Summary of Contents for RAM 3500 2019

Page 1 2 0 1 9 R A M 2 5 0 0 / 3 5 0 0 O W N E R ’ S M A N U A L...
Page 2 This manual illustrates and describes the operation VEHICLES SOLD IN CANADA of features and equipment that are either standard or With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the optional on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........................9 GETTING TO KNOW YOUR VEHICLE ..................12 GETTING TO KNOW YOUR INSTRUMENT PANEL ............. 104 SAFETY............................128 STARTING AND OPERATING ....................193 IN CASE OF EMERGENCY ....................295 SERVICING AND MAINTENANCE ..................337 TECHNICAL SPECIFICATIONS .................... 385 MULTIMEDIA ..........................394 CUSTOMER ASSISTANCE .....................467 INDEX ..............................
Page 4 INTRODUCTION HEAD RESTRAINTS..........35 SENTRY KEY............21 Key Programming ........21 Front Head Restraints ......... 35 INTRODUCTION ............9 Replacement Keys ........21 Rear Head Restraint Adjustment ....36 HOW TO USE THIS MANUAL .......11 General Information ........22 Rear Head Restraint Removal ....37 Essential Information ........
Page 5 INTERNAL EQUIPMENT ........76 EXTERIOR LIGHTS ..........44 CLIMATE CONTROLS ........... 52 Multifunction Lever........44 Climate Controls Without A Touchscreen Storage............76 Headlight Switch .......... 44 Overview ............52 Cupholders ..........82 Daytime Running Lights (DRL) — Climate Controls With A Touchscreen Electrical Power Outlets ......
Page 6 GETTING TO KNOW YOUR INSTRUMENT PANEL SAFETY STARTING AND OPERATING BASE / MIDLINE INSTRUMENT CLUSTER..104 SAFETY FEATURES..........128 STARTING THE ENGINE ........193 Base / Midline Instrument Cluster Anti-Lock Brake System (ABS) ....128 Automatic Transmission......193 Descriptions ..........105 Electronic Brake Control System .....129 Tip Start Feature ........193 PREMIUM INSTRUMENT CLUSTER ....
Page 7 To Turn Off ..........243 AIR SUSPENSION SYSTEM (2500/3500 WINCH USAGE — POWER WAGON ONLY (IF To Resume ..........243 MODELS) — IF EQUIPPED ......... 212 EQUIPPED) ............227 To Vary The Speed Setting ......243 Description ..........212 Things To Know Before Using Setting The Following Distance In ACC ..
Page 8 IN CASE OF EMERGENCY PARKSENSE FRONT AND REAR TRAILER TOWING ..........274 PARK ASSIST ............. 257 Common Towing Definitions .....274 HAZARD WARNING FLASHERS ...... 295 Trailer Hitch Type and Maximum Trailer ParkSense Sensors ........258 ASSIST AND SOS SYSTEM — IF EQUIPPED ..295 Weight ............278 ParkSense Warning Display ......258 BULB REPLACEMENT ........
Page 9 INTERIORS ............383 FREEING A STUCK VEHICLE ......332 Windshield Wiper Blades ......350 Exhaust System ........352 TOWING A DISABLED VEHICLE ....... 333 Seats And Fabric Parts......383 Cooling System .........353 Plastic And Coated Parts......384 Two-Wheel Drive Models ......335 Brake System ..........356 Leather Parts ..........384 Four-Wheel Drive Models ......335 Automatic Transmission......357...
Page 10 FLUID CAPACITIES..........390 Phone ............456 IF YOU NEED ASSISTANCE ......467 Voice Text Reply — If Equipped ....457 FLUIDS AND LUBRICANTS ....... 391 FCA US LLC Customer Center ....468 Climate (4C/4C NAV).........458 FCA Canada Inc. Customer Center ... 468 Engine ............391 Navigation (4C NAV) ........459 In Mexico Contact ........468 Chassis ............393...
Page 11: Introduction
INTRODUCTION Dear Customer, congratulations on selecting your new vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. This is a specialized utility vehicle. It can go places and perform tasks that are not intended for conventional passenger vehicles. It handles and maneuvers differently from many passenger vehicles both on-road and off-road, so take time to become familiar with your vehicle.
Page 12: How To Use This Manual
This Owner’s Manual describes all versions of this vehicle. Options and equipment dedicated to specific markets or versions are not expressly indicated in the text. Therefore, you should only consider the information which is related to the trim level, engine, and version that you have purchased. Any content introduced throughout the Owner’s Information, that may or may not be applicable to your vehicle, will be identified with the wording “If Equipped”.
Page 13: Warnings And Cautions
WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against operating procedures that could result in a collision, bodily injury and/or death. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information.
Page 14: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE VEHICLE USER GUIDE — IF EQUIPPED NOTE: playback. Plus, it’s updated throughout the Vehicle User Guide features are not available while year, in real-time, so it never goes out of date. Access your Owner’s Information right through the vehicle is moving.
Page 15: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE KEYS To Unlock The Doors And Tailgate Push and release the unlock button on the key Key Fob fob once to unlock the driver’s door. Push the unlock button twice within five seconds to Your vehicle uses a keyless ignition system. The unlock all doors, the tailgate and the RamBox (if ignition system consists of a key fob with equipped).
Page 16 GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: The following conditions must be met for the Pushing the lock button on the key fob while you vehicle to lower remotely: The interior lights will turn off if you place the  are in the vehicle will activate the vehicle secu- The vehicle must not already be in Entry/Exit ...
Page 17 GETTING TO KNOW YOUR VEHICLE Replacing The Battery In The Key Fob With 1. Remove the emergency key by pushing 2. Slightly remove the emergency key from the and holding the release button located on key fob, approximately 10 mm. The blade of Remote Control the side of the key fob while pulling the the emergency key should just become...
Page 18 GETTING TO KNOW YOUR VEHICLE 3. Holding the key fob with the button side NOTE: NOTE: facing down, use the emergency key to pry When replacing the battery, ensure the + sign The key fob battery should only be replaced by up the battery cover until the cover releases on the battery is facing upward.
Page 19: Ignition Switch
GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH Programming Additional Key Fobs Programming the key fob may be performed by Keyless Push Button Ignition an authorized dealer. This feature allows the driver to operate the NOTE: ignition switch with the push of a button as long Once a key fob is programmed to a vehicle, it as the Remote Keyless Entry key fob is in the cannot be repurposed and reprogrammed to...
Page 20 GETTING TO KNOW YOUR VEHICLE WARNING! (Continued) Driving position.  Do not leave children or animals inside  All the electrical devices are available.  parked vehicles in hot weather. Interior heat build-up may cause serious injury or START death. The engine will start.
Page 21: Remote Start - If Equipped
GETTING TO KNOW YOUR VEHICLE REMOTE START — IF EQUIPPED To Enter Remote Start Mode WARNING! Push and release the Remote Start How To Use Remote Start Do not start or run an engine in a closed  button on the key fob twice within five garage or confined area.
Page 22: To Exit Remote Start Mode Without Driving The Vehicle
GETTING TO KNOW YOUR VEHICLE To Exit Remote Start Mode Without Driving Remote Start Comfort Systems — If General Information The Vehicle Equipped The following regulatory statement applies to all radio frequency (RF) devices equipped in this Push and release the remote start button one When Remote Start is activated, the heated vehicle: time or allow the engine to run for the entire...
Page 23: Sentry Key
GETTING TO KNOW YOUR VEHICLE SENTRY KEY If the vehicle security light turns on during Replacement Keys normal vehicle operation (vehicle running for NOTE: The Sentry Key Immobilizer system prevents longer than ten seconds), it indicates that there Only key fobs that are programmed to the unauthorized vehicle operation by disabling the is a fault in the electronics.
Page 24: General Information
GETTING TO KNOW YOUR VEHICLE General Information 29 seconds, 5 seconds between cycles, up to 8 3. If any doors are open, close them. cycles if the trigger remains active and then the The following regulatory statement applies to all The vehicle security alarm will set when you use vehicle security alarm will rearm itself.
Page 25: Rearming Of The System
GETTING TO KNOW YOUR VEHICLE DOORS The vehicle security alarm is designed to protect WARNING! your vehicle. However, you can create Manual Door Locks conditions where the system will give you a false Do not leave children or animals inside ...
Page 26: Power Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE touchscreen. When configured for “Store” WARNING! (Continued) mode, the steps will stay in their position but can also be deployed manually through the Allowing children to be in a vehicle unat-  tended is dangerous for a number of radio.
Page 27 GETTING TO KNOW YOUR VEHICLE If the vehicle is unlocked by Passive Entry NOTE:  and no door is opened within 60 seconds, the All doors will unlock when the front passenger vehicle will re-lock and if equipped will arm door handle is grabbed regardless of the driver’s the security alarm.
Page 28 GETTING TO KNOW YOUR VEHICLE To Lock The Vehicle’s Doors: The Passive Entry system depends on a key  fob that is not fully discharged of its coin With one of the vehicle’s Passive Entry key fobs battery capacity. within 5 ft (1.5 m) of the driver or passenger front door handles, push the door handle lock The LED light on the key fob will not blink if ...
Page 29: Automatic Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE General Information Automatic Door Locks — If Equipped Automatic Doors Unlock Programming — If Equipped The following regulatory statement applies to all The auto door lock feature default condition is radio frequency (RF) devices equipped in this The Automatic Doors Unlock feature can be enabled.
Page 30: Child-Protection Door Lock
GETTING TO KNOW YOUR VEHICLE SEATS Child-Protection Door Lock To provide a safer environment for children Seats are a part of the Occupant Restraint riding in the rear seat, the rear doors (if System of the vehicle. equipped) of your vehicle have the WARNING! Child-Protection Door Lock system.
Page 31: Manual Rear Seat Adjustment
GETTING TO KNOW YOUR VEHICLE Manual Front Seat Recline Adjustment WARNING! (Continued) The recline lever is located on the outboard side To avoid injury, place your hand on the seat-  of the seat. To recline the seat, lean forward back and actuate the handle, then position slightly, lift the lever, lean back to the desired the seatback in the desired position.
Page 32: Power Driver Seat Adjustment - If Equipped
GETTING TO KNOW YOUR VEHICLE Reclining Rear Seats — If Equipped Power Driver Seat Adjustment — If Equipped Adjusting The Seat Forward Or Rearward The recliner handle is located on the outside of The seat can be adjusted both forward and Some models may be equipped with an the seat cushion.
Page 33: Driver Memory Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE Reclining The Seatback Driver Memory Seats — If Equipped CAUTION! The angle of the seatback can be adjusted This feature allows the driver to store up to two Do not place any article under a power seat forward or rearward.
Page 34 GETTING TO KNOW YOUR VEHICLE Programming The Memory Feature Linking And Unlinking The Remote Keyless 4. Push and release button (1) or (2) Entry Key Fob To Memory accordingly. “Memory Profile Set” (1 or 2) To create a new memory profile, perform the will display in the instrument cluster.
Page 35: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE Driver Two Memory Position Recall stop. The seat will return to its previously set Heated Seats — If Equipped position when you place the ignition into the To recall the memory setting for driver two ...
Page 36 GETTING TO KNOW YOUR VEHICLE Front Heated Seats Vehicles Equipped With Remote Start There are two heated seat switches that allow the rear passengers to operate the seats On models that are equipped with remote start, The heated seats control buttons are located on independently.
Page 37: Ventilated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE Ventilated Seats — If Equipped NOTE: WARNING! (Continued) The engine must be running for the ventilated Front Ventilated Seats seats to operate. Head restraints should never be adjusted  Located in the seat cushion are small fans that while the vehicle is in motion.
Page 38: Rear Head Restraint Adjustment
GETTING TO KNOW YOUR VEHICLE rearward, pull the top of the head restraint to the NOTE: forward most position and release. The head The head restraints should only be removed by restraint will return to the rear most position. qualified technicians, for service purposes only. If either of the head restraints require removal, NOTE: see an authorized dealer.
Page 39: Rear Head Restraint Removal
GETTING TO KNOW YOUR VEHICLE STEERING WHEEL Rear Head Restraint Removal WARNING! To remove the head restraint, push the Tilt Steering Column Do not adjust the steering column while adjustment button and the release button while driving. Adjusting the steering column while This feature allows you to tilt the steering pulling upward on the whole assembly.
Page 40: Driver Adjustable Pedals - If Equipped
GETTING TO KNOW YOUR VEHICLE DRIVER ADJUSTABLE PEDALS — IF NOTE: The pedals can be adjusted with the ignition  OFF. The engine must be running for the heated EQUIPPED steering wheel to operate. The pedals cannot be adjusted when the ...
Page 41: Mirrors
GETTING TO KNOW YOUR VEHICLE the vehicle). The mirror should be adjusted NOTE: WARNING! while set in the day position (toward the The Automatic Dimming feature is disabled Do not adjust the pedals while the vehicle is windshield). when the vehicle is in REVERSE to improve rear moving.
Page 42: Automatic Dimming Mirror With Rear View
GETTING TO KNOW YOUR VEHICLE Automatic Dimming Mirror With Rear View WARNING! Camera Display — If Equipped Vehicles and other objects seen in the A single ball joint mirror is provided in the vehicle. It passenger side convex mirror will look smaller is a twist on mirror that has a fixed position at the and farther away than they really are.
Page 43: Power Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE Power Mirrors — If Equipped To adjust the convex portion of the outside mirrors, push the Power Convex Mirror Switch. The controls for the power mirrors are located Then, select the mirror you want to adjust by on the driver's door trim panel.
Page 44: If Equipped
GETTING TO KNOW YOUR VEHICLE Trailer Towing Mirrors — If Equipped mirrors will then return to the original position when the vehicle is shifted out of the REVERSE These mirrors are designed with an adjustable position. Each stored memory setting will have mirror head to provide a greater vision range an associated Tilt Side Mirrors In Reverse when towing extra-wide loads.
Page 45 GETTING TO KNOW YOUR VEHICLE If the mirror is manually folded after electrically The mirrors come out of the unfolded position. Outside Mirrors Folding Feature  cycled, a potential extra button push is required All outside mirrors are designed to be able to be The mirrors shake and vibrate at normal ...
Page 46: Illuminated Vanity Mirror - If Equipped
GETTING TO KNOW YOUR VEHICLE Illuminated Vanity Mirror — If Equipped Headlight Switch Illuminated vanity mirrors are located on each The headlight switch is located on the left side sun visor. To use the mirror, rotate the sun visor of the instrument panel. This switch controls the down and swing the mirror cover upward.
Page 47: Daytime Running Lights (Drl)
GETTING TO KNOW YOUR VEHICLE Daytime Running Lights (DRL) — If Equipped Automatic High Beam Headlamp Control — If the windshield or Automatic High Beam Headlamp Control mirror is replaced, the mirror If Equipped The headlights on your vehicle will illuminate must be re-aimed to ensure proper when the engine is started and the The Automatic High Beam Headlamp Control...
Page 48: Flash-To-Pass
GETTING TO KNOW YOUR VEHICLE To Deactivate Delay feature is also on. This means your NOTE: headlights will stay on for up to 90 seconds This feature can be programmed through the 1. Pull the multifunction lever toward you (or after you turn the ignition switch OFF.
Page 49: Front Fog Lights - If Equipped
GETTING TO KNOW YOUR VEHICLE Front Fog Lights — If Equipped light when the lever is moved, it would suggest If the vehicle’s speed is 0 mph (0 km/h), these that the indicator bulb is defective. lights can also be turned on using the switch To activate the front fog lights, turn on the located just inside the pickup box, on the lower parking lights or low beam headlights and push...
Page 50: Battery Saver
GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: Courtesy/Reading Lights For vehicles shipped to or sold in the states of Battery saver mode is canceled if the ignition is The overhead console lights can also be California or Mississippi, the Cargo, Bed, and operated individually as reading lights by Mirror Spotter lights will not work while the pushing the corresponding buttons.
Page 51: Illuminated Entry
GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: With the parking lights or headlights on, rotating On vehicles equipped with an LED overhead The Rear Courtesy/Reading Lights will remain the right dimmer control upward will increase console, if both the Dome On and Dome Defeat on until the switch is pushed a second time, so the brightness of the instrument panel lights.
Page 52: Windshield Wipers And Washers
GETTING TO KNOW YOUR VEHICLE The illuminated entry system will not operate if Rotate the end of the lever upward, to the first will be sprayed and the wiper will operate for the Dome Defeat button on the overhead detent past the intermittent settings for two to three cycles after the washer knob is console is pushed.
Page 53: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE Mist Feature NOTE: The Rain Sensing system has protection This feature can be programmed through the features for the wiper blades and arms, and will When a single wipe to clear off road mist or Uconnect system.
Page 54: Climate Controls
GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Climate Controls Without A Touchscreen Overview The Climate Control System allows you to The controls for the manual heating and air regulate the temperature, air flow, and direction conditioning system in this vehicle consist of a of air circulating throughout the vehicle.
Page 55 GETTING TO KNOW YOUR VEHICLE Icon Description Temperature Control Use this control knob to regulate the temperature of the air inside the passenger compartment. Rotating the knob counterclockwise, from top center into the blue area of the scale, indicates cooler temperatures. Rotating the knob clockwise, into the red area, indicates warmer temperatures.
Page 56 GETTING TO KNOW YOUR VEHICLE Icon Description Floor Mode Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.
