page 360: To Stow The Flat Or Spare
IN CASE OF EMERGENCY Remove the lug nuts and pull the wheel off. On Single NOTE: Rear Wheel (SRW) trucks, install the spare wheel and The bottle jack will not lower by turning the dial (thumb- lug nuts with the cone shaped end of the wheel nuts wheel) by hand, it may be necessary to use the jack driver toward the wheel.
Page 361: Reinstalling The Jack And Tools
IN CASE OF EMERGENCY Lay the wheel flat after the retainer is installed. Rotate the lug wrench handle clockwise until the wheel is drawn into place against the underside of Attach the lug wrench to the extension tubes with the the vehicle.
Page 362: Hub Caps/Wheel Covers - If Equipped
IN CASE OF EMERGENCY NOTE: For 2500/3500 Single Rear Wheel (SRW) models, use the flat end of the lug wrench to hook and pull off the hub cap. Ensure that the jack and tool bracket assembly slides into Find the opening in the hub cap, insert the lug wrench, and the front hold down location.
Page 363: Jump Starting
IN CASE OF EMERGENCY JUMP STARTING WARNING! If your vehicle has a discharged battery, it can be jump  Remove any metal jewelry such as rings, watch started using a set of jumper cables and a battery in bands and bracelets that could make an inadvertent another vehicle, or by using a portable battery booster electrical contact.
Page 364: Gear Selector Override
IN CASE OF EMERGENCY Connecting The Jumper Cables Disconnect the opposite end of the positive (+) WARNING! jumper cable from the positive (+) post of the vehicle Connect the positive (+) end of the jumper cable to with the discharged battery, and reinstall the Do not connect the jumper cable to the negative (-) post the positive (+) post of the discharged vehicle.
Page 365: Manual Park Release
IN CASE OF EMERGENCY Insert a screwdriver or similar tool into the access To push or tow the vehicle in cases where the port (ringed circle) on the bottom of the steering transmission will not shift out of PARK (such as a depleted column, and push and hold the override release lever battery), a Manual Park Release is available.
Page 366: If Your Engine Overheats
IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS While holding the locking tab in the disengaged To Reset The Manual Park Release: position, pull the tether strap to rotate the lever Push the locking tab to the right, to unlock the lever. rearward, until it locks in place pointing towards the If the vehicle is overheating, it will need to be serviced by Rotate the Manual Park Release lever forward to its...
Page 367: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY FREEING A STUCK VEHICLE If the temperature gauge is moving towards or close to the WARNING! HOT (H) position, you can reduce the potential for overheating by taking the appropriate action. If your vehicle becomes stuck in mud, sand, or snow, it can Fast spinning tires can be dangerous.
Page 368: Towing A Disabled Vehicle
IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described on page 219. Ú...
Page 369: Two-Wheel Drive Models
IN CASE OF EMERGENCY If the transmission is not operable, or the vehicle must be HEEL RIVE ODELS HEEL RIVE ODELS towed faster than 30 mph (48 km/h) or farther than FCA US LLC recommends towing your vehicle with all four 30 miles (48 km), tow with the rear wheels OFF the FCA US LLC recommends towing with all wheels OFF the wheels OFF the ground using a flatbed.
Page 370: Emergency Tow Hooks - If Equipped
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM — MERGENCY OOKS WARNING! QUIPPED (EARS)  Do not use a chain for freeing a stuck vehicle. Chains may break, causing serious injury or death. Your vehicle may be equipped with emergency tow hooks. This vehicle is equipped with an Enhanced Accident ...
Page 371: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING An authorized dealer will reset the oil change indicator NOTE: message after completing the scheduled oil change. If a  It is recommended that every 3,000 miles (4,800 km), scheduled oil change is performed by someone other than check the engine oil level at least 30 minutes after a CAUTION! an authorized dealer, the message can be reset by...
Page 372 SERVICING AND MAINTENANCE Perform Service Indicator — Diesel Engine Once A Month Or Before A Long Trip:  Inspect the CV/Universal joints. Your vehicle will require emissions maintenance at a set  Check engine oil level.  Inspect brake pads, shoes, rotors, drums, hoses and interval.
Page 373: Maintenance Plan - Gasoline Engine
SERVICING AND MAINTENANCE — G AINTENANCE ASOLINE NGINE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Under no circumstances should oil change intervals exceed 8,000 miles (13,000 km), 12 months or 350 hours of engine run time, Change engine oil.
Page 374 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Replace spark plugs. Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Inspect the transfer case fluid, change for any of the following: police, taxi, fleet, or frequent trailer towing.