Page 57: Climate Controls With A Touchscreen Overview
GETTING TO KNOW YOUR VEHICLE Climate Controls With A Touchscreen Overview Uconnect 4/4C/4C NAV With 8.4–inch Display Automatic Temperature Controls...
Page 58 GETTING TO KNOW YOUR VEHICLE Uconnect 4C NAV With 12–inch Display Automatic Temperature Controls...
Page 59 GETTING TO KNOW YOUR VEHICLE Control Descriptions NOTE: Icons and descriptions can vary based upon vehicle equipment. Icon Description MAX A/C Press and release to change the current setting, the indicator illuminates when MAX A/C is on. Performing this function again will cause the MAX A/C operation to switch into manual mode and the MAX A/C indicator will turn off.
Page 60 GETTING TO KNOW YOUR VEHICLE Icon Description AUTO Control Knob AUTO Automatically controls the interior cabin temperature by adjusting airflow distribution and amount. Toggling this function AUTO Button will cause the system to switch between manual mode and automatic modes. Refer to “Automatic Operation”...
Page 61 GETTING TO KNOW YOUR VEHICLE Icon Description Driver and Passenger Temperature Up and Down Buttons Provides the driver and passenger with independent temperature control. Push the red button on the faceplate or touchscreen or press and slide the temperature bar towards the red arrow button on the touchscreen for warmer temperature settings.
Page 62 GETTING TO KNOW YOUR VEHICLE Icon Description Blower Control Blower Control is used to regulate the amount of air forced through the climate system. There are seven blower speeds Blower Control Knob available. Adjusting the blower will cause automatic mode to switch to manual operation. The speeds can be selected using either the blower control knob on the faceplate or the buttons on the touchscreen.
Page 63 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
Page 64: Climate Control Functions
GETTING TO KNOW YOUR VEHICLE Climate Control Functions If your air conditioning performance seems On systems with Manual Climate Controls, if  lower than expected, check the front of the equipped, the Recirculation mode is not A/C (Air Conditioning) A/C condenser (located in front of the radi- allowed in Defrost mode to improve window The Air Conditioning (A/C) button allows the ator), for an accumulation of dirt or insects.
Page 65: Operating Tips
GETTING TO KNOW YOUR VEHICLE NOTE: Operating Tips Vacation/Storage Before you store your vehicle, or keep it out of It is not necessary to move the temperature NOTE:  service (i.e., vacation) for two weeks or more, settings for cold or hot vehicles. The system Refer to the chart at the end of this section for run the air conditioning system at idle for about automatically adjusts the temperature,...
Page 66: Windows
GETTING TO KNOW YOUR VEHICLE WINDOWS Cabin Air Filter CAUTION! (Continued) The climate control system filters out dust and Power Windows Use care when washing the inside of the  pollen from the air. Contact an authorized rear window. Do not use abrasive window dealer to service your cabin air filter, and to Power Window Controls cleaners on the interior surface of the...
Page 67 GETTING TO KNOW YOUR VEHICLE NOTE: To stop the window from going all the way down trigger the auto reverse function unexpectedly The Key Off Power Delay feature will allow the during the Auto-Down operation, pull up on the during auto closure. If this happens, pull the power windows to operate for up to 10 minutes switch briefly.
Page 68: Wind Buffeting
GETTING TO KNOW YOUR VEHICLE Window Lockout Switch Power Sliding Rear Window — If Equipped Manual Sliding Rear Window — If Equipped The window lockout switch on the driver's door The switch for the power sliding rear window is A locking device in the center of the window allows you to disable the window control on the located on the overhead console.
Page 69: Power Sunroof - If Equipped
GETTING TO KNOW YOUR VEHICLE POWER SUNROOF — IF EQUIPPED Opening Sunroof WARNING! Express Single Pane Power Sunroof — If Equipped Never leave children unattended in a  Push the switch rearward and release it within vehicle, or with access to an unlocked The power sunroof switches are located on the one-half second.
Page 70 GETTING TO KNOW YOUR VEHICLE Closing Sunroof Wind Buffeting Pinch Protect Feature Express Wind buffeting can be described as the This feature will detect an obstruction in the perception of pressure on the ears or a closing of the sunroof during the Express Close Push the switch forward and release it within helicopter-type sound in the ears.
Page 71: Hood
GETTING TO KNOW YOUR VEHICLE HOOD Sunroof Maintenance 3. Push and hold the close switch. The sunroof will hit the hard stop and move to the vent Use only a non-abrasive cleaner and a soft cloth To Open The Hood position after ten seconds.
Page 72: To Close The Hood
GETTING TO KNOW YOUR VEHICLE 2. Reach into the opening beneath the center Electronic Tailgate Release — If Equipped WARNING! of the hood and push the safety latch lever The key fob may be equipped with an to the left to release it, before raising the Be sure the hood is fully latched before electronic release feature for the hood.
Page 73: Closing
GETTING TO KNOW YOUR VEHICLE Closing To close the tailgate, push it upward until both sides are latched. NOTE: Pull back on the tailgate firmly after closing to ensure it is securely latched. Bed Step — If Equipped Your vehicle may be equipped with an Bed Step Components Bed Step (Extended) extendable bed step on the driver’s side of the...
Page 74: Garage Door Opener - If Equipped
GETTING TO KNOW YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED NOTE: WARNING! Only use this transceiver with a garage door HomeLink replaces up to three hand-held Your motorized door or gate will open and opener that has a “stop and reverse” feature as ...
Page 75 GETTING TO KNOW YOUR VEHICLE NOTE: 4. Continue to hold both buttons and observe the indicator light. The HomeLink indicator Erasing all channels should only be  will flash slowly and then rapidly after performed when programming HomeLink for HomeLink has received the frequency the first time.
Page 76: Canadian/Gate Operator Programming
GETTING TO KNOW YOUR VEHICLE 6. Return to the vehicle and push the Programming A Non-Rolling Code To program the two remaining HomeLink  programmed HomeLink button twice buttons, repeat each step for each For programming Garage Door Openers (holding the button for two seconds each remaining button.
Page 77: Using Homelink
GETTING TO KNOW YOUR VEHICLE not be long enough for HomeLink to pick up the 4. Watch for the HomeLink indicator to change Reprogramming A Single HomeLink Button signal during programming. Similar to this flash rates. When it changes, it is (Canadian/Gate Operator) Canadian law, some U.S.
Page 78: Security
GETTING TO KNOW YOUR VEHICLE INTERNAL EQUIPMENT Security General Information It is advised to erase all channels before you sell The following regulatory statement applies to all Storage or turn in your vehicle. Radio Frequency (RF) devices equipped in this vehicle: Glove Compartment To do this, push and hold the two outside...
Page 79 GETTING TO KNOW YOUR VEHICLE If equipped with a covered upper glove Rear Door Storage — If Equipped Center Storage Compartment — If Equipped compartment, push the release button to open. Storage compartments are located in both the The center storage compartment is located To open the lower glove compartment, pull the driver and passenger rear door trim panels.
Page 80 GETTING TO KNOW YOUR VEHICLE WARNING! (Continued) In a collision, the latch may open if the total  weight of the items stored exceeds about 10 lbs (4.5 kg). These items could be thrown about endangering occupants of the vehicle. Items stored should not exceed a total of 10 lbs (4.5 kg).
Page 81 GETTING TO KNOW YOUR VEHICLE Push the release button at the front of the Front Bench Seat Storage — If Equipped There is a storage drawer located in the lower center cupholder bin to slide tray rearward for access of the instrument panel. It can be released by If your vehicle is equipped with a front bench of front lower storage bin, or forward to access pushing the access button above it.
Page 82 GETTING TO KNOW YOUR VEHICLE Seatback Storage Each storage bin also contains two hooks for securing cargo. These hooks should be used to Located in the back of both the driver and secure loads safely when the vehicle is moving. passenger front seats are pockets that can be used for storage.
Page 83 GETTING TO KNOW YOUR VEHICLE Storage Bin (Regular Cab) Unfolding The Load Floor/Crew Cab 3. Lift the front panel until the load floor unfolds into position. The storage bin is located behind the front 1. Lift the 60/40 seat cushion(s) to the seats and runs the length of the cab.
Page 84: Cupholders
GETTING TO KNOW YOUR VEHICLE Below Rear Seat Storage (Crew Cab) Cupholders WARNING! The Crew Cab models provide additional Front Seat Cupholders Do not drive with the load floor in the up storage under the rear seats. Lift the seats to For vehicles equipped with a center console, position.
Page 85: Electrical Power Outlets
GETTING TO KNOW YOUR VEHICLE Vehicles Equipped With 40/20/40 Seats Rear Cupholders — If Equipped Electrical Power Outlets The cupholders are located on the backside of Some vehicles are equipped with rear The auxiliary 12 Volt (13 Amp) power outlet can the center portion of the front seat (20).
Page 86 GETTING TO KNOW YOUR VEHICLE An auxiliary power outlet can be found in the tray on When the vehicle is turned off, be sure to CAUTION! top of the center stack. This power outlet only works unplug any equipment as to not drain the when the vehicle is in the ON/RUN or ACC position.
Page 87: Power Inverter - If Equipped
If equipped, a 115 Volt (400 Watts Maximum) Maximum) power inverter located on the rear of inverter may be located inside the ram box of the center console. This inverter can power your vehicle. The inverter can be turned on by...
Page 88: Wireless Charging Pad - If Equipped
GETTING TO KNOW YOUR VEHICLE If equipped, there may be a 115 Volt (400 Watts NOTE: Wireless Charging Pad — If Equipped Maximum) inverter located to the right of the The Power Inverter only turns on if the igni-  center stack, just below the climate controls.
Page 89: Overhead Sunglass Storage
GETTING TO KNOW YOUR VEHICLE PICKUP BOX Your mobile phone must be designed for Qi Overhead Sunglass Storage wireless charging. If the phone is not equipped At the front of the overhead console, a The pickup box has many features designed for with Qi wireless charging functionality, an compartment is provided for the storage of one utility and convenience.
Page 90: Cargo Camera - If Equipped
GETTING TO KNOW YOUR VEHICLE You can carry wide building materials (sheets of A touchscreen button to indicate the current WARNING! (Continued) plywood, etc.) by building a raised load floor. active camera image being displayed is made Place lumber across the box in the indentations Unrestrained cargo may be thrown forward available whenever the Cargo Camera image is ...
Page 91 GETTING TO KNOW YOUR VEHICLE adjusted. The centerline will adjust in response to Deactivation Turning Cargo Camera On Or Off — With steering angle inputs, and will not obstruct the Uconnect 4C/4C NAV The Dynamic Centerline feature will gooseneck receiver or an approaching trailer automatically be deactivated whenever the 1.
Page 92: Rambox - If Equipped
GETTING TO KNOW YOUR VEHICLE RAMBOX — IF EQUIPPED CAUTION! CAUTION! The RamBox system is an integrated pickup box Failure to follow the following items could Leaving the lid open for extended periods of storage and cargo management system cause damage to the vehicle: time could cause the vehicle battery to consisting of three features: discharge.
Page 93: Rambox Safety Warning
GETTING TO KNOW YOUR VEHICLE Cargo bins feature two removable drain plugs CAUTION! WARNING! (Continued) (to allow water to drain from bins). To remove plug, pull up on the edge. To install push plug Ensure cargo bin lids are closed and Do not allow children to have access to the ...
Page 94: Bed Divider - If Equipped
GETTING TO KNOW YOUR VEHICLE RamBox Storage Bin Cover Emergency Storage Position 2. With the side gates open, position the Release Lever — If Equipped divider fully forward in the bed against the The storage position for the bed divider is at the front panel.
Page 95 GETTING TO KNOW YOUR VEHICLE 4. Rotate the center handle horizontally to To install the bed divider into a divider position, 2. With the side gates open, position the secure the side gates in the closed position. perform the following: divider so the outboard ends align with the intended slots in the sides of the bed.
Page 96: Bed Rail Tie-Down System
GETTING TO KNOW YOUR VEHICLE 4. Rotate the center handle horizontally to NOTE: To move the cleat to any position on the rail, secure the side gates in the closed position. This feature is available for vehicles both turn the nut counterclockwise, approximately equipped, or not equipped, with a RamBox.
Page 97: Slide-In Campers
GETTING TO KNOW YOUR VEHICLE To remove the cleats from the utility rail, remove Disconnecting The Rear Camera And WARNING! the end cap screw located in the center of the end Remote Keyless Entry cap, using a #T30 Torx head driver. Remove the To avoid inhaling carbon monoxide, which is 1.
Page 98: Removing The Tailgate
GETTING TO KNOW YOUR VEHICLE 2. Remove the connector bracket from the sill 5. Connect the tailgate plug (provided in the NOTE: by pushing inward in the locking tab. glove compartment) to the tailgate wiring Make sure tailgate is supported when removing harness to ensure that the terminals do not support cables.
Page 99: Locking Tailgate
GETTING TO KNOW YOUR VEHICLE TRI-FOLD TONNEAU COVER — IF EQUIPPED NOTE: Tri-Fold Tonneau Cover Removal Do not carry the tailgate loose in the truck To remove the Tonneau Cover, follow the next Your vehicle may be equipped with a Tri-Fold pickup box.
Page 100 GETTING TO KNOW YOUR VEHICLE NOTE: 3. From the released position, send the CAUTION! If clamp wire is damaged replace immediately. clamps to the Stowed Position by pushing from the yellow bumper up. Listen for a Make sure the Tonneau Cover clamp and 2.
Page 101 GETTING TO KNOW YOUR VEHICLE NOTE: The vehicle cannot be driven when the Tonneau Cover is in this position. 5. Fold the rear and center panels up onto the front panel (Tri-Folded position). Incorrect Folding — Will Cause Damage Correct Folding — Hold Panels Together NOTE: Fold the panels gently.
Page 102: Tri-Fold Tonneau Cover Installation
GETTING TO KNOW YOUR VEHICLE 7. From the Released Position, send the Tri-Fold Tonneau Cover Installation clamps to the Stowed Position by pushing To install the Tonneau Cover follow the following from the yellow bumper up. Listen for a steps: “clicking”...
Page 103 3. Push clamp wires up and under the flange NOTE: NOTE: of the box (or flange of the Ram Box rail, if Once clamped, be sure the clamps are not The vehicle cannot be driven when the Tonneau equipped) to the semi clamped position.
Page 104 Stowed Position 9. Push clamp wires up and under the flange Incorrect Folding — Will Cause Damage of box (or flange of Ram Box rail, if equipped) to the semi clamped position. Fully Unfolded Position Correct Folding — Hold Panels Together...
Page 105: Tri-Fold Tonneau Cover Cleaning
GETTING TO KNOW YOUR VEHICLE 10. Push clamp handles upward to the clamped NOTE: position to properly engage the clamps. Once clamped, be sure the clamps are not partially clamped to the truck bed flange. CAUTION! It is the driver’s responsibility to ensure the Tonneau Cover is properly installed on the vehicle.
Page 106: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL BASE / MIDLINE INSTRUMENT CLUSTER Base / Midline Instrument Cluster...
Page 107: Base / Midline Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL Base / Midline Instrument Cluster normal driving conditions may indicate a The gauge pointer will likely indicate a higher  lubrication system malfunction. Imme- temperature when driving in hot weather, up Descriptions diate service should be obtained from an mountain grades, or when towing a trailer.
Page 108: Premium Instrument Cluster
GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER Premium Instrument Cluster...
Page 109: Premium Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Instrument Cluster Descriptions 5. Temperature Gauge CAUTION! The gauge pointer shows engine coolant  1. Tachometer temperature. The pointer positioned Driving with a hot engine cooling system could Indicates the engine speed in revolutions ...
Page 110: Instrument Cluster Display
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY Instrument Cluster Display Controls The instrument cluster display features a Your vehicle will be equipped with an driver-interactive display that is located in the instrument cluster display, which offers useful instrument cluster. information to the driver.
Page 111: Oil Life Reset
GETTING TO KNOW YOUR INSTRUMENT PANEL Trailer Tow main menu items, submenu screen, and has sounded, to indicate the next scheduled oil  vehicle settings. change interval. The engine oil change indicator Audio  system is duty cycle based, which means the Down Arrow Button ...
Page 112: Display Menu Items
GETTING TO KNOW YOUR INSTRUMENT PANEL right arrow button to reset the Oil Life to NOTE: submenus items of Vehicle Info. Follow the 100%. If the indicator message illuminates when you directional prompts to access or reset any of the start the vehicle, the oil change indicator following Vehicle Info submenu items: 6.
Page 113 GETTING TO KNOW YOUR INSTRUMENT PANEL Driver Assist — If Equipped ACC SET Fuel Economy When ACC is set, the set speed will display in The Driver Assist menu displays the status of Push and release the up or down arrow button the instrument cluster.
Page 114 GETTING TO KNOW YOUR INSTRUMENT PANEL Trailer Tow Phone Call Status is displayed in the instrument cluster as well as the location that information is displayed. When a call is incoming, a Phone Call Status Push and release the up or down arrow button pop-up will display on the screen.
Page 115 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Transmission Temperature — If Equipped Upper Right  Menus with (Show/Hide) can push the OK None  Oil Life — If Equipped  button to choose whether to show or hide this Compass — If Equipped ...
Page 116 GETTING TO KNOW YOUR INSTRUMENT PANEL Turbo Boost — If Equipped Oil Temperature Oil Temperature    Fuel Filter Life — If Equipped Transmission Temperature Battery Voltage (Default Setting)    Left Side — If Equipped Oil Life Transmission Temperature ...