Page 375: Maintenance Plan - Diesel Engine
SERVICING AND MAINTENANCE — D AINTENANCE IESEL NGINE Mileage Or Time Passed (Whichever Comes First): Or Months: 102 108 114 120 Or Kilometers: Change engine oil every 15,000 miles (24,000 km) or 12 months or 500 Hours or sooner if prompted by the oil change indicator system, whichever comes first.
Page 376 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First): Or Months: 102 108 114 120 Or Kilometers: Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary.
Page 377 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First): Or Months: 102 108 114 120 Or Kilometers: Inspect the front and rear axle surfaces. If gear oil leakage is suspected, check the fluid level. If using your vehicle for police, taxi, fleet, off-road or frequent trailer towing change the axle fluid.
Page 378 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First): Or Months: 102 108 114 120 Or Kilometers: Replace Crankcase Ventilation Filter (CCV). Flush and replace power steering fluid. Flush and replace engine coolant. *** 1. Under no circumstances should the engine air cleaner filter exceed 30,000 miles (48,000 km) or 24 months, whichever comes first. WARNING! ...
Page 379: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 6.4L G ASOLINE NGINE 1 — Engine Coolant Pressure Cap 6 — Engine Air Cleaner Filter 2 — Engine Oil Fill 7 — Power Steering Reservoir Cap 3 — Engine Oil Dipstick 8 — Power Distribution Center (Fuses) 4 —...
Page 380: L Diesel Engine - 6-Speed 68Rfe
SERVICING AND MAINTENANCE 6.7L D — 6-S 68RFE IESEL NGINE PEED 1 — Battery 7 — Brake Fluid Reservoir Cap 2 — Engine Coolant Pressure Reservoir 8 — Battery 3 — Engine Coolant Reservoir Cap 9 — Engine Air Cleaner Filter 4 —...
Page 381: L Diesel Engine - 6-Speed As69Rc Hd
SERVICING AND MAINTENANCE 6.7L D — 6-S AS69RC HD IESEL NGINE PEED 1 — Battery 7 — Brake Fluid Reservoir Cap 2 — Engine Coolant Pressure Cap 8 — Battery 3 — Engine Coolant Pressure Reservoir 9 — Power Distribution Center (Fuses) 4 —...
Page 382: Checking Oil Level
SERVICING AND MAINTENANCE HECKING EVEL DDING ASHER LUID AINTENANCE ATTERY To ensure proper engine lubrication, the engine oil must The fluid reservoir is located under the hood and the fluid Your vehicle is equipped with a maintenance-free battery. be maintained at the correct level. Check the oil level at level should be checked at regular intervals.
Page 383: Pressure Washing
SERVICING AND MAINTENANCE Engine Oil Selection — Diesel Engine Service Manuals are available which include detailed CAUTION! service information for your vehicle. Refer to these Service Use only the manufacturer's recommended fluid Manuals before attempting any procedure yourself.  It is essential when replacing the cables on the Ú...
Page 384: Engine Oil Filter
SERVICING AND MAINTENANCE Synthetic Engine Oils Engine Air Cleaner Filter Inspection And Engine Oil Filter Selection Replacement — Gasoline Engine A full-flow type disposable oil filter should be used for Your engine was designed for synthetic engine oils, only replacement. The quality of replacement filters varies use synthetic API approved engine oils.
Page 385 SERVICING AND MAINTENANCE Remove the engine air cleaner filter from the housing Lift the engine air cleaner filter cover to access the CAUTION! assembly. engine air cleaner filter. Do not overtighten the engine air cleaner filter cover lid Remove the engine air cleaner filter from the housing screws or damage may result.
Page 386: Air Conditioner Maintenance
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Installation NOTE: WARNING! Use only manufacturer approved A/C system PAG NOTE: compressor oil and refrigerants.  Use only refrigerants and compressor lubricants Inspect and clean the housing if significant dirt or debris is approved by the manufacturer for your air condi- Refrigerant Recovery And Recycling —...
Page 387 SERVICING AND MAINTENANCE The cabin air filter is located in the fresh air inlet behind There are travel stops on both sides of the glove Remove the filter cover by pushing in on the finger the glove compartment. Perform the following procedure compartment.
Page 388: Accessory Drive Belt Inspection
SERVICING AND MAINTENANCE Remove the cabin air filter by pulling it straight out of Reinstall the glove compartment on the hinges. Reattach the glove compartment tension tether by the housing. inserting the tether clip in the glove compartment and Pull the tension tether outward and reinstall the glove sliding the clip away from the face of the glove compartment past the travel stops by pushing in on compartment door.
Page 389 SERVICING AND MAINTENANCE When inspecting accessory drive belts, small cracks that  Belt broken (identify and correct problem before new If water is detected in the water separator while the engine run across ribbed surface of belt from rib to rib, are belt is installed) is running, or while the ignition switch is in the ON position, considered normal.
Page 390: Diesel Engine
SERVICING AND MAINTENANCE Drain the fuel/water separator filters when the Water In NGINE OUNTED ILTER CAUTION! Fuel Indicator Light is ON. Within 10 minutes of vehicle — D EPLACEMENT IESEL NGINE shutdown, turn the engine mounted filter drain valve  Diesel fuel will damage blacktop paving surfaces. (located on the side of the filter assembly) Drain the filter into an appropriate container.
Page 391: Underbody Mounted Fuel Filter Replacement - Diesel Engine
SERVICING AND MAINTENANCE Wipe clean the sealing surfaces of the lid and Ensure engine is turned off. housing. Place drain pan under the fuel filter drain hose. Install new o-ring back into ring groove on the filter Open the water drain valve one full turn counter- housing and lubricate with clean engine oil.
Page 392: Priming If The Engine Has Run Out Of Fuel - Diesel Engine
SERVICING AND MAINTENANCE RIMING NGINE NTERVENTION EGENERATION WARNING! — D — M IESEL NGINE TRATEGY ESSAGE ROCESS Do not use alcohol or gasoline as a fuel blending agent. They can be unstable under certain conditions and be The Cummins® diesel engine meets all Environmental WARNING! hazardous or explosive when mixed with diesel fuel.
Page 393: Diesel Exhaust Fluid (Def)
SERVICING AND MAINTENANCE Additionally, your vehicle has the ability to alert you to Avoid using the wiper blades to remove frost or ice from UBRICATION additional maintenance required on your truck or engine the windshield. Keep the blade rubber out of contact with Locks and all body pivot points, including such items as petroleum products such as engine oil, gasoline, etc.
Page 394 SERVICING AND MAINTENANCE Wiper Blade Removal/Installation To disengage the wiper blade from the wiper arm, flip up the locking tab. CAUTION! Do not allow the wiper arm to spring back against the glass without the wiper blade in place or the glass may be damaged.
Page 395: Exhaust System
SERVICING AND MAINTENANCE With the wiper blade disengaged, remove the wiper Installing The Front Wipers WARNING! blade from the wiper arm by holding the wiper arm Lift the wiper arm off of the glass, until the wiper arm with one hand and separating the wiper blade from ...
Page 396: Cooling System
SERVICING AND MAINTENANCE Engine Coolant Checks Under normal operating conditions, the catalytic converter OOLING YSTEM will not require maintenance. However, it is important to Check the engine coolant (antifreeze) protection every keep the engine properly tuned to ensure proper catalyst WARNING! 12 months (before the onset of freezing weather, where operation and prevent possible catalyst damage.
Page 397 SERVICING AND MAINTENANCE Selection Of Coolant Adding Coolant  Use only high purity water such as distilled or deionized water when mixing the water/engine coolant (anti- Your vehicle has been built with an improved engine For further information page 446. Ú...
Page 398: Charge Air Cooler - Inter-Cooler
SERVICING AND MAINTENANCE Cooling System Pressure Cap Checking Coolant Level — 6.4L Engine  Maintain engine coolant concentration at a minimum of 50% OAT coolant (conforming to MS.90032) and The cap must be fully tightened to prevent loss of engine The level of the coolant in the pressurized coolant bottle distilled water for proper corrosion protection of your coolant (antifreeze), and to ensure that engine coolant will...
Page 399: Brake System
SERVICING AND MAINTENANCE RAKE YSTEM UTOMATIC RANSMISSION WARNING! Special Additives In order to ensure brake system performance, all brake  Use only manufacturer's recommended brake fluid system components should be inspected periodically page 448. Using the wrong type of brake fluid can Ú...
Page 400 SERVICING AND MAINTENANCE Fluid Level Check — 8-Speed Transmission Use the following procedure to check the transmission The fluid level should be between the “HOT” (upper) fluid level properly: reference holes on the dipstick at normal operating The fluid level is preset at the factory and does not require temperature.
Page 401: Level
SERVICING AND MAINTENANCE Reinsert the dipstick until fully seated and lock it CAUTION! down. The bending of the blade will orient the cap in the correct position. Do not force or rotate the cap Using a transmission fluid other than the into another position.
Page 402: Transfer Case
SERVICING AND MAINTENANCE Drain And Refill Drain And Refill Required Maintenance For Noise Control Systems For the proper maintenance intervals page 369. For the proper maintenance intervals page 369. Ú Ú Lubricant Selection Selection Of Lubricant The following maintenance services must be performed every six months or 7,500 miles (12,000 km) whichever Use only the manufacturer's recommended fluid For further information...