Page 117: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Trip B Distance Commercial Settings — If Equipped Battery Saver On/Battery Saver Mode  Message — Electrical Load Reduction Commercial Settings allows the driver to set Trailer Trip  Actions — If Equipped and recall additional features when the Trailer Brake ...
Page 118 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: the capability of charging system. The What to do when an electrical load reduction charging system is still functioning properly. action message is present (“Battery Saver On” The charging system is independent from ...
Page 119: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES Control (ESC) system. In this case, the light will — Air Bag Warning Light remain on until the condition has been This warning light will illuminate to indicate a The warning/indicator lights will illuminate in corrected.
Page 120 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: temperature reaches the upper limit, a WARNING! This light shows only that the parking brake is continuous chime will sound for four minutes or Driving a vehicle with the red brake light on is applied.
Page 121 GETTING TO KNOW YOUR INSTRUMENT PANEL placed in the PARK position. The light should — Oil Pressure Warning Light WARNING! turn off. If the light remains on with the vehicle This warning light will illuminate to indicate low running, your vehicle will usually be drivable; Continued operation with reduced assist engine oil pressure.
Page 122: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Yellow Warning Lights Certain conditions, such as a loose or missing WARNING! gas cap, poor quality fuel, etc., may illuminate — Adaptive Cruise Control (ACC) Fault If you continue operating the vehicle when the light after engine start. The vehicle should Warning Light —...
Page 123 GETTING TO KNOW YOUR INSTRUMENT PANEL The “ESC Off Indicator Light” and the “ESC — Low Fuel Warning Light  CAUTION! Indicator Light” come on momentarily each When the fuel level reaches approximately 3.2 gal time the ignition is placed in the ON/RUN or Prolonged driving with the Malfunction (12 L) this light will turn on, and remain on until ACC/ON/RUN position.
Page 124 GETTING TO KNOW YOUR INSTRUMENT PANEL under-inflated tire causes the tire to overheat TPMS malfunction telltale after replacing one or CAUTION! and can lead to tire failure. Under-inflation also more tires or wheels on your vehicle to ensure Do not continue driving with one or more flat reduces fuel efficiency and tire tread life, and that the replacement or alternate tires and tires as handling may be compromised.
Page 125: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL RUN position and may stay on for as long as four — Service 4WD Warning Light — If — Air Suspension Payload Protection seconds. Equipped Indicator Light — If Equipped If the ABS light remains on or turns on while This warning light will illuminate to signal a fault This indicator light will illuminate to indicate driving, then the Anti-Lock portion of the brake...
Page 126: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL — Air Suspension Alternate Trailer — Rear Axle Lock Indicator Light — 4WD High Indicator Light — If Equipped Height Indicator Light— If Equipped This light indicates when the rear axle lock has This light alerts the driver that the vehicle is in been activated.
Page 127: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: — Adaptive Cruise Control (ACC) Set With — Cruise Control Ready Indicator No Target Detected Indicator Light — If This indicator light will illuminate when the cruise A continuous chime will sound if the vehicle is ...
Page 128: Onboard Diagnostic System - Obd Ii
GETTING TO KNOW YOUR INSTRUMENT PANEL ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! WARNING! Your vehicle is equipped with a sophisticated Prolonged driving with the MIL on could ONLY an authorized service technician   Onboard Diagnostic system called OBD II. This cause further damage to the emission should connect equipment to the OBD II system monitors the performance of the...
Page 129: Programs
GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND Your vehicle has a simple ignition actuated test, The MIL will not flash at all and will  which you can use prior to going to the test remain fully illuminated until you place MAINTENANCE PROGRAMS the ignition in the off position or start the station.
Page 130: Safety
SAFETY SAFETY FEATURES You also may experience the following when WARNING! (Continued) ABS activates: Anti-Lock Brake System (ABS) Pumping of the Anti-Lock Brakes will diminish The ABS motor noise (it may continue to run   their effectiveness and may lead to a colli- for a short time after the stop).
Page 131: Electronic Brake Control System
SAFETY ABS is designed to function with the OEM tires. Electronic Brake Control System mode and may stay on for as long as four Modification may result in degraded ABS seconds. Your vehicle is equipped with an advanced performance. If the “Brake System Warning Light” remains on Electronic Brake Control system (EBC).
Page 132 SAFETY The following conditions must be met in order WARNING! WARNING! for HSA to activate: The Brake Assist System (BAS) cannot prevent There may be situations where the Hill Start The feature must be enabled.  the natural laws of physics from acting on the Assist (HSA) will not activate and slight rolling The vehicle must be stopped.
Page 133 SAFETY Towing With HSA Disabling And Enabling HSA 7. Rotate the steering wheel back to center and then an additional slightly more than HSA will also provide assistance to mitigate roll This feature can be turned on or turned off. To one-half turn to the right.
Page 134 SAFETY Electronic Stability Control (ESC) Indicator Light” begins to flash during WARNING! (Continued) acceleration, ease up on the accelerator and This system enhances directional control and apply as little throttle as possible. Be sure to Vehicle modifications, or failure to properly ...
Page 135 SAFETY ESC On NOTE: WARNING! System may switch from ESC “Full Off” to This is the normal operating mode for the ESC. When in “Partial Off” mode, the TCS func- “Partial Off” mode when vehicle exceeds a Whenever the vehicle is started, the ESC system ...
Page 136 SAFETY than 30 mph (48 km/h), see an authorized The ESC system will make buzzing or clicking  WARNING! (Continued) sounds when it is active. This is normal; the dealer as soon as possible to have the problem diagnosed and corrected. sounds will stop when ESC becomes inactive The Electronic Stability Control (ESC) ...
Page 137 SAFETY NOTE: NOTE: HDC Has Three States: ERM is disabled anytime the ESC is in “Full Off” TSC cannot stop all trailers from swaying. 1. Off (feature is not enabled and will not mode (if equipped). Refer to “Electronic Stability Always use caution when towing a trailer and activate).
Page 138 SAFETY Activating HDC 8th = 5.0 mph (8 km/h) Disabling HDC  Once HDC is enabled it will activate HDC will be deactivated and disabled if any of 9th = 5.6 mph (9 km/h) – If Equipped  automatically if driven down a grade of the following conditions occur: NOTE: sufficient magnitude.
Page 139: Auxiliary Driving Systems
SAFETY AUXILIARY DRIVING SYSTEMS The cluster icon and switch lamp will flash for The BSM detection zone covers approximately  several seconds then extinguish when the one lane width on both sides of the vehicle 12 ft Blind Spot Monitoring (BSM) — If Equipped driver pushes the HDC switch but enable (3.8 m).
Page 140 SAFETY The vehicle’s taillights, where the radar sensors sensors of the blockage. After removing the The BSM system monitors the detection zone are located, must remain free of snow, ice, and blockage, the following procedure can be used from three different entry points (side, rear, dirt/road contamination so that the BSM to reset the system: front) while driving to see if an alert is...
Page 141 SAFETY Entering From The Rear Vehicles that come up from behind your vehicle on either side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h). Overtaking/Approaching Stationary Objects The BSM system will not alert you of objects that are traveling in the opposite direction of the vehicle in adjacent lanes.
Page 142 SAFETY When RCP is on and the vehicle is in REVERSE, WARNING! the driver is alerted using both the visual and The Blind Spot Monitoring system is only an audible alarms, including reducing the radio aid to help detect objects in the blind spot volume.
Page 143 SAFETY Blind Spot Alert Lights Only NOTE: General Information Whenever an audible alert is requested by the When operating in Blind Spot Alert mode, the The following regulatory statement applies to all BSM system, the radio is also muted. BSM system will provide a visual alert in the Radio Frequency (RF) devices equipped in this appropriate side view mirror based on a vehicle:...
Page 144: Forward Collision Warning (Fcw) With Mitigation - If Equipped
SAFETY Forward Collision Warning (FCW) With the driver intends to avoid the collision by NOTE: Mitigation — If Equipped braking but has not applied sufficient brake The minimum speed for FCW activation is  force, the system will compensate and provide The Forward Collision Warning (FCW) system 3 mph (5 km/h).
Page 145 SAFETY NOTE: FCW Braking Status And Sensitivity WARNING! The FCW sensitivity and Active Braking status When the FCW is “on”, this allows the system  Forward Collision Warning (FCW) is not are programmable through the Uconnect to warn the driver of a possible collision with intended to avoid a collision on its own, nor System.
Page 146: Tire Pressure Monitoring System (Tpms)
SAFETY Near Service FCW Warning NOTE:  Changes or modifications not expressly If the system turns off, and the instrument When the sensitivity of FCW is set to the  approved by the party responsible for compli- cluster displays: “Near” setting and the system status is ance could void the user’s authority to operate ACC/FCW Unavailable Service Required “Warning and Braking”, this allows the...
Page 147 SAFETY inflation tire pressure. This is defined as the tire receives the updated tire pressures. The vehicle CAUTION! pressure after the vehicle has not been driven may need to be driven for up to 20 minutes for at least three hours, or driven less than above 15 mph (24 km/h) in order for the TPMS The TPMS has been optimized for the orig- ...
Page 148 SAFETY NOTE: NOTE: It is particularly important for you to check the The TPMS is not intended to replace normal  tire pressure in all of the tires on your vehicle tire care and maintenance or to provide monthly and to maintain the proper pressure. warning of a tire failure or condition.
Page 149 SAFETY Tire Pressure Monitoring Low Pressure value as shown in the "Inflate to XX" message. the system fault no longer exists, the “Tire Once the system receives the updated tire Pressure Monitoring Telltale Light” will no Warnings pressures, the system will automatically longer flash, and the "SERVICE TPM SYSTEM"...
Page 150 SAFETY cluster will display a “Tire Pressure Temporarily After driving the vehicle for up to 20 minutes Trailer Tire Pressure Monitoring System  above 15 mph (24 km/h), the TPM Telltale Light Unavailable” message in place of the tire (TTPMS) pressure display screen.
Page 151 SAFETY The TTPMS is configured though the trailer Tire Pressure Monitoring Low Pressure Service TTPMS Warning settings menu in the Uconnect system by Warnings If a system fault is detected, the system fault will selecting the desired trailer number (up to four When a tire pressure low in one or more of the sound a chime and the instrument cluster will trailers can be configured), the number of axles...
Page 152 SAFETY Trailer Sensors Detected Do Not Match Active Tire Fill Alert When Tire Fill Alert Mode is entered, the tire Trailer pressure display screen will be displayed in the This feature notifies the user when the placard instrument cluster. The “Trailer Sensors Detected Do Not Match tire pressure is attained while inflating or Active Trailer”...
Page 153 SAFETY In the Selectable Tire Fill Alert customer The hazard lamps will come on to confirm the NOTE: settings menu in the radio, the customer will be vehicle is in Tire Fill Alert mode. It is particularly important for you to check the able to select a pressure setting for both the tire pressure in all of the tires on your vehicle When Tire Fill Alert Mode is entered, the tire...
Page 154: Occupant Restraint Systems
SAFETY displayed, and a pressure value will display in NOTE: Here are some simple steps you can take to place of the dashes. A system fault can occur Changes or modifications not expressly minimize the risk of harm from a deploying air due to any of the following: approved by the party responsible for compli- bag:...
Page 155: Seat Belt Systems
SAFETY 6. All occupants should always wear their lap Enhanced Seat Belt Use Reminder System WARNING! (Continued) and shoulder belts properly. (BeltAlert) Never install a rear-facing child restraint in  Driver And Passenger BeltAlert — If Equipped 7. The driver and front passenger seats should the front seat of a vehicle.
Page 156 SAFETY BeltAlert Warning Sequence The outboard front passenger seat BeltAlert is feature allows the shoulder part of the seat belt not active when the outboard front passenger to move freely with you under normal The BeltAlert warning sequence is activated seat is unoccupied.
Page 157 SAFETY WARNING! WARNING! (Continued) WARNING! (Continued) A lap belt worn too high can increase the Do not allow people to ride in any area of A seat belt that is worn under your arm is    risk of injury in a collision. The seat belt your vehicle that is not equipped with seats dangerous.
Page 158 SAFETY Lap/Shoulder Belt Operating Instructions 3. When the seat belt is long enough to fit, insert the latch plate into the buckle until 1. Enter the vehicle and close the door. Sit you hear a “click.” back and adjust the seat. 2.
Page 159 SAFETY Lap/Shoulder Belt Untwisting Procedure verify the shoulder belt anchorage is latched, pull downward on the shoulder belt anchorage Use the following procedure to untwist a twisted until it is locked into position. lap/shoulder belt. 1. Position the latch plate as close as WARNING! possible to the anchor point.
Page 160 SAFETY First Row Center Seat Belt Operating 7. Position the lap belt so that it is snug and Instructions (Regular Cab Only) lies low across your hips, below your abdomen. To remove slack in the lap belt The first row center seat belt (Regular Cab only) portion, pull up on the shoulder belt.
Page 161 SAFETY First Row Center Lap Belt Operating WARNING! Instructions — If Equipped ONLY use a Seat Belt Extender if it is physi-  The center seating position for the Mega Cab cally required in order to properly fit the and Crew Cab front seat has a lap belt only. To original seat belt system.
Page 162 SAFETY Seat Belts And Pregnant Women Seat Belt Pretensioner Switchable Automatic Locking Retractors (ALR) — If Equipped The front outboard seat belt system is equipped with pretensioning devices that are designed to The seat belts in the passenger seating remove slack from the seat belt in the event of positions may be equipped with a Switchable a collision.
Page 163 SAFETY In Automatic Locking Mode, the shoulder belt is How To Engage The Automatic Locking Mode automatically pre-locked. The seat belt will still 1. Buckle the combination lap and shoulder retract to remove any slack in the shoulder belt. belt. Use the Automatic Locking Mode anytime a child restraint is installed in a seating position 2.
Page 164: Supplemental Restraint Systems (Srs)
SAFETY Air Bag System Components position. If the ignition switch is in the OFF WARNING! (Continued) position or in the ACC position, the air bag Occupant Restraint Controller (ORC)  system is not on and the air bags will not inflate. Failure to replace the seat belt assembly ...
Page 165 SAFETY The Air Bag Warning Light does not come on Front Air Bags  WARNING! during the four to eight seconds when the This vehicle has front air bags and lap/shoulder ignition switch is first in the ON/RUN position. Being too close to the steering wheel or ...
Page 166 SAFETY Driver And Passenger Front Air Bag Features 3500 Series Truck WARNING! (Continued) The Advanced Front Air Bag system has multistage 2500 Series Truck Do not put anything on or around the air driver and front passenger air bags. This system ...
Page 167 SAFETY On the other hand, depending on the type and Knee Impact Bolsters The SABs may help to reduce the risk of location of impact, front air bags may deploy in occupant injury during certain side impacts, in The Knee Impact Bolsters help protect the crashes with little vehicle front-end damage but addition to the injury reduction potential knees of the driver and front passenger, and...
Page 168 SAFETY SABICs may help reduce the risk of head and WARNING! WARNING! (Continued) other injuries to front and rear seat outboard Do not use accessory seat covers or place occupants in certain side impacts, in addition to In order for the SABICs to work as intended, ...
Page 169 SAFETY deploys the right Side Air Bags only. Vehicle WARNING! (Continued) WARNING! (Continued) damage by itself is not a good indicator of whether or not Side Air Bags should have Seat belts (and child restraints where Relying on the Side Air Bags alone could ...
Page 170 SAFETY The Side Air Bags will not deploy in all rollover Driver and Front Passenger Air Bags you haven’t healed significantly within a few  days, or if you have any blistering, see your events. The rollover sensing system determines Seat Belt Buckle Switch ...
Page 171 SAFETY NOTE: Your vehicle may also be designed to perform NOTE: any of these other functions in response to the After an accident, remember to cycle the ignition Air bag covers may not be obvious in the inte-  Enhanced Accident Response System: to the STOP (OFF/LOCK) position and remove the rior trim, but they will open during air bag key from the ignition switch to avoid draining the...
Page 172 SAFETY Maintaining Your Air Bag System Event Data Recorder (EDR) WARNING! (Continued) This vehicle is equipped with an event data WARNING! Do not attempt to modify any part of your  recorder (EDR). The main purpose of an EDR is air bag system.
Page 173: Child Restraints
SAFETY NOTE: Children 12 years or younger should ride Before buying any restraint system, make sure EDR data are recorded by your vehicle only if a properly buckled up in a rear seat, if available. that it has a label certifying that it meets all non-trivial crash situation occurs;...
Page 174 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and Either an Infant Carrier or a Convertible Child Infants and Toddlers who have not reached the height or weight limits Restraint, facing rearward in a rear seat of the vehicle...
Page 175 SAFETY Older Children And Child Restraints WARNING! WARNING! (Continued) Children who are two years old or who have Improper installation can lead to failure of Never install a rear-facing child restraint in   outgrown their rear-facing convertible child seat an infant or child restraint.
Page 176 SAFETY Children Too Large For Booster Seats 3. Does the shoulder belt cross the child’s A child’s squirming or slouching can move the shoulder between the neck and arm? belt out of position. If the shoulder belt contacts Children who are large enough to wear the the face or neck, move the child closer to the shoulder belt comfortably, and whose legs are 4.