Page 403 SERVICING AND MAINTENANCE Tampering With Noise Control System Noise Emission Warranty Among those acts presumed to constitute tampering are the following: Prohibited The manufacturer warrants that this vehicle as AIR CLEANER manufactured by the manufacturer, was designed, built Federal law prohibits the following acts or the causing and equipped to conform at the time it left the ...
Page 404 SERVICING AND MAINTENANCE Maintenance Log and Service Chart (Diesel Engines) Noise Systems Maintenance Chart and Service Log — Insert Month, Day, Year under column mileage closest to the mileage at which service was performed. MILES 7,500 15,000 22,500 30,000 37,500 45,000 52,500 60,000...
Page 405: Fuses
SERVICING AND MAINTENANCE Power Distribution Center USES CAUTION! The Power Distribution Center is located in the engine General Information If it is necessary to wash the engine compartment, take compartment near the battery. This center contains care not to directly hit the fuse box, and the windshield cartridge fuses, micro fuses, relays, and circuit breakers.
Page 406 SERVICING AND MAINTENANCE Power Distribution Center Location Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare 60 Amp Yellow – ABS Pump Mtr 60 Amp Yellow – Rad Fan HI / Lo *...
Page 407 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 50 Amp Red – 400W Inverter 50 Amp Red – Air Suspension Comp 40 Amp Green – STOM 40 Amp Green – Starter Solenoid 20 Amp Blue – NOX Sensor * 30 Amp Pink Gas –...
Page 408 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 30 Amp Pink – Driver Door Mod 30 Amp Pink – FT Wiper – – Spare – – Spare 20 Amp Blue – TRLR Tow B / U 20 Amp Blue –...
Page 409 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 10 Amp Red Upfitters Relay Coils * – – Spare – – Spare – 15 Amp Blue IP Cluster / CSG – 20 Amp Yellow Air Suspension Mod * –...
Page 410 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 10 Amp Red AEB RACAM HTR * – 15 Amp Blue SCR Mod 12 Volt * – 30 Amp Green Fuel Pump Mtr / Fuel Htr RLY –...
Page 411 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare – 20 Amp Yellow Power Outlet / Batt – – Power Outlet / Acc – 10 Amp Red Invertor MOD / USB-IP / WCPM * –...
Page 412: Bulb Replacement
SERVICING AND MAINTENANCE EPLACEMENT Replacement Bulbs, Names, And Part Numbers In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers. All of the inside bulbs are brass or glass-wedge base. Aluminum base bulbs are not approved.
Page 413 SERVICING AND MAINTENANCE Exterior Bulbs Bulb Name Bulb Number Front Fog Lamps (LED Headlamps) Side Indicators (Front And Side View Mirror) Base Rear Tail/Turn and Stop Lamp 3157K Premium Rear Tail/Turn and Stop Lamp Base Tail/Backup Lamp W21/5W Center High Mounted Stop Lamp (CHMSL) Cab Roof Marker Lamps Rear Lamp Bar ID Marker Lamp Side Marker Lamps (Dual Rear Wheels)
Page 414 SERVICING AND MAINTENANCE Reach through the access hole of the wheel house Rotate the bulb counterclockwise a quarter turn to Look under the hood and behind the headlamp to splash shield and disengage the bulb access cover by unlock the bulb from the lamp. find the high beam bulb access cover.
Page 415 SERVICING AND MAINTENANCE Outer Front Park And Turn Reach through the access hole of the wheel house Halogen splash shield and disengage the side marker socket See the following steps to replace: See the following steps to replace: by rotating counterclockwise a quarter turn. Open the hood.
Page 416 SERVICING AND MAINTENANCE REAR TAIL/STOP, TURN SIGNAL AND CENTER HIGH MOUNTED STOP LAMP (CHMSL) BACKUP LAMPS WITH CARGO LAMP See the following steps to replace: See the following steps to replace: Remove the two screws and pushpins that pass Remove the two screws holding the housing/lens to through the bed sheet metal.
Page 417 SERVICING AND MAINTENANCE CAB TOP CLEARANCE LAMPS — IF EQUIPPED REAR LAMP BAR ID MARKER (DUAL REAR Pull the desired bulb straight from the socket. WHEELS) — IF EQUIPPED See the following steps to replace: See the following steps to replace: Remove the screws from the top of the lamp.