Page 177 SAFETY Use Any Attachment Method Shown With An “X” Below Combined Weight of LATCH – Lower Restraint Type the Child + Child LATCH – Lower Seat Belt + Top Seat Belt Only Anchors + Top Tether Restraint Anchors Only Tether Anchor Anchor Forward-Facing Child Up to 65 lbs (29.5 kg)
Page 178 SAFETY Crew Cab 60/40 Split Bench LATCH Positions Mega Cab LATCH Positions Crew Cab Full Bench LATCH Positions Top Tether Anchorage Symbol Top Tether Anchorage Symbol Top Tether Anchorage Symbol Lower Anchorage Symbol (2 Anchorages Per Lower Anchorage Symbol (2 Anchorages Per Lower Anchorage Symbol (2 Anchorages Per Seating Position) Seating Position)
Page 179 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined weight of the child and the child What is the weight limit (child’s weight + weight restraint is 65 lbs (29.5 kg). Use the seat belt of the child restraint) for using the LATCH 65 lbs (29.5 kg) and tether anchor instead of the LATCH system...
Page 180 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Never “share” a LATCH anchorage with two or more child restraints. If the center position does Can two child restraints be attached using a not have dedicated LATCH lower anchorages, common lower LATCH anchorage? use the seat belt to install a child seat in the center position next to a child seat using the...
Page 181 SAFETY Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the gap between the seatback and seat cushion.
Page 182 SAFETY LATCH-compatible child restraint systems will Always follow the directions of the child WARNING! (Continued) be equipped with a rigid bar or a flexible strap restraint manufacturer when installing your on each side. Each will have a hook or child restraint. Not all child restraint systems Never use the same lower anchorage to ...
Page 183 SAFETY room for the child seat. You may also move being used to secure child restraints. An unused Installing Child Restraints Using The Vehicle the front seat forward to allow more room belt could injure a child if they play with it and Seat Belt for the child seat.
Page 184 SAFETY into the retractor. Refer to the “Automatic Lap/Shoulder Belt Systems For Installing Locking Mode” description in “Switchable Child Restraints In This Vehicle Automatic Locking Retractors (ALR)” under “Occupant Restraint Systems” for additional information on ALR. The cinching latch plate is designed to hold the lap portion of the seat belt tight when webbing is pulled tight and straight through a child restraint’s belt path.
Page 185 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight Always use the tether anchor when using the of the child restraint) for using the Tether Anchor seat belt to install a forward facing child Weight limit of the Child Restraint with the seat belt to attach a forward facing restraint, up to the recommended weight limit of...
Page 186 SAFETY Installing A Child Restraint With A Switchable For Regular Cab Models 7. Finally, pull up on any excess webbing to Automatic Locking Retractor (ALR): tighten the lap portion around the child Place the child seat in the center of the restraint while you push the child restraint Child restraint systems are designed to be seating position.
Page 187 SAFETY Installing A Child Restraint With A Cinching 2. Next, pull enough of the seat belt webbing Any seat belt system will loosen with time, so from the retractor to pass it through the belt check the belt occasionally, and pull it tight if Latch Plate (CINCH) —...
Page 188 SAFETY Installing Child Restraints Using The Top Regular and Mega Cab Trucks: 2. Route the tether strap to provide the most Tether Anchorage direct path between the anchorage and the In the regular cab truck, the top tether child seat. The tether strap should go anchorages are located behind the center and WARNING! between the head restraint posts...
Page 189 SAFETY Crew Cab Trucks: The top tether anchorages in this vehicle are tether strap loops located between the rear glass and the back of the rear seat. There is a tether strap loop located behind each seating position. Follow the steps below to attach the tether strap of the child restraint.
Page 190 SAFETY NOTE: 2. Place a child restraint on the seat and 4. Attach the hook to the outboard tether strap If there are child seats in both of the outboard adjust the tether strap so that it will reach loop (see diagram). Tighten the tether strap (left and right) seating positions, the tether over the seat back, under the head according to the child seat manufacturer’s...
Page 191: Transporting Pets
SAFETY SAFETY TIPS 3. Place a child restraint on the center rear WARNING! seat. Route the tether strap following the Transporting Passengers directions for the center seating position, An incorrectly anchored tether strap could  lead to increased head motion and above.
Page 192: Exhaust Gas
SAFETY Exhaust Gas The best protection against carbon monoxide Front seat belt assemblies must be replaced entry into the vehicle body is a properly after a collision. Rear seat belt assemblies must WARNING! maintained engine exhaust system. be replaced after a collision if they have been damaged (i.e., bent retractor, torn webbing, Whenever a change is noticed in the sound of Exhaust gases can injure or kill.
Page 193 SAFETY Defroster WARNING! (Continued) WARNING! (Continued) Check operation by selecting the defrost mode ONLY use the driver’s side floor mat on the  and place the blower control on high speed. You ALWAYS securely attach your floor mat  driver’s side floor area. To check for inter- should be able to feel the air directed against using the floor mat fasteners.
Page 194: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY Periodic Safety Checks You Should Make Door Latches WARNING! (Continued) Outside The Vehicle Check for proper closing, latching, and locking. If the vehicle carpet has been removed and  Tires Fluid Leaks re-installed, always properly attach carpet Examine tires for excessive tread wear and to the floor and check the floor mat Check area under the vehicle after overnight uneven wear patterns.
Page 195: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE NOTE: WARNING! (Continued) This vehicle is equipped with a transmission Before starting your vehicle, adjust your seat,  Do not leave the key fob in or near the  shift interlocking system. The brake pedal adjust both inside and outside mirrors, and vehicle, or in a location accessible to chil- must be pressed to shift out of PARK.
Page 196: Keyless Enter-N-Go - Ignition
STARTING AND OPERATING Keyless Enter-N-Go — Ignition 3. The system takes over and attempts to start 4. If the gear selector is not in PARK and the the vehicle. If the vehicle fails to start, the ENGINE START/STOP button is pushed starter will disengage automatically after 10 once with the vehicle speed above 5 MPH seconds.
Page 197 STARTING AND OPERATING 1. Start with the ignition in the OFF mode. If the vehicle is not in PARK and the driver turns WARNING! off the engine, the vehicle may AutoPark. 2. Push the ENGINE START/STOP button once Driver inattention could lead to failure to ...
Page 198 STARTING AND OPERATING If the vehicle is not in PARK and the driver exits If the driver shifts into PARK while moving, the Additional customer warnings will be given the vehicle with the engine running, the vehicle vehicle may AutoPark. when all of these conditions are met: may AutoPark.
Page 199: Cold Weather Operation (Below -22°F Or −30°C)
STARTING AND OPERATING The starter motor will engage automatically, run After Starting CAUTION! for 10 seconds, and then disengage. Once this The idle speed is controlled automatically, and occurs, release the accelerator pedal and the To prevent damage to the starter, do not crank it will decrease as the engine warms up.
Page 200: Engine Break-In Recommendations
STARTING AND OPERATING ENGINE BREAK-IN RECOMMENDATIONS NOTE: A new engine may consume some oil during its A long break-in period is not required for the first few thousand miles (kilometers) of opera- engine and drivetrain (transmission and axle) in tion. This should be considered a normal part of your vehicle.
Page 201: Automatic Transmission
STARTING AND OPERATING AUTOMATIC TRANSMISSION When parking on a hill, it is important to turn the WARNING! (Continued) front wheels toward the curb on a downhill grade and away from the curb on an uphill Do not leave the key fob in or near the ...
Page 202: Ignition Park Interlock
STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) CAUTION! (Continued) It is dangerous to shift out of PARK or Never leave children alone in a vehicle, or Before shifting into any gear, make sure    NEUTRAL if the engine speed is higher than with access to an unlocked vehicle.
Page 203: Brake/Transmission Shift Interlock System
STARTING AND OPERATING Brake/Transmission Shift Interlock System NOTE: The transmission gear selector has only PARK, In the event of a mismatch between the gear REVERSE, NEUTRAL, and DRIVE positions. This vehicle is equipped with a Brake selector position and the actual transmission Manual downshifts can be made using the Transmission Shift Interlock System (BTSI) that gear (for example, driver selects PARK while...
Page 204 STARTING AND OPERATING Gear Ranges NOTE: WARNING! (Continued) On four-wheel drive vehicles be sure that the Do not depress the accelerator pedal when transfer case is in a drive position. The transmission may not engage PARK if  shifting from PARK or NEUTRAL into another the vehicle is moving.
Page 205 STARTING AND OPERATING REVERSE (R) WARNING! (Continued) WARNING! (Continued) This range is for moving the vehicle backward. Unintended movement of a vehicle could Do not leave the key fob in or near the vehicle   Shift into REVERSE only after the vehicle has injure those in or near the vehicle.
Page 206 STARTING AND OPERATING DRIVE (D) During extremely cold temperatures (-22°F In the event of a momentary problem, the [-30°C] or below), transmission operation may transmission can be reset to regain all forward This range should be used for most city and be modified depending on engine and gears by performing the following steps: highway driving.
Page 207 STARTING AND OPERATING NOTE: cluster, and set that gear as the top available When to Use TOW/HAUL Mode Even if the transmission can be reset, we gear. Once in ERS mode, tapping the GEAR- or When driving in hilly areas, towing a trailer, recommend that you visit an authorized dealer GEAR+ switch will change the top available carrying a heavy load, etc., and frequent...
Page 208: Active Noise Cancellation
STARTING AND OPERATING FOUR-WHEEL DRIVE OPERATION — IF This electronically shifted transfer case WARNING! provides four mode positions: EQUIPPED Do not use the “TOW/HAUL” feature when Two-Wheel Drive High Range (2WD)  driving in icy or slippery conditions. The Four-wheel drive trucks are equipped with Four-Wheel Drive High Range (4WD HIGH) ...
Page 209 STARTING AND OPERATING 4WD LOW This electronically shifted transfer case is WARNING! designed to be driven in the two–wheel drive Four-Wheel Drive Low Range — This range You or others could be injured or killed if you position (2WD) for normal street and highway provides low speed four-wheel drive.
Page 210 STARTING AND OPERATING NOTE: If One Or More Of The Following Shift Conditions WARNING! The transfer case NEUTRAL button is located in Are Not Met: the center of the 4WD Control Switch and is Always engage the parking brake when 1.
Page 211 STARTING AND OPERATING Shifting Procedure 2WD To 4WD HIGH 2WD Or 4WD HIGH To 4WD LOW Push the desired position on the 4WD control NOTE: NOTE: switch to shift the transfercase. Shifts between When shifting into or out of 4WD LOW some If any of the requirements to select a new 2WD and 4WD HIGH can be done with the ...
Page 212: Manually Shifted Transfer Case - If Equipped
STARTING AND OPERATING Alternate Procedure Manually Shifted Transfer Case — If NEUTRAL (N) Equipped Neutral — This range disengages both the front 1. Bring the vehicle to a complete stop. and rear driveshafts from the powertrain. To be The transfer case provides four mode positions: 2.
Page 213 STARTING AND OPERATING The 4H and 4L positions are intended for loose, Because four-wheel drive provides improved Four-Wheel Drive High Range (4H) slippery road surfaces only. Driving in the 4H traction, there is a tendency to exceed safe Four-Wheel Drive High Range — This range locks and 4L positions on dry, hard surfaced roads turning and stopping speeds.
Page 214: Air Suspension System
STARTING AND OPERATING AIR SUSPENSION SYSTEM (2500/3500 Shifting Procedure — Manually Shifted NOTE: Transfer Case MODELS) — IF EQUIPPED Pausing in transfer case NEUTRAL in vehicles  equipped with an automatic transmission 2H To 4H Description may require shutting the engine OFF to avoid Shifting between 2H and 4H can be made with gear clash while completing the shift.
Page 215: Air Suspension Modes
STARTING AND OPERATING Normal Ride Height (NRH) – This is the standard settings menu or driving the vehicle above Tire/Jack Mode position of the suspension and is meant for 5 mph (8 km/h) for Tire Jack Mode or Alignment To assist with changing a tire, the air normal driving.
Page 216: Instrument Cluster Display Messages
STARTING AND OPERATING NOTE: soon as system operation requirements are NOTE: This mode is intended to be enabled with met. See your authorized dealer if system does The LED will continuously blink until Normal engine running. not resume. Ride Height (NRH) has been achieved and the LED will turn off.
Page 217: Axle Locker System - Power Wagon
STARTING AND OPERATING AXLE LOCKER SYSTEM — POWER WAGON NOTE: CAUTION! Even when the axles are in the AXLE UNLOCK MODELS ONLY (IF EQUIPPED) Do not lock the front or rear axle on hard position, the limited slip differential in the rear ...
Page 218: Stabilizer/Sway Bar System - Power Wagon Only
STARTING AND OPERATING NOTE: This system is controlled by the electronic WARNING! The axle lockers could be torque locked due to control sway bar switch located below the Do not use the locked axle position for normal side to side loads on the axle. Driving slowly instrument panel.
Page 219: Safe Off-Road Driving - Power
STARTING AND OPERATING SAFE OFF-ROAD DRIVING — POWER NOTE: WARNING! The stabilizer/sway bar may be torque locked WAGON ONLY Do not disconnect the stabilizer bar and drive due to left and right suspension height differ- ences. This condition is due to driving surface on hard surfaced roads or at speeds above Off-Road Driving Tips And Vehicle 18 mph (29 km/h), you may lose control of...
Page 220 STARTING AND OPERATING Skid Plates And Underbody Protection water, without stopping, 24 inches (60 cm) deep vehicle's steering, handling and traction. at a maximum speed of 10 mph (16 km/h) and a Controlling your vehicle is one of the keys to Steel skid plates protect the major driveline pool of water 30 inches (76 cm) deep at a successful off-road driving, so always keep a...
Page 221: Driving In Snow, Mud And Sand
STARTING AND OPERATING When To Use Low Range engine can spin the wheels and traction will Sand – Soft sand is very difficult to travel  be lost. If you start to slow to a stop, try through with full tire pressure. When crossing When driving off-road, shift into 4LO (Low turning your steering wheel no more than a ¼...
Page 222: Crossing Obstacles (Rocks And Other High Points)
STARTING AND OPERATING Crossing Obstacles (Rocks And Other High the person stand a safe distance in front of you crossing large obstacles with steep sides. Do Points) where they can see the obstacle, watch your not attempt to cross any large obstacle with tires and undercarriage, and guide you through.
Page 223: Hill Climbing
STARTING AND OPERATING should not be attempted. You should always tires back on the ground. As you approach CAUTION! feel confident with the vehicle and your abilities. the crest of the hill ease off the throttle and slowly proceed over the top. If the wheels Do not attempt to cross a log with a greater You should always climb hills straight up and start to slip as you approach the crest of a...
Page 224: Driving Through Water
STARTING AND OPERATING you feel confident in your ability to proceed Driving Through Water WARNING! then make sure you are in 4LO (Low Range) Extreme care should be taken crossing any type with the transmission in first gear (manually Driving across an incline increases the risk of of water.
Page 225 STARTING AND OPERATING Crossing Puddles, Pools, Flooded Areas Or around your tires putting you and your vehicle  CAUTION! Other Standing Water – Puddles, pools, in jeopardy. There is still a high risk of flooded or other standing water areas personal injury and vehicle damage with Water ingestion into the axles, transmission, normally contain murky or muddy waters.
Page 226: Airing Down For Off-Road Driving
STARTING AND OPERATING Airing Down For Off-Road Driving Vehicle Recovery the job better than a winch. If you are severely hung up on something you should jack the Running lower tire pressure off-road can If you drive off-road, you may encounter a vehicle up and stack something under the improve your ride comfort and vehicle traction.
Page 227 STARTING AND OPERATING before and after the shift. If after a few rock two tow straps together using a 1 ½ inch WARNING! cycles your vehicle is not free, stop and try hard wood dowel. This will keep the straps another method of recovery.
Page 228: After Driving Off-Road
STARTING AND OPERATING vehicle's weight and provide a direction of Check for accumulations of plants or brush.  WARNING! pull as straight as possible. Use block and These things could be a fire hazard. They tackle if necessary to improve the angle of Winch cables are under high tension when in might hide damage to fuel lines, brake hoses, pull or increase the winch's pulling force.
Page 229: Limited-Slip Differential
STARTING AND OPERATING LIMITED-SLIP DIFFERENTIAL Care should be taken to avoid sudden accelerations 2. Attach the hook to a suitable anchor point. when both rear wheels are on a slippery surface. The limited-slip differential provides additional CAUTION! This could cause both rear wheels to spin, and allow traction on snow, ice, mud, sand and gravel, the vehicle to slide sideways on the crowned surface Be certain the anchor will withstand the load...
Page 230: Understanding The Features Of Your Winch
STARTING AND OPERATING Understanding The Features Of Your Winch Winch Components 1. Motor: The winch motor is powered by the that will stop rotation of the winch drum if 6. Remote Control: The remote control provides vehicle charging system. the winch motor is stopped. the interface between the winch operator and the winch.
Page 231: Winch Accessories
STARTING AND OPERATING Fairlead: The hawse fairlead acts as a guide for Tree Trunk Protector: Typically made WARNING! (Continued) the synthetic rope and minimizes damage to the of tough, high-quality nylon, it rope. provides the operator an attachment Never exceed winch or synthetic rope rated ...
Page 232 STARTING AND OPERATING General Information WARNING! (Continued) CAUTION! (Continued) Practice using your winch before you get stuck. Never attempt to tow a vehicle with the Always inspect winch installation and   Some key points to remember when using your recovery strap attached directly to the synthetic rope condition before operating winch are:...
Page 233 STARTING AND OPERATING 1. Inspect the winch, winch mount, and 2. Put on gloves. 4. Free the winch hook and attach the hook synthetic rope for damage. Do not use the strap. Free the winch hook from its anchor 3. Disengage the clutch to allow free spooling winch if the mount is loose or rope shows point.
Page 234 STARTING AND OPERATING 5. Pull the wire to the anchor point. Pull out 6. Secure to the anchor point. Once you have NOTE: enough wire rope to reach your anchor established your anchor point, secure the How to choose an anchor point: A secure point.
Page 235 STARTING AND OPERATING 7. Attach the Clevis/D-shackle and Tree Trunk 9. Connect the remote control to the winch 10. Put synthetic rope under tension. Using the Protector. Attach the shackle to the two control box, located on the front bumper. Be remote control switch, slowly wind the rope ends of the strap or chain and through the careful not to let the remote control cord...
Page 236 STARTING AND OPERATING 12. Check synthetic rope. The rope should be 13. Establish "no people" zones: Make your neatly wound around the spooling drum. intentions clear. Be sure that everyone in the Improper winding can cause damage to the immediate vicinity surrounding the winching synthetic rope.
Page 237 STARTING AND OPERATING 14. Begin winching. With the winching vehicles NOTE: 15. Secure vehicle. Once recovery of the vehicle engine on and light tension already on the is complete, be sure to secure the vehicle's Avoid overheating the winch motor. For ...
Page 238: Rigging Techniques
STARTING AND OPERATING 18. Store the hook on the most outboard loop of increasing pulling power, or maintaining a WARNING! the hawse fairlead. straight-line pulling situation. You will have to To prevent serious injury, NEVER put your assess what technique is correct for your fingers inside the hook area as you are situation.
Page 239: Fuel Saver Technology - If Equipped
STARTING AND OPERATING Increasing Pulling Power block, pull out enough synthetic rope to reach your anchor point. Do not attach the hook to the In some cases, you may find yourself needing mounting kit. Secure to the anchor point with a more pulling power.
Page 240: To Activate
STARTING AND OPERATING To Activate To Vary The Speed Setting If the button is continually pushed, the set  speed will continue to increase until the Push the On/Off button to activate the Speed To Increase Speed button is released, then the new set speed Control.
Page 241: To Accelerate For Passing
STARTING AND OPERATING ADAPTIVE CRUISE CONTROL (ACC) — IF Metric Speed (km/h) WARNING! Pushing the SET (-) button once will result in  EQUIPPED Speed Control can be dangerous where the a 1 km/h decrease in set speed. Each subse- system cannot maintain a constant speed.
Page 242 STARTING AND OPERATING The Cruise Control system has two control WARNING! WARNING! (Continued) modes: Adaptive Cruise Control (ACC) is a conve- Does not always fully recognize complex  Adaptive Cruise Control mode for main-   nience system. It is not a substitute for active driving conditions, which can result in taining an appropriate distance between driving involvement.
Page 243: Adaptive Cruise Control (Acc) Operation
STARTING AND OPERATING NOTE: When the automatic transmission is in PARK,  WARNING! (Continued) Any chassis/suspension or tire size modifica- REVERSE or NEUTRAL. tions to the vehicle will effect the performance When entering a turn lane or highway off  When the vehicle speed is outside of the ...
Page 244: To Set A Desired Acc Speed
STARTING AND OPERATING To turn the system off, push and release the To Set A Desired ACC Speed To Cancel Adaptive Cruise Control (ACC) on/off button When the vehicle reaches the speed desired, The following conditions cancel the system: again. At this time, the system will turn off and push the SET (-) button and release.
Page 245: To Turn Off
STARTING AND OPERATING To Turn Off Metric Speed (km/h) WARNING! Pushing the RES (+) button once will result in  The system will turn off and clear the set speed The Resume function should only be used if a 1 km/h increase in set speed. Each subse- in memory if: traffic and road conditions permit.
Page 246: Setting The Following Distance In Acc
STARTING AND OPERATING Metric Speed (km/h) The ACC system applies the brake down to a distance setting and the vehicle speed, ACC  full stop when following the vehicle in front. calculates and sets the distance to the vehicle Pushing the SET (-) button once will result in ...
Page 247 STARTING AND OPERATING distance setting decreases by one bar. Once the NOTE: shortest setting is reached, if the button is The brake lights will illuminate whenever the pushed again it will reset to the default setting ACC system applies the brakes. (longest).
Page 248: Overtake Aid
STARTING AND OPERATING NOTE: standstill, your vehicle will resume motion Adaptive Cruise Control (ACC) Menu The “Brake!” Screen in the instrument cluster without the need for any driver action. The instrument cluster display will show the display is a warning for the driver to take action If the vehicle in front does not start moving current ACC system settings.
Page 249: Display Warnings And Maintenance
STARTING AND OPERATING The ACC screen may display once again if any “ACC/FCW Unavailable Wipe Front Radar To keep the ACC System operating properly, it is ACC activity occurs, which may include any of Sensor” and the system will deactivate. important to note the following maintenance the following: items:...
Page 250: Precautions While Driving With Acc
STARTING AND OPERATING NOTE: The “ACC/FCW Limited Functionality Clean Service ACC/FCW Warning Front Windshield” message can sometimes be If the system turns off, and the instrument If the “ACC/FCW Unavailable Wipe Front  displayed while driving in adverse weather cluster displays “ACC/FCW Unavailable Service Radar Sensor”...
Page 251 STARTING AND OPERATING Do not put stickers or easy passes over the Offset Driving Turns And Bends  camera/radar field of view. ACC may not detect a vehicle in the same lane When driving on a curve with ACC engaged, the that is offset from your direct line of travel, or a system may decrease the vehicle speed and Any modifications to the vehicle that may...
Page 252 STARTING AND OPERATING Using ACC On Hills Lane Changing Narrow Vehicles When driving on hills, ACC may not detect a ACC may not detect a vehicle until it is Some narrow vehicles traveling near the outer vehicle in your lane. Depending on the speed, completely in the lane in which you are edges of the lane or edging into the lane are not vehicle load, traffic conditions, and the...
Page 253: General Information
STARTING AND OPERATING Stationary Objects And Vehicles 1. This device may not cause harmful button will result in turning on (changing to) the interference. Normal (Fixed Speed) Cruise Control mode. ACC does not react to stationary objects and stationary vehicles. For example, ACC will not 2.
Page 254 STARTING AND OPERATING To Vary The Speed Setting Metric Speed (km/h) decrements until the button is released. The decrease in set speed is reflected in the Pushing the RES (+) button once will result in a To Increase Speed  instrument cluster display.
Page 255: Parksense Rear Park Assist - If Equipped
STARTING AND OPERATING PARKSENSE REAR PARK ASSIST — IF The braking temperature exceeds normal ParkSense Sensors  range (overheated). EQUIPPED The four ParkSense sensors, located in the rear fascia/bumper, monitor the area behind the The gear selector is removed from the DRIVE ...
Page 256: Parksense Display
STARTING AND OPERATING ParkSense Display When the vehicle is in REVERSE, the warning display will turn on indicating the system status. The system will indicate a detected obstacle by showing a single arc in the left and/or right rear regions based on the object’s distance and location relative to the vehicle.
Page 257 STARTING AND OPERATING Continuous Tone The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Greater than Less than...
Page 258: Enabling And Disabling Parksense
STARTING AND OPERATING Adjustable Chime Volume Settings The ParkSense switch LED will be on when rear fascia/bumper is clean and clear of snow, ParkSense is disabled or defective. The ice, mud, dirt or other obstruction, and then The rear chime volume settings are ParkSense switch LED will be off when the cycle the ignition.
Page 259: Parksense Front And Rear Park Assist
STARTING AND OPERATING ParkSense, when on, will reduce the volume  WARNING! CAUTION! of the radio when it is sounding a tone. Drivers must be careful when backing up ParkSense is only a parking aid and it is   Clean the ParkSense sensors regularly, ...
Page 260: Parksense Sensors
STARTING AND OPERATING ParkSense will retain the last system state NOTE: The system will indicate a detected obstacle by (enabled or disabled) from the last ignition cycle If equipped as a dually, the ParkSense system showing a single arc in the left and/or right rear when the ignition is changed to the ON/RUN has six rear sensors to assist in detection regions based on the obstacle’s distance and...
Page 261 STARTING AND OPERATING If an obstacle is detected in the left and/or right rear region, the display will show a single arc in the left and/or right rear region and the system will produce a tone. As the vehicle moves closer to the obstacle, the display will show the single arc moving closer to the vehicle and the tone will change from a single 1/2 second tone to...
Page 262 STARTING AND OPERATING The vehicle is close to the obstacle when the display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS FOR REAR Greater than Less than Rear Distance...
Page 263: Enabling And Disabling Front And/Or Rear Parksense
STARTING AND OPERATING NOTE: When the gear selector is moved to When the gear selector is moved into REVERSE, ParkSense will reduce the volume of the radio, REVERSE and the Front or Rear a vehicle graphic will show in the instrument if on, when the system is sounding an audio system is disabled, the instrument cluster display, along with the display overlay...
Page 264: Parksense System Usage Precautions
STARTING AND OPERATING ParkSense System Usage Precautions Use the ParkSense switch to turn the Park-  WARNING! (Continued) Sense system off if obstacles such as bicycle NOTE: carriers, trailer hitches, etc. are placed within Before using ParkSense, it is strongly ...
Page 265: Parkview Rear Back Up Camera
STARTING AND OPERATING Manual Activation Of The Rear View Camera: NOTE: CAUTION! (Continued) 1. Press the "Controls" button located on the If the vehicle speed remains below 8 mph  The vehicle must be driven slowly when  bottom of the Uconnect display. (13 km/h), the Rear View Camera image will using ParkSense in order to be able to stop be displayed continuously until deactivated...
Page 266 STARTING AND OPERATING A touchscreen button "X" to disable display of A dashed center line overlay indicates the CAUTION! the camera image is made available when the center of the vehicle to assist with parking or vehicle is not in REVERSE gear. aligning to a hitch/receiver.
Page 267 STARTING AND OPERATING four times the standard view. Pressing the icon NOTE: If equipped with two AUX Cameras, you can a second time will return the view to the switch between each camera by pressing the If the vehicle in is DRIVE, NEUTRAL, or ...
Page 268: Surround View Camera System - If Equipped
STARTING AND OPERATING SURROUND VIEW CAMERA SYSTEM — IF When the vehicle is shifted into REVERSE, the The following table shows the approximate rear camera view and top view is the default distances for each zone: EQUIPPED view of the system (Automatic Activation). Distance To The Rear Zone When the vehicle is shifted out of REVERSE...
Page 269 STARTING AND OPERATING The fifth button of the ParkSense Camera View NOTE: Front Cross Path View screen will be changed based on the features Pressing the Front Cross Path soft key Front tires will be in image when the tires are ...
Page 270 STARTING AND OPERATING NOTE: the display screen, the image will zoom in to Deactivation If the Cargo Camera view was selected through four times the standard view. Pressing the icon The system is deactivated in the following the Surround View screen, exiting out of the a second time will return the view to the conditions if it was activated automatically: Cargo Camera screen will return to the...
Page 271 STARTING AND OPERATING Ignition is cycled to OFF that aligns to the center of the pickup box to aid 2. Use the arrows on the bottom left corner of  in hooking up a fifth wheel camper or the Cargo Camera display to adjust the Vehicle speed is over 8 mph (13 km/h) for ...
Page 272 STARTING AND OPERATING When Zoom View is selected while the vehicle is roads. Tire Lines can be activated/deactivated If the vehicle goes out of 4LO, then the regular in REVERSE, then shifted to DRIVE, the camera through the Uconnect settings. deactivation conditions listed above are delay view will display the standard Cargo applied.
Page 273 STARTING AND OPERATING switched to the OFF position. There is a touch If equipped with two AUX Cameras, you can CAUTION! (Continued) screen button (X) to disable the display of the switch between each camera by pressing the camera image. AUX 1 or AUX 2 buttons on the Trailer Camera To avoid vehicle damage, the vehicle must ...
Page 274: Refueling The Vehicle - Gas Engine
STARTING AND OPERATING REFUELING THE VEHICLE — GAS ENGINE NOTE: WARNING! (Continued) When the fuel nozzle “clicks” or shuts off, the The fuel filler cap (gas cap) is located behind the  A fire may result if gasoline is pumped into ...
Page 275: Loose Fuel Filler Cap Message
STARTING AND OPERATING Loose Fuel Filler Cap Message Payload Rim Size If the vehicle diagnostic system The payload of a vehicle is defined as the This is the rim size that is appropriate for the tire determines that the fuel filler cap is allowable load weight a truck can carry, size listed.
Page 276: Trailer Towing
STARTING AND OPERATING TRAILER TOWING The entire vehicle should first be weighed on a Gross Trailer Weight (GTW) commercial scale to insure that the GVWR has The GTW is the weight of the trailer plus the In this section you will find safety tips and not been exceeded.
Page 277 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) Trailer Sway Control Weight-Distributing Hitch The GAWR is the maximum capacity of the front The trailer sway control can be a mechanical A weight-distributing system works by applying and rear axles. Distribute the load over the front telescoping link that can be installed between leverage through spring (load) bars.
Page 278 STARTING AND OPERATING NOTE: WARNING! (Continued) Normal Ride Height (NRH) or Alternate Trailer Height (ATH) can be used. The vehicle must Weight distributing systems may not be  compatible with surge brake couplers. remain in the engine running position while Consult with your hitch and trailer manufac- attaching a trailer for proper leveling of the air turer or a reputable Recreational Vehicle...
Page 279 STARTING AND OPERATING 4. Measure the height of the top of the front NOTE: Measurement Example 2500/ wheel opening on the fender to ground, this For all towing conditions, we recommend towing Example 3500 Height (mm) is height H2. with tow haul mode engaged. 1030 5.
Page 280: Trailer Hitch Type And Maximum Trailer Weight
STARTING AND OPERATING Trailer Hitch Type and Maximum Trailer Weight The following chart provides the maximum trailer weight a given factory equipped trailer hitch type can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Type and Maximum Trailer Weight Hitch Type Max.
Page 281: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Consider the following items when computing Towing Requirements the weight on the rear axle of the vehicle: Weight Ratings) To promote proper break-in of your new vehicle The tongue weight of the trailer. ...
Page 282 STARTING AND OPERATING Check for signs of tire wear or visible tire  WARNING! WARNING! (Continued) damage before towing a trailer. Refer to Make certain that the load is secured in the “Tires” in “Servicing And Maintenance” for GCWR must not be exceeded. ...
Page 283 STARTING AND OPERATING Integrated Trailer Brake Module — If The user interface consists of the following: WARNING! Equipped Manual Brake Control Lever Do not connect trailer brakes to your  Your vehicle may have an Integrated Trailer Slide the manual brake control lever to the left vehicle's hydraulic brake lines.
Page 284 STARTING AND OPERATING GAIN Adjustment Buttons (+/-) 1. Make sure the trailer brakes are in good 5. Push the RIGHT arrow on the steering wheel working condition, functioning normally to enter “TRAILER TOW”. Pushing these buttons will adjust the brake and properly adjusted.
Page 285 STARTING AND OPERATING Light Electric Heavy Electric Light EOH Heavy EOH Electric over Hydraulic Electric over Hydraulic Type of Trailer Brakes Electric Trailer Brakes Electric Trailer Brakes Trailer Brakes Trailer Brakes Load *Under 10,000 lbs *Above 10,000 lbs *Under 10,000 lbs *Above 10,000 lbs * The suggested selection depends and may change depending on the customer preferences for braking performance.
Page 286: Towing Tips
STARTING AND OPERATING NOTE: Automatic Transmission The DRIVE range can be selected when towing. Disconnect trailer wiring connector from the  The transmission controls include a drive vehicle before launching a boat (or any other strategy to avoid frequent shifting when towing. device plugged into vehicle’s electrical However, if frequent shifting does occur while in connect) into water.
Page 287: Snowplow
STARTING AND OPERATING SNOWPLOW Speed Control — If Equipped Highway Driving Reduce speed. Do not use on hilly terrain or with heavy   2500/3500 Models Only loads. Temporarily turn off air conditioning.  Snowplow Prep Packages are available as a When using the speed control, if you experi- ...
Page 288 STARTING AND OPERATING Check the runners and cutting edge for The loaded vehicle weight, including the  WARNING! excessive wear. The cutting edge should be snowplow system, all aftermarket accessories, Attaching a snowplow to this vehicle could ¼ to ½ in (6 cm to 1.2 cm) above ground in driver, passengers, options, and cargo, must snow plowing position.
Page 289 STARTING AND OPERATING The blade should be lowered whenever the Operating Tips Operate with transfer case in 4LO when  vehicle is parked. plowing small or congested areas where Under ideal snow plowing conditions, 20 mph speeds are not likely to exceed 15 mph Maintain and operate your vehicle and (32 km/h) should be maximum operating (24 km/h).
Page 290: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Wheels OFF The Two-Wheel Drive Towing Condition Four-Wheel Drive Models Ground Models See Instructions Automatic transmission in PARK  Flat Tow NONE NOT ALLOWED Transfer case in NEUTRAL (N) ...