Page 418: Tires
SERVICING AND MAINTENANCE SIDE MARKER LAMPS (DUAL REAR WHEELS) — Tire Markings NOTE: IF EQUIPPED  P (Passenger) — Metric tire sizing is based on US design standards. P-Metric tires have the letter “P” molded See the following steps to replace: into the sidewall preceding the size designation.
Page 419 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 420 SERVICING AND MAINTENANCE EXAMPLE: Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire:  XL = Extra load (or reinforced) tire, or  LL = Light load tire or ...
Page 421 SERVICING AND MAINTENANCE EXAMPLE: 03 = Number representing the week in which the tire was manufactured (two digits)  03 means the 3rd week 01 = Number representing the year in which the tire was manufactured (two digits)  01 means the year 2001 ...
Page 422 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: Number of people that can be carried in the vehicle. NOTE: The proper cold tire inflation pressure is listed on the Total weight your vehicle can carry. driver’s side B-pillar or the rear edge of the driver's side Tire size designed for your vehicle.
Page 423: Tires - General Information
SERVICING AND MAINTENANCE Steps For Determining Correct Load (5) Determine the combined weight of  For the following example, the combined weight of occupants and cargo should never exceed 865 lbs Limit— luggage and cargo being loaded on the (392 kg). vehicle.
Page 424 SERVICING AND MAINTENANCE Safety Fuel Economy Inflation pressures specified on the placard are always “cold tire inflation pressure”. Cold tire inflation pressure is Underinflated tires will increase tire rolling resistance WARNING! defined as the tire pressure after the vehicle has not been resulting in higher fuel consumption.
Page 425 SERVICING AND MAINTENANCE Tire Pressures For High Speed Operation Tire Repair NOTE: TPMS sensor must be replaced after driving the vehicle on If your tire becomes damaged, it may be repaired if it The manufacturer advocates driving at safe speeds and a flat tire condition.
Page 426 SERVICING AND MAINTENANCE Tread Wear Indicators Life Of Tire NOTE: Wheel valve stem must be replaced as well when installing Tread wear indicators are in the original equipment tires to The service life of a tire is dependent upon varying factors new tires due to wear and tear in existing tires.
Page 427: Tire Types
SERVICING AND MAINTENANCE Snow Tires It is recommended you contact an authorized tire dealer or YPES original equipment dealer with any questions you may Some areas of the country require the use of snow tires All Season Tires — If Equipped have on tire specifications or capability.
Page 428 SERVICING AND MAINTENANCE Spare Tire Matching Original Equipped Tire Inflate collapsible tire only after the wheel is properly WARNING! installed to the vehicle. Inflate the collapsible tire using And Wheel — If Equipped the electric air pump before lowering the vehicle. Compact and collapsible spares are for temporary Your vehicle may be equipped with a spare tire and wheel emergency use only.
Page 429: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE Limited Use Spare — If Equipped Your wheels are susceptible to deterioration caused by NOTE: salt, sodium chloride, magnesium chloride, calcium If you intend parking or storing your vehicle for an The limited use spare tire is for temporary emergency use chloride, etc., and other road chemicals used to melt ice extended period after cleaning the wheels with wheel only.
Page 430 SERVICING AND MAINTENANCE Snow Traction Device 2500 4x2 (2WD) Axle Tire/Wheel Size (Maximum Projection Beyond Tire Profile Trim Level Or Equivalent) LT245/70R17E Tradesman LT275/70R18E Bighorn Rear LT275/70R18E U Class Laramie LT285/60R20E Longhorn Limited LT285/60R20E Snow Traction Device 2500 4x4 (4WD) Axle Tire/Wheel Size (Maximum Projection Beyond Tire Profile...
Page 431 SERVICING AND MAINTENANCE Snow Traction Device 3500 SRW 4x2 (2WD) & 4x4 (4WD) Axle Tire/Wheel Size (Maximum Projection Beyond Tire Profile Trim Level Or Equivalent) Tradesman LT275/70R18E Bighorn Rear U Class Limited LT275/70R18E Laramie LT285/60R20E Longhorn Snow Traction Device 3500 DRW 4x2 (2WD) Axle Tire/Wheel Size (Maximum Projection Beyond Tire Profile...
Page 432: Tire Rotation Recommendations
SERVICING AND MAINTENANCE Snow Traction Device 3500 DRW 4x4 (4WD) Axle Tire/Wheel Size (Maximum Projection Beyond Tire Profile Trim Level Or Equivalent) Tradesman Bighorn Limited Front/Rear LT235/80R17E U Class Laramie Longhorn OTATION ECOMMENDATIONS WARNING! CAUTION! Tires on the front and rear axles of vehicles operate at Using tires of different size and type (M+S, Snow) ...