Page 291: Recreational Towing - Four-Wheel Drive Models
STARTING AND OPERATING NOTE: CAUTION! (Continued) CAUTION! (Continued) If vehicle is equipped with air suspension, ensure the vehicle is set to Normal Ride Height. Do not disconnect the driveshaft because Before recreational towing, the transfer   fluid may leak from the transmission, case must be in NEUTRAL.
Page 292 STARTING AND OPERATING Shifting Into NEUTRAL (N) NOTE: 6. Shift the transmission into REVERSE. If vehicle is equipped with air suspension, Use the following procedure to prepare your 7. Release the brake pedal for five seconds ensure the vehicle is set to Normal Ride Height. vehicle for recreational towing.
Page 293 STARTING AND OPERATING NOTE: Shifting Out Of NEUTRAL (N) With electronic shift transfer case with  With electronic shift transfer case: push-button selector switch, push and Use the following procedure to prepare your hold the switch for the desired transfer vehicle for normal usage: Steps 2 through 3 are requirements that must ...
Page 294: Driving Tips
STARTING AND OPERATING DRIVING TIPS 9. Press and hold the brake pedal. Flowing/Rising Water 10. Release the parking brake. WARNING! Driving On Slippery Surfaces 11. Shift the transmission into gear, release the Do not drive on or across a road or path Acceleration brake pedal, and check that the vehicle where water is flowing and/or rising (as in...
Page 295: Off-Road Driving Tips
STARTING AND OPERATING Off-Road Driving Tips WARNING! (Continued) CAUTION! (Continued) Care should be taken when attempting to climb Driving through standing water limits your Driving through standing water may cause   steep hills or driving diagonally across a hill or vehicle’s braking capabilities, which damage to your vehicle’s drivetrain compo- slope.
Page 296 STARTING AND OPERATING After Driving Off-Road Check for accumulations of plants or brush.  WARNING! These things could be a fire hazard. They Off-road operation puts more stress on your might hide damage to fuel lines, brake hoses, Abrasive material in any part of the brakes vehicle than does most on-road driving.
Page 297: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS NOTE: WARNING! With extended use the Hazard Warning flashers The Hazard Warning switch is located may wear down your battery. ALWAYS obey traffic laws and pay attention to on the upper switch bank just below the road.
Page 298 IN CASE OF EMERGENCY ASSIST Call the cancellation button on the Device Screen. WARNING! Termination of the SOS Call will turn off the The ASSIST Button is used to automatically green LED light on the overhead console. ALWAYS obey traffic laws and pay attention to connect you to any one of the following support the road.
Page 299 IN CASE OF EMERGENCY in the vehicle. The vehicle’s SOS Call system SOS Call System Limitations WARNING! (Continued) will attempt to remain connected with the Vehicles sold in Mexico DO NOT have SOS Call SOS operator until the SOS operator termi- The SOS Call system is embedded into the ...
Page 300 IN CASE OF EMERGENCY Even if the SOS Call system is fully functional, The vehicle battery loses power or becomes  WARNING! disconnected during a vehicle crash. factors beyond FCA US LLC’s control may Ignoring the overhead console light could prevent or stop the SOS Call system operation.
Page 301 IN CASE OF EMERGENCY NOTE: General Information WARNING! This device complies with Part 15 of the FCC Your vehicle may be transmitting data as  ALWAYS obey traffic laws and pay attention to Rules. Operation is subject to the following two authorized by the subscriber.
Page 302: Bulb Replacement
IN CASE OF EMERGENCY BULB REPLACEMENT Replacement Bulbs All of the inside bulbs are brass or glass-wedge base. Aluminum base bulbs are not approved. Interior Bulbs Bulb Number Overhead Console Lamps TS 212–9 Dome Lamp 7679 For lighted switches, see your authorized dealer for replacement instructions. Exterior Bulbs Bulb Number Low Beam (Halogen Reflector Headlamp)
Page 303: Replacing Exterior Bulbs
IN CASE OF EMERGENCY Bulb Number Side Indicators (Front And Side View Mirror) LED (Serviced at authorized dealer) Base Rear Tail/Turn and Stop Lamp 3157K Premium Rear Tail/Turn and Stop Lamp LED (Serviced At An Authorized Dealer) Premium Backup Lamp 7440/W21W Center High Mounted Stop Lamp (CHMSL) Cab Roof Marker Lamps...
Page 304 IN CASE OF EMERGENCY 4. Reach through the access hole of the wheel 6. Rotate the bulb counterclockwise 1/4 turn CAUTION! house splash shield and disengage the bulb to unlock the bulb from the lamp. access cover by rotating counterclockwise. Do not contaminate the bulb glass by ...
Page 305 IN CASE OF EMERGENCY 3. Look under the hood and behind the Side Marker Lamp 4. Reach through the access hole of the wheel headlamp to find the park and turn socket. house splash shield and disengage the side 1. Open the hood. marker socket by rotating counterclockwise ¼...
Page 306 IN CASE OF EMERGENCY Fog Lamps — If Equipped Rear Tail/Stop, Turn Signal And Backup 2. Pull the outboard side of the lamp rearward Lamps far enough to unsnap the two receptacles 1. Reach under and behind the front bumper on the outboard side of the lamp housing to access the back of the front fog lamp 1.
Page 307 IN CASE OF EMERGENCY 3. Disconnect the wiring harness connectors Center High-Mounted Stoplamp (CHMSL) 2. Separate the connector holding the housing from the bulb socket. and wiring harness to the body. With Cargo Lamp 4. Rotate the bulb socket counterclockwise 1.
Page 308 IN CASE OF EMERGENCY 4. Pull the desired bulb straight from the Outside Bulbs: Cargo Lamps 2. Rotate the bulb socket ¼ turn and pull it  socket. from the lamp assembly. Inside Bulb: Center High-Mounted Stop  Lamp 5. Reverse the procedure for installation of bulbs and housing.
Page 309: Fuses
IN CASE OF EMERGENCY FUSES Rear Lamp Bar ID Marker (Dual Rear Wheels) Side Marker Lamps (Dual Rear Wheels) — If — If Equipped Equipped WARNING! 1. Loosen the two screws and the housing to gain access to the bulb sockets. When replacing a blown fuse, always use ...
Page 310: Power Distribution Center
IN CASE OF EMERGENCY Power Distribution Center The Power Distribution Center is located in the engine compartment near the battery. This center contains cartridge fuses, micro fuses, relays, and circuit breakers. A description of each fuse and component may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
Page 311 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 20 Amp Blue (DS 1500 LD/ – NOX Sensor – If Equipped Cummins Diesel) – Aux Relay Output- SSV Only 40 Amp Green 40 Amp Green – Aux Relay Output / Diesel Fuel Heater – If Equipped (SSV &...
Page 312 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 30 Amp Pink – Passenger Door Module 30 Amp Pink – Drive Train Control Module Engine Control Module GPEC / Heavy Duty / Other – If 20 Amp Blue – Equipped 25 Amp White –...
Page 313 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description Vehicle System Interface Module #2 – If Equipped (HD 30 Amp Pink – Only) SSV (DS 1500 Only) 30 Amp Pink – Sunroof – If Equipped 30 Amp Pink – Electric Back Light –...
Page 314 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description Ignition Node Module / Keyless Ignition Node Module, – 10 Amp Red Radio Frequency Hub Module / Electric Steering Column Lock - If Equipped – 5 Amp Tan Battery Sensor –...
Page 315 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description MOD Inverter (Wake Up) / Power Port / USB IP / WCPM – – 10 Amp Red If Equipped (HD Only) Spare (DS 1500 Only) Sunroof / Light and Rain Sensor Module / Inside Rearview –...
Page 316 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description Electronic Stability Control (HD Only) – Brake System Module / Stop Lamp Switch / Electric Park 10 Amp Red Brake / Clutch Pedal Switch (DS 1500 Only) Drivetrain Control Module / Front Axle Disconnect Module / TCM (HD Only) –...
Page 317 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description Air Suspension / ITBM / Steering Column Control Module / MOD Gateway CAN-C Trailer TPM (HD Only) – 10 Amp Red Air Suspension / Trailer Tow / DC/DC Converter (Voltage Stabilizer) / Steering Column Control Module / Occupant Classification Sensor (DS 1500 Only) –...
Page 318 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 20 Amp Yellow Front Heated Seat Driver – If Equipped (HD Only) HVAC / DASM (DS 1500 Only) – 10 Amp Red HVAC / In-Car Temperature Sensor / CSG MOD / Humidity Sensor (HD Only) F100 –...
Page 319: Jacking And Tire Changing
IN CASE OF EMERGENCY JACKING AND TIRE CHANGING NOTE: If your vehicle is equipped with an air suspen- sion system, there is a feature which allows the WARNING! automatic leveling to be disabled to assist with Do not attempt to change a tire on the side ...
Page 320 IN CASE OF EMERGENCY Remove the jack and tools from the bracket There are two ways to assemble the tools: CAUTION! assembly. Turn the jack-turn-screw Assembled For Spare Tire Lowering/Raising counterclockwise to release jack from bracket The lug wrench can only be attached to ...
Page 321: Removing The Spare Tire
IN CASE OF EMERGENCY Assembled For Jack Operation 2. Remove the protective cover over the WARNING! access hole for the winch mechanism by After using the jack and tools, always reinstall sliding the cover upward. them in the original carrier and location. While driving you may experience abrupt stopping, rapid acceleration or sharp turns.
Page 322 IN CASE OF EMERGENCY 3. Insert the extension tube through the ground with enough cable slack to allow you 6. Lift the spare tire with one hand to give access hole between the lower tailgate and to pull it out from under the vehicle. clearance to tilt the retainer at the end of the top of the bumper and into the winch the cable.
Page 323: Preparations For Jacking
IN CASE OF EMERGENCY NOTE: 5. Turn the ignition OFF. Jacking Instructions The winch mechanism is designed for use with 6. Block both the front and rear of the wheel WARNING! the extension tubes only. Use of an air wrench diagonally opposite the jacking position.
Page 324 IN CASE OF EMERGENCY NOTE: WARNING! (Continued) If your vehicle is equipped with hub caps/wheel covers they must be removed before raising the Only use the jack in the positions indicated  and for lifting this vehicle during a tire vehicle off the ground.
Page 325 IN CASE OF EMERGENCY 3. Placement of the jack is critical: 4. Front Jacking Location 5. Rear Jacking Location When changing the front wheel, assemble When changing a rear wheel, assemble the the jack driver to the jack and connect the jack driver to the jack and connect the jack jack driver to the extension tubes.
Page 326 IN CASE OF EMERGENCY 8. Remove the lug nuts and pull the wheel off. CAUTION! On single rear-wheel (SRW) trucks, install Before raising the wheel off the ground, make the spare wheel and lug nuts with the cone sure that the jack will not damage shaped end of the wheel nuts toward the surrounding truck parts and adjust the jack wheel.
Page 327: To Stow The Flat Or Spare
IN CASE OF EMERGENCY NOTE: 1. Turn the wheel so that the valve stem is WARNING! Do not oil wheel studs. For chrome wheels, do facing the ground and toward the rear of A loose tire or jack thrown forward in a not substitute with chrome plated lug nuts.
Page 328 IN CASE OF EMERGENCY 2. Lift the spare tire with one hand to give 3. Attach the lug wrench to the extension 4. Rotate the lug wrench handle clockwise clearance to tilt the retainer at the end of tubes with the curved angle facing away until the wheel is drawn into place against the cable and position it properly across the from the vehicle.
Page 329: Reinstalling The Jack And Tools
IN CASE OF EMERGENCY Reinstalling The Jack And Tools 3. Place the jack and tool bracket assembly in 4. Turn the wing bolt clockwise to secure to the the storage position holding the jack by the floor pan. Reinstall the plastic cover. 1.
Page 330: Jump Starting
IN CASE OF EMERGENCY JUMP STARTING For 2500/3500 single rear wheel (SRW) models, use the flat end of the lug wrench to If your vehicle has a discharged battery, it can hook and pull off the hub cap. Find the opening be jump started using a set of jumper cables in the hub cap, insert the lug wrench, and pull and a battery in another vehicle, or by using a...
Page 331: Preparations For Jump Start
IN CASE OF EMERGENCY Preparations For Jump Start WARNING! WARNING! The battery in your vehicle is located in the front Take care to avoid the radiator cooling fan Do not allow vehicles to touch each other as  of the engine compartment, behind the left whenever the hood is raised.
Page 332 IN CASE OF EMERGENCY Connecting The Jumper Cables Disconnecting The Jumper Cables WARNING! 1. Connect the positive (+) end of the jumper 1. Disconnect the negative (-) end of the Do not connect the jumper cable to the cable to the positive (+) post of the jumper cable from the engine ground of negative (-) post of the discharged battery.
Page 333: Manual Park Release - 8-Speed
IN CASE OF EMERGENCY In order to push or tow the vehicle in cases 4. Using the screwdriver or similar tool, push the CAUTION! where the transmission will not shift out of Manual Park Release lever locking tab (just Accessories plugged into the vehicle power PARK (such as a dead battery), a Manual Park below the middle of the lever) to the right.
Page 334: If Your Engine Overheats
IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS FREEING A STUCK VEHICLE WARNING! In any of the following situations, you can If your vehicle becomes stuck in mud, sand, or You or others can be badly burned by hot reduce the potential for overheating by taking snow, it can often be moved using a rocking engine coolant (antifreeze) or steam from the appropriate action.
Page 335: Towing A Disabled Vehicle
IN CASE OF EMERGENCY NOTE: WARNING! CAUTION! (Continued) Vehicles equipped with the Air Suspension Fast spinning tires can be dangerous. Forces System must be placed in Transport mode, When “rocking” a stuck vehicle by shifting  before tying them down (from the body) on a generated by excessive wheel speeds may between DRIVE and REVERSE, do not spin cause damage, or even failure, of the axle...
Page 336 IN CASE OF EMERGENCY Wheels OFF The Towing Condition 2WD Models 4WD Models Ground See instructions in “Recreational Towing” under “Starting And Operating” If transmission is operable: Automatic Transmission in PARK  • Transmission in NEUTRAL Flat Tow NONE • 30 mph (48 km/h) max speed Transfer Case in NEUTRAL (N) ...
Page 337: Two-Wheel Drive Models
IN CASE OF EMERGENCY Two-Wheel Drive Models (when using a suitable steering wheel stabilizer CAUTION! to hold the front wheels in the straight position) The manufacturer recommends towing your with the rear wheels raised and the front wheels Front or rear wheel lifts must not be used (if ...
Page 338: Enhanced Accident Response System (Ears)
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM EVENT DATA RECORDER (EDR) WARNING! (EARS) This vehicle is equipped with an Event Data Do not use a chain for freeing a stuck  Recorder (EDR). The main purpose of an EDR is vehicle.
Page 339: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING If a scheduled oil change is performed by is operated predominantly at idle, or only very someone other than your authorized dealer, the low engine RPM’s. This type of vehicle use is Your vehicle is equipped with an automatic oil message can be reset by referring to the steps considered Severe Duty.
Page 340: Maintenance Plan
SERVICING AND MAINTENANCE Maintenance Plan Required Maintenance Refer to the Maintenance Plan on the following pages for required maintenance. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter.  Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before the oil indicator system turns on. ...
Page 341 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, and replace if necessary. Inspect the front and rear axle surfaces. If gear oil leakage is suspected, check the fluid level.
Page 342 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Replace spark plugs. Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Inspect the transfer case fluid, change for any of the following: police, taxi, fleet, or frequent trailer towing.
Page 343: Heavy Duty Use Of The Vehicle
SERVICING AND MAINTENANCE Heavy Duty Use Of The Vehicle WARNING! Change engine oil at 4,000 miles (6,500 km) or You can be badly injured working on or  350 hours of engine run time if the vehicle is around a motor vehicle. Do only service operated in a dusty and off road environment or work for which you have the knowledge and is operated predominately at idle or only very...
Page 344: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 6.4L Engine 1 — Engine Coolant Pressure Cap 6 — Battery 2 — Engine Coolant Reservoir 7 — Distribution Center (Fuses) 3 — Engine Oil Fill 8 — Washer Fluid Reservoir 4 — Engine Oil Dipstick 9 —...
Page 345: Checking Oil Level - Gas Engine
SERVICING AND MAINTENANCE Checking Oil Level — Gas Engine When refilling the washer fluid reservoir, take Maintenance-Free Battery some washer fluid and apply it to a cloth or To assure proper lubrication of your vehicle's Your vehicle is equipped with a towel and wipe the wiper blades clean.
Page 346: Dealer Service
SERVICING AND MAINTENANCE NOTE: Engine Oil Selection — 6.4L CAUTION! Intentional tampering with emissions control For best performance and maximum protection It is essential when replacing the cables on systems may void your warranty and could result  under all types of operating conditions, the the battery that the positive cable is in civil penalties being assessed against you.
Page 347: Engine Oil Filter
SERVICING AND MAINTENANCE Engine Oil Viscosity (SAE Grade) — 6.4L Materials Added To Engine Oil Engine Air Cleaner Filter Engine The manufacturer strongly recommends Refer to the “Maintenance Plan” in this section against the addition of any additives (other than Use Mopar SAE 0W-40 engine oil approved to for the proper maintenance intervals.
Page 348: Air Conditioner Maintenance
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection And 3. Remove the air cleaner filter element from 3. Tighten the fasteners (six) on the air cleaner Replacement the housing assembly. filter assembly Inspect engine air cleaner filter for dirt and or Air Conditioner Maintenance debris, if you find evidence of either dirt or For best possible performance, your air...