Page 433 SERVICING AND MAINTENANCE The suggested rotation method is the “rearward cross”  If the tires are rotated incorrectly, The auto localization shown in the following diagram. This rotation pattern does of the TPIS sensors will fail to locate correctly resulting not apply to some directional tires that must not be in incorrect locations for the pressure values displayed reversed.
Page 434: Department Of Transportation Uniform
SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION READWEAR RACTION RADES UNIFORM TIRE QUALITY GRADES The Treadwear grade is a comparative The Traction grades, from highest to rating, based on the wear rate of the tire lowest, are AA, A, B, and C. These grades The following tire grading categories when tested under controlled conditions represent the tire's ability to stop on wet...
Page 435: Temperature Grades
SERVICING AND MAINTENANCE BODYWORK EMPERATURE RADES WARNING! The Temperature grades are A (the The temperature grade for this tire is established for a ROTECTION TMOSPHERIC tire that is properly inflated and not overloaded. highest), B, and C, representing the tire's GENTS Excessive speed, underinflation, or excessive loading, resistance to the generation of heat and...
Page 436: Body And Underbody Maintenance
SERVICING AND MAINTENANCE Fascia/Bumper Care NDERBODY AINTENANCE RESERVING ODYWORK The customer is responsible to clean and maintain the Cleaning Headlights Washing chrome components of the vehicle. Washing away road Your vehicle is equipped with plastic headlights and fog  Wash your vehicle regularly. Always wash your vehicle debris and salt using an automotive soap.
Page 437: Interiors
SERVICING AND MAINTENANCE Special Care To help maintain the appearance of your Spray-On Repairing The Spray-On Bedliner Bedliner, the manufacturer recommends you periodically While extremely tough, it is possible to damage a Spray-On  If you drive on salted or dusty roads or if you drive near rinse all loose dirt from your truck bed and clean your truck Bedliner.
Page 438: Plastic And Coated Parts
SERVICING AND MAINTENANCE Stain Repel Fabric Cleaning Procedure — Sun damage can also weaken the fabric. Replace the belts LASTIC OATED ARTS if they appear frayed or worn or if the buckles do not work If Equipped properly. Use Mopar® Total Clean to clean vinyl upholstery. Stain Repel seats may be cleaned in the following manner: NOTE: CAUTION!
Page 439: Leather Surfaces
SERVICING AND MAINTENANCE NOTE: EATHER URFACES LASS URFACES If equipped with light colored leather, it tends to show any Mopar® Total Clean is specifically recommended for All glass surfaces should be cleaned on a regular basis foreign material, dirt, and fabric dye transfer more so than leather upholstery.
Page 440: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) BRAKE SYSTEM WHEEL AND TIRE TORQUE SPECIFICATIONS The VIN is found on the left front corner of the instrument If power assist is lost for any reason (for example, Proper lug nut/bolt torque is very important to ensure that panel, visible through the windshield.
Page 441 TECHNICAL SPECIFICATIONS NOTE: Dual wheels are flat mounted, center piloted. The lug nuts are a two-piece assembly. When the tires are being rotated or replaced, clean these lug nuts at the interface between the lug nut/bolt and the washer. Do not oil wheel studs.
Page 442: Fuel Requirements - Gasoline Engine
TECHNICAL SPECIFICATIONS All wheel nuts should be tightened occasionally to Poor quality gasoline can cause problems such as hard ATERIALS DDED eliminate the possibility of wheel studs being sheared or starting, stalling, and hesitations. If you experience these the bolt holes in the wheels becoming elongated. This is symptoms, try another brand of gasoline before Besides using unleaded gasoline with the proper octane especially important during the first few hundred miles/...
Page 443: Gasoline/Oxygenate Blends
TECHNICAL SPECIFICATIONS  Poor engine performance. ASOLINE XYGENATE LENDS YSTEM AUTIONS  Poor cold start and cold drivability. Some fuel suppliers blend unleaded gasoline with CAUTION!  Increased risk for fuel system component corrosion. oxygenates such as ethanol. CNG A LP F Follow these guidelines to maintain your vehicle’s YSTEM...
Page 444: Fuel Requirements - Diesel Engine
TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS – DIESEL ENGINE Diesel fuel is seldom completely free of water. To prevent NOTE: fuel system trouble, drain the accumulated water from the  If you accidentally fill the fuel tank with gasoline on your fuel/water separator using the fuel/water separator drain Use good quality diesel fuel from a reputable supplier in diesel vehicle, do not start the vehicle.
Page 445: Biodiesel Fuel Requirements
Fuel Water Separation — Must Use Ram PickUp 2500/3500 Only — 15,000 miles requirements. Failure to comply with Oil Change (24,000 km)* Mopar®/Cummins® Approved Fuel Filter requirements for vehicles operating on biodiesel blends up to B20 will result in premature engine wear.
Page 446: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES 6.4L GASOLINE ENGINE Metric Fuel (Approximate) 2500/3500 Shortbed Models 31 gal 117 L 2500/3500 Longbed Models 32 gal 121 L 2500/3500 Crew Cab Longbed Models — If Equipped 50 gal 189 L Engine Oil With Filter 6.4L Engine 7 qt 6.6 L...
Page 447 TECHNICAL SPECIFICATIONS 6.7L DIESEL ENGINE Metric Fuel (Approximate) 2500/3500 Standard Cab Longbed Models 28 gal 106 L 2500/3500 Crew/Mega Cab Shortbed Models 31 gal 117 L 2500/3500 Crew Cab Longbed Models 32 gal 121 L 2500/3500 Crew Cab Longbed Models — If Equipped 50 gal 189 L Diesel Exhaust Fluid Tank...
Page 448: Engine Fluids And Lubricants
TECHNICAL SPECIFICATIONS ENGINE FLUIDS AND LUBRICANTS 6.4L GASOLINE ENGINE Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile (240,000 km) Formula OAT (Organic Additive Engine Coolant Technology). We recommend using Mopar® API Certified SAE 0W-40 Full Synthetic Engine Oil which meets the requirements of the manufacturer Material Standard MS-A0921.
Page 449 Use of fluids not API Certified to ISO 22241 may result in system damage. You can receive assistance in locating DEF in Diesel Exhaust Fluid the United States by calling 866-RAM-INFO (866-726-4636). In Canada call 1–800–465–2001 (English) or 1–800–387–9983 (French).
Page 450: Chassis Fluids And Lubricants
We recommend using Mopar® BW44–44 Transfer Case Fluid. We recommend using SAE 75W-85 HD Ram GL-5 Synthetic Axle Lubricant in 9.25 Front, 11.5 and 12.0 (Single Rear Wheel) Rear Axles. Use Mopar® GL-5 Synthetic Gear Lubricant SAE 75W-140 in 12.0 (Dual Rear Wheel) Rear axles.
Page 451: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE IF YOU NEED ASSISTANCE Any communication to FCA US LLC’s customer center should include the following information: FOR YOUR VEHICLE FCA US LLC and its authorized dealers are vitally  Owner's name and address interested in your satisfaction.
Page 452 Chrysler, Dodge, Jeep®, or Ram dealer. If you choose to go to another dealer, you will be responsible for the cost if the extra distance exceeds...
Page 453: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE FCA US LLC C FCA US LLC is not responsible for any service contract you USTOMER ENTER USTOMER SSISTANCE may have purchased from another manufacturer. If you EARING PEECH MPAIRED P.O. Box 21–8004 require service after the FCA US LLC New Vehicle Limited (TDD/TTY) Warranty expires, please refer to the contract documents, Auburn Hills, MI 48321–8004...
Page 454: Warranty Information
CUSTOMER ASSISTANCE WARRANTY INFORMATION REPORTING SAFETY DEFECTS To contact NHTSA, you may call the Vehicle Safety Hotline toll free at See the Warranty Information for the terms and provisions 50 U NITED TATES 1-888-327-4236 (TTY: of FCA US LLC warranties applicable to this vehicle and , D.C.
Page 455: Publication Order Forms
CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Owner's Manuals Le présent appareil est conforme aux CNR d`Innovation, Science and Economic Development applicables aux These Owner's Manuals have been prepared with the appareils radio exempts de licence. L'exploitation est To order the following manuals, you may use either the assistance of service and engineering specialists to autorisée aux deux conditions suivantes: website or the phone numbers listed below.
Page 456: Change Of Ownership Or Address
CUSTOMER ASSISTANCE CHANGE OF OWNERSHIP OR ADDRESS GENERAL INFORMATION La operación de este equipo está sujeta a las siguientes dos condiciones: *If you have purchased this vehicle used or have changed The following regulatory statement applies to all Radio es posible que este equipo o dispositivo no cause your address, please provide the following information Frequency (RF) devices equipped in this vehicle: interferencia perjudicial y...
Page 457 INDEX Air Conditioner Maintenance ........384 Automatic Transmission ........141 Air Conditioner Refrigerant ..........384 Adding Fluid............. 399 Adaptive Cruise Control (ACC) Air Conditioner System ..........384 Fluid And Filter Change........... 399 (Cruise Control) ........... 174 Air Conditioning............... 59 Fluid Change ............399 Adding Engine Coolant (Antifreeze) ......395 Air Conditioning Filter ..........62 Fluid Level Check ...........397 Adding Fuel............