Page 349 SERVICING AND MAINTENANCE global-warming potential. The manufacturer 2. With the glove compartment door open, CAUTION! recommends that air conditioning service be remove the glove compartment tension Do not use chemical flushes in your air performed by an authorized dealer using tether and tether clip by sliding the clip recovery and recycling equipment.
Page 350 SERVICING AND MAINTENANCE by removing the left side from the hinge by 4. Remove the filter cover by pushing in on the 5. Remove the cabin air filter by pulling it slightly lowering the compartment while finger tabs on each end of the filter cover. straight out of the housing.
Page 351: Accessory Drive Belt Inspection
SERVICING AND MAINTENANCE 8. Pull the tension tether outward and reinstall Accessory Drive Belt Inspection the glove compartment past the travel stops WARNING! by pushing in on the glove compartment sides. Do not attempt to inspect an accessory  drive belt with vehicle running. When working near the radiator cooling fan, ...
Page 352: Body Lubrication
SERVICING AND MAINTENANCE Some conditions can be caused by a faulty The external lock cylinders should be lubricated NOTE: component such as a belt pulley. Belt pulleys twice a year, preferably in the Fall and Spring. Life expectancy of wiper blades varies should be carefully inspected for damage and Apply a small amount of a high quality lubricant, depending on geographical area and frequency...
Page 353 SERVICING AND MAINTENANCE Wiper Blade Removal/Installation 2. To disengage the wiper blade from the wiper 3. Tilt the lower end of the wiper blade away arm, flip up the locking tab. from the arm and use one finger push the CAUTION! release tab toward the wiper arm.
Page 354: Exhaust System
SERVICING AND MAINTENANCE 5. With the wiper blade disengaged, remove Installing The Front Wipers have an authorized technician inspect the the wiper blade from the wiper arm by complete exhaust system and adjacent body 1. Lift the wiper arm off of the glass, until the holding the wiper arm with one hand and areas for broken, damaged, deteriorated, or wiper arm is in the full up position.
Page 355: Cooling System
SERVICING AND MAINTENANCE NOTE: Cooling System CAUTION! Intentional tampering with emissions control WARNING! The catalytic converter requires the use of systems can result in civil penalties being  unleaded fuel only. Leaded gasoline will assessed against you. You or others can be badly burned by hot ...
Page 356 SERVICING AND MAINTENANCE Engine Coolant Checks If the engine coolant (antifreeze) is dirty or Do not use water alone or alcohol-based engine  coolant (antifreeze) products. Do not use addi- contains visible sediment, have an authorized Check the engine coolant (antifreeze) protection dealer clean and flush with OAT coolant tional rust inhibitors or antirust products, as every 12 months (before the onset of freezing...
Page 357 SERVICING AND MAINTENANCE Please review these recommendations for NOTE: WARNING! using Organic Additive Technology (OAT) engine It is the owner's responsibility to maintain the  coolant (antifreeze) that meets the Do not open hot engine cooling system.  proper level of protection against freezing Never add engine coolant (antifreeze) when requirements of FCA Material Standard according to the temperatures occurring in...
Page 358: Brake System
SERVICING AND MAINTENANCE Checking Coolant Level — 6.4L Engine If an examination of your engine compartment Keep the front of the radiator clean. If your  vehicle is equipped with air conditioning, shows no evidence of radiator or hose leaks, The level of the coolant in the pressurized coolant the vehicle may be safely driven.
Page 359: Automatic Transmission
SERVICING AND MAINTENANCE Fluid Level Check — Brake Master Cylinder WARNING! WARNING! (Continued) The fluid level of the master cylinder should be Use only manufacturer's recommended Overfilling the brake fluid reservoir can   checked when performing under the hood brake fluid.
Page 360: Rear Axle And 4X4 Front Driving Axle Fluid Level
SERVICING AND MAINTENANCE Fluid Level Check — Eight-Speed Fluid And Filter Changes — Eight-Speed CAUTION! Transmission Transmission Using a transmission fluid other than the The fluid level is preset at the factory and does Under normal operating conditions, the fluid manufacturer’s recommended fluid may not require adjustment under normal operating installed at the factory will provide satisfactory...
Page 361: Transfer Case
SERVICING AND MAINTENANCE Lubricant Selection Drain And Refill Drain And Refill Refer to “Fluids And Lubricants” in “Technical Refer to the “Maintenance Plan” for the proper Refer to the “Maintenance Plan” in this section Specification” for further information. maintenance intervals. for the proper maintenance intervals.
Page 362 SERVICING AND MAINTENANCE Tire Markings NOTE: Temporary spare tires are designed for  temporary emergency use only. Temporary P (Passenger) — Metric tire sizing is based on  high pressure compact spare tires have the U.S. design standards. P-Metric tires have letter “T”...
Page 363 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
Page 364 SERVICING AND MAINTENANCE EXAMPLE: H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions  The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e., tire pressure, vehicle ...
Page 365 SERVICING AND MAINTENANCE Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle.
Page 366 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a Cold Tire Inflation Pressure minimum of three hours.
Page 367 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: NOTE: 1. Number of people that can be carried in The proper cold tire inflation pressure is listed the vehicle. on the driver’s side B-Pillar or the rear edge of the driver's side door.
Page 368 SERVICING AND MAINTENANCE For further information on GAWRs, vehicle (4) The resulting figure equals the NOTE: loading, and trailer towing, refer to “Vehicle available amount of cargo and luggage If your vehicle will be towing a trailer, load  Loading” in the “Starting And Operating” load capacity.
Page 369 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.
Page 370: Tires - General Information
SERVICING AND MAINTENANCE Tires — General Information Fuel Economy WARNING! (Continued) Underinflated tires will increase tire rolling Tire Pressure Unequal tire pressures can cause steering  resistance resulting in higher fuel consumption. Proper tire inflation pressure is essential to the problems.
Page 371 SERVICING AND MAINTENANCE Example: If garage temperature = 68°F (20°C) CAUTION! WARNING! and the outside temperature = 32°F (0°C) then After inspecting or adjusting the tire the cold tire inflation pressure should be High speed driving with your vehicle under increased by 3 psi (21 kPa), which equals 1 psi pressure, always reinstall the valve stem cap.
Page 372 SERVICING AND MAINTENANCE Tire Repair Run Flat Tires — If Equipped Tire Spinning If your tire becomes damaged, it may be Run Flat tires allow you the capability to drive When stuck in mud, sand, snow, or ice repaired if it meets the following criteria: 50 miles (80 km) at 50 mph (80 km/h) after a conditions, do not spin your vehicle's wheels rapid loss of inflation pressure.
Page 373 SERVICING AND MAINTENANCE Tread Wear Indicators Life Of Tire NOTE: Wheel Valve Stem must be replaced as well Tread wear indicators are in the original The service life of a tire is dependent upon when installing new tires due to wear and tear equipment tires to help you in determining varying factors including, but not limited to: in existing tires.
Page 374: Tire Types
SERVICING AND MAINTENANCE It is recommended to replace the two front tires sidewall. Use all season tires only in sets of four; WARNING! (Continued) or two rear tires as a pair. Replacing just one tire failure to do so may adversely affect the safety can seriously affect your vehicle’s handling.
Page 375: Spare Tires - If Equipped
SERVICING AND MAINTENANCE Snow Tires Spare Tires — If Equipped If your vehicle has this option, refer to an authorized tire dealer for the recommended tire Some areas of the country require the use of NOTE: rotation pattern. snow tires during the Winter. Snow tires can be For vehicles equipped with Tire Service Kit identified by a “mountain/snowflake”...
Page 376 SERVICING AND MAINTENANCE Since this tire has limited tread life, the original Full Size Spare — If Equipped WARNING! equipment tire should be repaired (or replaced) The full size spare is for temporary emergency use Compact and collapsible spares are for and reinstalled on your vehicle at the first only.
Page 377: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE Your wheels are susceptible to deterioration When cleaning extremely dirty wheels including WARNING! caused by salt, sodium chloride, magnesium excessive brake dust, care must be taken in the Limited use spares are for emergency use chloride, calcium chloride, etc., and other road selection of tire and wheel cleaning chemicals chemicals used to melt ice or control dust on and equipment to prevent damage to the...
Page 378: Tire Chains (Traction Devices)
SERVICING AND MAINTENANCE NOTE: Dark Vapor Chrome, Black Satin Chrome, or Tire Chains (Traction Devices) If you intend parking or storing your vehicle for Low Gloss Clear Coat Wheels Use of traction devices require sufficient an extended period after cleaning the wheels tire-to-body clearance.
Page 379: Tire Rotation Recommendations
SERVICING AND MAINTENANCE increase tread life, help to maintain mud, snow WARNING! CAUTION! (Continued) and wet traction levels and contribute to a Using tires of different size and type (M+S, smooth, quiet ride. Drive cautiously and avoid severe turns and ...
Page 380: Department Of Transportation
SERVICING AND MAINTENANCE Dual Rear Wheels — If Equipped After a tire rotation is completed, as shown  CAUTION! (Continued) below, the system can auto learn the loca- The tires used on dual wheel assemblies should tions of each sensor ID. Auto learning/local- When replacing a flat, the spare tire may ...
Page 381: Treadwear
SERVICING AND MAINTENANCE represent higher levels of performance Treadwear WARNING! on the laboratory test wheel, than the The Treadwear grade is a comparative The traction grade assigned to this tire is minimum required by law. rating, based on the wear rate of the tire based on straight-ahead braking traction when tested under controlled conditions tests, and does not include acceleration,...
Page 382: Bodywork
SERVICING AND MAINTENANCE BODYWORK Insects, tree sap and tar. Preserving The Bodywork  Salt in the air near seacoast localities. Washing  Protection From Atmospheric Agents Wash your vehicle regularly. Always wash  Atmospheric fallout/industrial pollutants.  Vehicle body care requirements vary according your vehicle in the shade using Mopar Car to geographic locations and usage.
Page 383 SERVICING AND MAINTENANCE Special Care CAUTION! CAUTION! (Continued) If you drive on salted or dusty roads or if you  Do not use scouring pads, steel wool, a bristle Use of power washers exceeding 1,200 psi  drive near the ocean, hose off the undercar- (8,274 kPa) can result in damage or brush, metal polishes, or oven cleaner.
Page 384 SERVICING AND MAINTENANCE If you carry special cargo such as chemicals, To Help Maintain The Appearance Of Your Spray-On Bedliners are chemically-resistant to  fertilizers, de-icer salt, etc., be sure that such Spray-On Bedliner, Follow The Steps Below: many different types of chemicals (including materials are well packaged and sealed.
Page 385: Interiors
SERVICING AND MAINTENANCE INTERIORS For tough stains, apply Mopar Total Clean, or NOTE:  a mild soap solution to a clean, damp cloth If the belts retract slowly, inspect the upper Seats And Fabric Parts and remove stain. Use a fresh, damp towel to turning loop for soiling.
Page 386: Plastic And Coated Parts
SERVICING AND MAINTENANCE Plastic And Coated Parts Leather Parts CAUTION! Use Mopar Total Clean to clean vinyl upholstery. Mopar Total Clean is specifically recommended Do not use Alcohol and Alcohol-based and/or for leather upholstery. Ketone based cleaning products to clean CAUTION! Your leather upholstery can be best preserved leather upholstery, as damage to the...
Page 387: Technical Specifications
TECHNICAL SPECIFICATIONS IDENTIFICATION DATA NOTE: Hydraulic Brake Assist — 2500/3500 It is illegal to remove or alter the VIN. Models Only (Except Power Wagon) Vehicle Identification Number BRAKE SYSTEM The brake system power assist is provided by a The Vehicle Identification Number (VIN) is found hydro-boost unit which shares fluid with the If power assist is lost for any reason (for on the left front corner of the instrument panel,...
Page 388: Torque Specifications
TECHNICAL SPECIFICATIONS Torque Specifications Tighten the lug nuts/bolts in a star pattern until each nut/bolt has been tightened twice. Ensure Lug Nut/ that the socket is fully engaged on the lug nut/ Lug Nut/ **Lug Lug Nut/ Bolt bolt (do not insert it halfway). Bolt Nut/Bolt Bolt Type...
Page 389: Fuel Requirements
TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS Reformulated Gasoline www.toptiergas.com for a list of TOP TIER Detergent Gasoline Retailers. Many areas of the country require the use of 6.4L Engine Indiscriminate use of fuel system cleaning cleaner burning gasoline referred to as agents should be avoided. Many of these Do not use E-85 flex fuel or ethanol blends “Reformulated Gasoline”.
Page 390: Do Not Use E-85 In Non-Flex Fuel Vehicles
TECHNICAL SPECIFICATIONS Problems that result from using gasoline CNG And LP Fuel System Modifications gasoline pump; therefore, you should ask your containing more than 15% ethanol (E-15) or gasoline retailer whether the gasoline contains Modifications that allow the engine to run on gasoline containing methanol are not the MMT.
Page 391: Carbon Monoxide Warnings
TECHNICAL SPECIFICATIONS Carbon Monoxide Warnings CAUTION! (Continued) WARNING! The use of fuel additives, which are now  being sold as octane enhancers, is not Carbon monoxide (CO) in exhaust gases is recommended. Most of these products deadly. Follow the precautions below to contain high concentrations of methanol.
Page 392: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES U.S. Metric Fuel (Approximate) 2500/3500 Shortbed Models 31 Gallons 117 Liters 2500/3500 Longbed Models 32 Gallons 121 Liters Engine Oil With Filter 6.4L Engine (We recommend you use SAE 0W-40 engine oil meeting the requirements of 7 Quarts 6.6 Liters FCA Material Standard MS-12633 for use in all operating temperatures.)
Page 393: Fluids And Lubricants
TECHNICAL SPECIFICATIONS FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Engine Coolant Formula OAT (Organic Additive Technology). For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of Engine Oil –...
Page 394 TECHNICAL SPECIFICATIONS CAUTION! CAUTION! (Continued) Mixing of engine coolant (antifreeze) other Do not use water alone or alcohol-based   than specified Organic Additive Technology engine coolant (antifreeze) products. Do (OAT) engine coolant (antifreeze), may not use additional rust inhibitors or antirust result in engine damage and may decrease products, as they may not be compatible corrosion protection.
Page 395: Chassis
We recommend you use Mopar Transfer Case Lubricant for Borg Warner Transfer Case 44-44 and 44-45. We recommend you use SAE 75W-85 HD Ram GL-5 Synthetic Axle Lubricant in 9.25 Front & 11.5 Rear Axles. Use Mopar Synthetic Gear Front and Rear Axle Lubricant SAE 75W-140 (MS-8985) in 12.0 Rear axles.
Page 396: Multimedia
MULTIMEDIA UCONNECT SYSTEMS DRAG & DROP MENU BAR For detailed information about your Uconnect The Uconnect features and services in the main system, refer to your Uconnect Owner’s Manual menu bar are easily changed for your Supplement. convenience. Simply follow these steps: NOTE: Uconnect screen images are for illustration purposes only and may not reflect exact soft-...
Page 397: Cybersecurity
MULTIMEDIA unauthorized and unlawful access to your NOTE: 1. Press the “Apps ” button to open the vehicle systems. App screen. FCA US LLC or your dealer may contact you  The risk of unauthorized and unlawful access to directly regarding software updates. 2.
Page 398: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS Push the MORE or SETTINGS button on the When making a selection, press the button on faceplate, then press the “Settings” button on the touchscreen to enter the desired mode. The Uconnect system uses a combination of the touchscreen (if equipped) to display the Once in the desired mode, press and release buttons on the touchscreen and buttons on the...
Page 399 MULTIMEDIA Display After pressing the “Display” button on the touchscreen, the following settings will be available. Setting Name Selectable Options Display Mode Auto Manual Set Language English, Français, Español Touchscreen Beep Fuel Saver Display NOTE: The “Fuel Saver Display” feature will allow you to enable fuel saver mode and will be displayed in the instrument cluster display. Units —...
Page 400 MULTIMEDIA Voice After pressing the “Voice” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Detailed Show Command List Always With Help Never Clock After pressing the “Clock” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Time...
Page 401 MULTIMEDIA Setting Name Selectable Options Tilt Side Mirrors In Reverse — If Equipped NOTE: When the “Tilt Side Mirrors In Reverse” feature is selected, the exterior side-view mirrors tilt downward when the ignition is in the RUN position and the transmission gear selector is in the REVERSE position. The mirrors move back to their previous position when the transmission is shifted out of REVERSE.
Page 402 MULTIMEDIA Setting Name Selectable Options ParkView Backup Camera Active Guidelines NOTE: Your vehicle may be equipped with the ParkView Rear Back Up Camera Active Guidelines that allows you to see active guidelines over the ParkView Back up camera display whenever the gear selector is put into REVERSE. The image will be displayed on the radio touchscreen display along with a caution note to “check entire surroundings”...
Page 403 MULTIMEDIA Setting Name Selectable Options Rain Sensing Auto Wipers — If Equipped NOTE: When the “Rain Sensing Auto Wipers” feature is selected, the system automatically activates the windshield wipers if it senses moisture on the wind- shield. Hill Start Assist — If Equipped NOTE: When the “Hill Start Assist”...
Page 404 MULTIMEDIA Setting Name Selectable Options Headlights With Wipers — If Equipped Auto Dim High Beams — If Equipped Flash Lights With Lock NOTE: When the “Flash Lights With Lock” feature is selected, the exterior lights flash when the doors are locked or unlocked with the key fob. This feature may be selected with or without the sound horn on lock feature selected.