Page 458 Bluetooth Cargo Light ..............52 Cooling System ............. 394 Connecting To A Particular Mobile Phone Or CD ..................261 Adding Coolant (Antifreeze)........395 Audio Device After Pairing ........ 266 Cellular Phone...............288 Coolant Level..........394 Body Builders Guide ............10 Center High Mounted Stop Light .........414 Cooling Capacity............
Page 459 Disabled Vehicle Towing..........366 Emergency, In Case Of Exhaust Brake .............. 139 Disc Drive..............261 Freeing Vehicle When Stuck........365 Exhaust Gas Cautions ..........348 Disconnecting............... 266 Hazard Warning Flasher .........349 Exhaust System ......... 348 Disposal Jump Starting............361 Exterior Lighting.............. 49 Antifreeze (Engine Coolant) ........
Page 460 Four-Way Hazard Flasher ..........349 Getting Started .............273 Hood Prop ............... 75 Freeing A Stuck Vehicle ..........365 Glass Cleaning ..............437 Hood Release ..............75 Front And Rear ParkSense System......183 Gross Axle Weight Rating ..........205 Hub Caps ..............360 Front Axle (Differential)..........
Page 461 Cruise ............. 122 Limited-Slip Differential ........166 Daytime Running............50 Load Shed Battery Saver Mode........114 Key Fob ECO................122 Load Shed Battery Saver On ........114 Panic Alarm ..............18 Electronic Stability Program (ESP) Indicator..116 Load Shed Electrical Load Reduction......114 Programming Additional Key Fobs ......19 Exterior ..............49 Load Shed Intelligent Battery Sensor ......
Page 462 Midline instrument Cluster — Gas Engine ....93 Oil Filter, Selection............382 Passive Entry ..............26 Mirror, Digital Rearview ..........39 Oil Life Reset ............107 Pedals, Adjustable............38 Mirror, Digital Trailer Camera.........39 Oil Pressure Light............117 Pedestrian Warning System ........308 Mirrors ................38 Oil Reset ................107 Pets ................
Page 463 Pretensioners Release, Hood..............75 Saved Radio Stations........... 259 Seat Belts..............322 Release, Tailgate ............76 Schedule, Maintenance..........369 Profile Settings ............. 228 Reminder, Seat Belt .............316 Seat Belt Reminder ............117 Programmable Features..........226 Remote Features, Door Lock/Unlock....278 Seat Belts.............316 Remote Features, Horn And Lights ......279 Adjustable Shoulder Belt ........
Page 464 Security Alarm ............24 Speed Control Surround View Camera ..........191 Selection Of Coolant (Antifreeze)........ 446 Accel/Decel..............175 Sway Control, Trailer ............ 301 Send & Go ............280 Cancel ..............175 Synthetic Engine Oil ............. 382 Sentry Key (Immobilizer)..........20 Resume ..............175 Service Assistance ............449 Speed Control (Cruise Control) ......
Page 465 Rotation ..............430 Trailer Towing Guide.............208 Help Command ............265 Safety.............. 416 Trailer Weight..............208 Join Calls..............270 Sizes ................ 417 Transfer Case..............400 Making A Phone Or Audio Device A Favorite..267 Snow Tires............... 425 Electronically Shifted........148 Making A Second Call While Current Call Is Spare Tires ..........425 Fluid................448 In Progress ............
Page 466 Wind Buffeting..............74 Window Fogging ............. 62 Vehicle Finder............280 Warning Lights (Instrument Cluster Descriptions) ..118 Windows................72 Vehicle Health Alert ............. 282 Warranty Information ...........452 Power ................. 72 Vehicle Health Report ..........282 Washers, Windshield............380 Rear Sliding ............... 74 Vehicle Identification Number (VIN) ......
Page 467 This Owner’s Manual has been prepared to help you get acquainted with your new Ram brand vehicle and to provide a convenient reference for common questions. Not all features shown in this manual may apply to your vehicle. For additional information on accessories to help personalize your vehicle, visit mopar.com/om (USA), owners.mopar.ca (Canada) or your local Ram brand dealer.
Page 468 ©2022 FCA US LLC. All Rights Reserved. Tous droits réservés. Ram is a registered trademark of FCA US LLC. SECOND EDITION V1 Ram est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google. 23_DJD2_OM_EN_USC...

This manual is also suitable for:

3500 2023

RAM 2500 2023 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RAM 2500 2023

Summary of Contents for RAM 2500 2023