Page 405 MULTIMEDIA Setting Name Selectable Options Auto Unlock On Exit NOTE: When the “Auto Unlock On Exit” feature is selected, all doors unlock when the vehicle is stopped, the transmission is in the PARK or NEUTRAL position and the driver's door is opened. Sound Horn With Lock 1st Press 2nd Press...
Page 406 MULTIMEDIA Setting Name Selectable Options Flash Lights With Lock NOTE: When the “Flash Lights With Lock” feature is selected, the exterior lights flash when the doors are locked or unlocked with the key fob. This feature may be selected with or without the “Sound Horn With Lock” feature selected. Power Side Steps —...
Page 407 MULTIMEDIA Engine Off Options After pressing the “Engine Off Options” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Easy Exit Seats — If Equipped 0 sec 30 sec Headlight Off Delay 60 sec 90 sec 0 sec 45 sec Engine Off Power Delay...
Page 408 MULTIMEDIA Setting Name Selectable Options Transport Mode NOTE: When the “Transport Mode” feature is selected, the air suspension system is disabled to assist with flat bed towing. Wheel Alignment Mode NOTE: The “Wheel Alignment Mode” feature prevents auto leveling of the air suspension while performing a wheel alignment service. Before performing a wheel alignment, this mode must be enabled.
Page 409 MULTIMEDIA Audio After pressing the “Audio” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance/Fade Front Back Left Right NOTE: The “Balance/Fade” feature allows you to adjust the Balance and Fade settings. Press and drag the speaker icon or use the arrows to adjust, tap the “C”...
Page 410 MULTIMEDIA Compass Settings — If Equipped After pressing the “Compass Settings” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Variance NOTE: Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences the variance should be set ...
Page 411 MULTIMEDIA Compass Variance Zone Map...
Page 412 MULTIMEDIA Phone/Bluetooth After pressing the “Phone/Bluetooth” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Paired Phones List of Paired Phones NOTE: The “Paired Phones” feature shows which phones are paired to the Phone/Bluetooth system. For further information, refer to the Uconnect Owner’s Manual Supplement.
Page 413 MULTIMEDIA Restore Default Settings After pressing the “Restore Default Settings” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Restore Default Settings Cancel NOTE: When the “Restore Default Settings” feature is selected it will reset the Display, Clock, Audio, and Radio Settings to their default settings. If “Yes” is selected a pop-up will appear asking "Are you sure you want to reset your settings to default?”...
Page 414: Uconnect 4/4C/4C Nav Settings
MULTIMEDIA Uconnect 4/4C/4C NAV Settings Press the “Apps” button on the touchscreen When making a selection, press the button on then press the “Settings” button on the the touchscreen to enter the desired mode. touchscreen to display the settings menu Once in the desired mode, press and release screen.
Page 415 MULTIMEDIA Language After pressing the “Language” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Language English Français Español NOTE: When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 416 MULTIMEDIA Setting Name Selectable Options Touchscreen Beep Controls Screen Time-Out — If Equipped Fuel Saver Display in Cluster — If Equipped NOTE: When selected, the system displays fuel saver mode in the instrument cluster. Navigation Next Turn Pop-ups Displayed In Cluster —...
Page 417 MULTIMEDIA Setting Name Selectable Options Power — If Equipped HP (US) HP (UK) Temperature °F °C Torque — If Equipped lb-ft Voice After pressing the “Voice” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Detailed...
Page 418 MULTIMEDIA Camera After pressing the “Camera” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Surround View Camera — If Equipped NOTE: The “Surround View Camera” feature displays a complete 360 degree view of the vehicle's exterior environment while backing up. Surround View Camera Delay —...
Page 419 MULTIMEDIA Setting Name Selectable Options Active Parkview Backup Camera Guidelines NOTE: The “ParkView Backup Camera Active Guide Lines” feature overlays the Rear Backup Camera image with active, or dynamic, grid lines to help illustrate the width of the vehicle and its project back up path, based on the steering wheel position when the option is checked. A dashed center line overlay indicates the center of the vehicle to assist with parking or aligning to a hitch/receiver.
Page 420 MULTIMEDIA Setting Name Selectable Options Surround View Camera Delay — If Equipped NOTE: The “Surround View Camera Delay” setting determines whether or not the screen will display the 360 degree view image with guidelines for up to ten seconds after the vehicle is shifted out of REVERSE. This delay will be canceled if the vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to the OFF position.
Page 421 MULTIMEDIA Setting Name Selectable Options Fixed Parkview Backup Camera Guidelines Forward Facing Camera Guidelines — If Equipped NOTE: The “Forward Facing Camera Guidelines” feature is an off-road type of feature that shows the path of the tires based on the steering wheel input. CHMSL (Center High Mounted Stop Lamp) Camera Dynamic Centerline —...
Page 422 MULTIMEDIA Setting Name Selectable Options Blind Spot Alert Lights Lights & Chime NOTE: Brakes the vehicle while in reverse if potential rear collision is detected. Hill Start Assist — If Equipped Tire Fill Assist — If Equipped Mirrors & Wipers After pressing the “Mirrors &...
Page 423 MULTIMEDIA Lights After pressing the “Lights” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay – NOTE: When the “Headlight Off Delay” feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle.
Page 424 MULTIMEDIA Setting Name Selectable Options Rear Cargo Guidance Lights — If Equipped NOTE: When the “Rear Cargo Guidance Lights” feature is selected, the lights in the cargo and bed of the truck will come on either when the headlight switch is pressed, or the button on the back bed of the truck is pressed.
Page 425 MULTIMEDIA Setting Name Selectable Options 1st Press Of Key Fob Unlocks Driver Door All Doors NOTE: When “1st Press Of Key Fob Unlocks: Driver Door” is selected, only the driver's door unlocks on the first press of the key fob unlock button. You ...
Page 426 MULTIMEDIA Power Side Steps — If Equipped After pressing the “Power Side Steps” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Power Side Steps Automatic Stow Auto Comfort Systems — If Equipped After pressing the “Auto-On Comfort” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated...
Page 427 MULTIMEDIA Setting Name Selectable Options Headlight Off Delay – NOTE: When the “Headlight Off Delay” feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle. Setting Name Selectable Options Auto Entry/Exit —...
Page 428 MULTIMEDIA Setting Name Selectable Options Wheel Alignment Mode NOTE: Before performing a wheel alignment, the “Wheel Alignment Mode” must be enabled. Refer to an authorized dealer for further information. Four Corner Air Suspension Modes Tire Jack Mode Transport Mode Wheel Alignment Mode —...
Page 429 MULTIMEDIA Audio After pressing the “Audio” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance/Fade Front Rear Left Right NOTE: The “Balance/Fade” feature allows you to adjust the Balance and Fade settings. Press and drag the speaker icon or use the arrows to adjust, tap the “C”...
Page 430 MULTIMEDIA Phone/Bluetooth Settings After pressing the “Phone/Bluetooth Settings” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Phone Pop-ups Displayed in Cluster — If Equipped Do Not Disturb List of Settings NOTE: Press “Do Not Disturb” to access the available settings. The following settings are: Auto Reply (both, text, call), Auto Reply Message (custom, default) and Custom Auto Reply Message (create message).
Page 431 MULTIMEDIA Setting Name Selectable Options Channel Skip List of Channels NOTE: SiriusXM can be programmed to designate a group of channels that are the most desirable to listen to or to exclude undesirable channels while scan- ning. This feature allows you to select the channels you would like to skip. Subscription Info Sirius ID NOTE:...
Page 432: Uconnect 4C Nav With 12-Inch Display Settings
MULTIMEDIA System Information After pressing the “System Information” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Software License System Software Information Screen NOTE: When the “Software License” feature is selected, a “System Software Information” screen will appear, displaying the system software version. Uconnect 4C NAV With 12–inch Display Press the “Settings”...
Page 433 MULTIMEDIA Language After pressing the “Language” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Espanol Français NOTE: When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 434 MULTIMEDIA Setting Name Selectable Options Touchscreen Beep Controls Screen Time-Out — If Equipped Fuel Saver Display — If Equipped NOTE: When selected, the system displays fuel saver mode in the instrument cluster. Navigation Turn-By-Turn Displayed in Cluster — If Equipped Phone Pop-Ups Displays In Cluster Ready To Drive Pop-Ups —...
Page 435 MULTIMEDIA Setting Name Selectable Options Temperature °F °C Torque — If Equipped lb-ft Voice After pressing the “Voice” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Detailed Show Command List Always w/Help Never...
Page 436 MULTIMEDIA Camera After pressing the “Camera” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Surround View Camera — If Equipped NOTE: The “Surround View Camera” feature displays a complete 360 degree view of the vehicle's exterior environment while backing up. Surround View Camera Delay —...
Page 437 MULTIMEDIA Setting Name Selectable Options Parkview Camera Delay NOTE: The “Parkview Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE. This delay will be canceled if the vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to the OFF position.
Page 438 MULTIMEDIA Safety & Driving Assistance After pressing the “Safety & Driving Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning — If Warning Only Warning & Active Braking Equipped NOTE: Applies brakes to slow the vehicle in case of potential forward collision, or applies brakes and a warning. Forward Collision Warning Near Sensitivity —...
Page 439 MULTIMEDIA Mirrors & Wipers After pressing the “Mirror and Wipers” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Tilt Side Mirrors In Reverse — If Equipped NOTE: When the “Tilt Side Mirrors In Reverse” feature is selected, the outside side-view mirrors will tilt downward when the ignition is in the RUN position and the transmission gear selector is in the REVERSE position.
Page 440 MULTIMEDIA Setting Name Selectable Options Headlight Off Delay NOTE: When the “Headlight Off Delay” feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle. Headlights With Wipers — If Equipped NOTE: When the “Headlights With Wipers”...
Page 441 MULTIMEDIA Doors & Locks After pressing the “Doors & Locks” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto Door Locks Auto Unlock On Exit NOTE: When the “Auto Unlock On Exit” feature is selected, all doors unlock when the vehicle is stopped and the transmission is in the PARK or NEUTRAL position and the driver's door is opened.
Page 442 MULTIMEDIA Setting Name Selectable Options Passive Entry — If Equipped NOTE: The “Passive Entry” feature allows you to lock and unlock the vehicle’s door(s) without having to push the key fob lock or unlock buttons. Personal Settings Linked To Key Fob — If Equipped NOTE: The “Personal Settings Linked To Key Fob”...
Page 443 MULTIMEDIA Engine Off Options After pressing the “Engine Off Options” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Engine Off Power Delay – NOTE: When the “Engine Off Power Delay” feature is selected, the power window switches, radio, Uconnect phone system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to ten minutes after the ignition is cycled to OFF.
Page 444 MULTIMEDIA Suspension — If Equipped After pressing the “Suspension” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Suspension Messages Warning Only Tire Jack Mode NOTE: When the “Tire Jack Mode” feature is selected, the air suspension system is disabled to assist with changing a spare tire. Transport Mode NOTE: When the “Transport Mode”...
Page 445 MULTIMEDIA Trailer Brake After pressing the “Trailer Brake” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Trailer Select Trailer 1 Trailer 2 Trailer 3 Trailer 4 NOTE: Once a Trailer is selected, press the “Use This Trailer” on the touchscreen to set this trailer as the one in current use. In each Trailer setting, the following settings appear: Heavy Electric over Braking...
Page 446 MULTIMEDIA Setting Name Selectable Options Speed Adjusted Volume NOTE: The “Speed Adjusted Volume” feature increases or decreases volume relative to vehicle speed. Surround Sound — If Equipped NOTE: The “Surround Sound” feature provides simulated surround sound mode. AUX Volume Offset — If Equipped NOTE: The “AUX Volume Offset”...
Page 447 MULTIMEDIA Setting Name Selectable Options Paired Phones and Audio Devices List Of Paired Phones and Audio Sources NOTE: The “Paired Phones and Audio Sources” feature shows which phones and audio sources are paired to the Phone and Audio Sources Settings system. For further information, refer to the Uconnect Owner’s Manual Supplement.
Page 448 MULTIMEDIA Setting Name Selectable Options NOTE: The “Tune Start” feature begins playing the current song from the beginning when you tune to a music channel using one of the twelve presets, so you can enjoy the complete song. This feature occurs the first time the preset is selected during that current song. Tune Start works in the background, so you will not even realize it's on, except that you will miss the experience of joining your favorite song with only a few seconds left to play.
Page 449 MULTIMEDIA Reset After pressing the “Reset” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Reset App Drawer Cancel Restore Settings Cancel NOTE: When the “Restore Settings” feature is selected it resets all settings to their default settings. Clear Personal Data Cancel NOTE:...
Page 450: Steering Wheel Audio Controls - If
MULTIMEDIA STEERING WHEEL AUDIO CONTROLS — IF IPOD/USB/MP3 CONTROL — IF EQUIPPED The left hand control is a rocker type switch with a push-button in the center. The function of the EQUIPPED Located on the center stack, just below the left hand control is different depending on instrument panel, is the main media hub.
Page 451 MULTIMEDIA For example, if a device is plugged into the Type A third and fourth USB Ports are located behind A USB port and another device is plugged into the center console, above the Power Inverter. the Type C port, connection to the Type A port One is a charge only port, and can only charge USB devices.
Page 452 MULTIMEDIA Center Console USB Port If equipped, two Mini-USB Ports (Type C), two Standard USB Ports (Type A), and one AUX Port Device Plugged In Message Screen Phone Or USB Plugged In Message Screen may be located to the left of the center stack, Plugging in a phone or another USB device may just below the climate controls.
Page 453: Radio Operation And Mobile Phones
MULTIMEDIA RADIO OPERATION AND MOBILE PHONES The radio manufacturer believes the internal wireless radio is safe for use by consumers. The Under certain conditions, the mobile phone level of energy emitted is far less than the being on in your vehicle can cause erratic or electromagnetic energy emitted by wireless noisy performance from your radio.
Page 454: Voice Commands
MULTIMEDIA NOTE: If this equipment does cause harmful inter- Get Started  ference to radio or television reception, Changes or modifications not expressly All you need to control your Uconnect system approved by the party responsible for compli- which can be determined by turning the with your voice are the buttons on your steering equipment off and on, the user is encour- ance could void the user’s authority to operate...
Page 455: Basic Voice Commands
MULTIMEDIA Notice the visual cues that inform you of your voice recognition system’s status. Cues appear on the top of the touchscreen. Uconnect Voice Command Buttons 1 — Push To Begin Radio Or Media Functions 2 — Push To Initiate, Answer, End A Phone Call, Or Send/Receive A Text Uconnect 3 With 5–inch Display Basic Voice Commands...
Page 456: Radio
MULTIMEDIA Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button . After the beep, say: “Tune to ninety-five-point-five FM” ...
Page 457: Media
MULTIMEDIA Media TIP: Press the Browse button on the touchscreen to Uconnect offers connections via USB, Bluetooth see all of the music on your USB device. Your and auxiliary ports (If Equipped). Voice Voice Command must match exactly how the operation is only available for connected USB artist, album, song and genre information is and AUX devices.
Page 458: Phone
MULTIMEDIA Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. Check UconnectPhone.com for mobile phone compatibility and pairing instructions. Push the Phone button . After the beep, say one of the following commands: Uconnect 3 Phone “Call John Smith”...
Page 459: Voice Text Reply - If Equipped
MULTIMEDIA Voice Text Reply — If Equipped PRE-DEFINED VOICE TEXT REPLY Uconnect announces incoming text messages. RESPONSES Push the VR button or Phone button I’ll call you I need See you in 5 enabled) and say “Listen.” (Must have later. directions.
Page 460: Climate (4C/4C Nav)
MULTIMEDIA Apple iPhone iOS 6 or later supports reading TIP: TIP: incoming text messages only. To enable this Voice Text Reply is not compatible with iPhone, Voice Command for Climate may only be used feature on your Apple iPhone, follow these four but if your vehicle is equipped with Siri Eyes to adjust the interior temperature of your simple steps:...
Page 461: Navigation (4C Nav)
MULTIMEDIA Navigation (4C NAV) The Uconnect navigation feature helps you save time and become more productive when you know exactly how to get to where you want to go. 1. To enter a destination, push the VR button . After the beep, say: “Find address 800 Chrysler Drive Auburn Hills, Michigan.”...
Page 462: Siriusxm Guardian (4C/4C Nav) - If Equipped
MULTIMEDIA SiriusXM Guardian (4C/4C NAV) — If Canada. Services can only be used where Register (4C/4C NAV) Equipped coverage is available; see coverage map for To unlock the full potential of SiriusXM details. Guardian in your vehicle, you must activate your CAUTION! SiriusXM Guardian services.
Page 463: Mobile App (4C/4C Nav)
MULTIMEDIA Mobile App (4C/4C NAV) Press the Location button on the navigation TIP:  bar at the bottom of the app to bring up a Traffic alerts are not accessible with Voice You’re only a few steps away from using remote map to locate your vehicle or send a location Command.
Page 464: Siri Eyes Free - If Equipped
MULTIMEDIA Siri Eyes Free — If Equipped Siri lets you use your voice to send text messages, select media, place phone calls and much more. Siri uses your natural language to understand what you mean and responds back to confirm your requests. The system is designed to keep your eyes on the road and your hands on the wheel by letting Siri help you perform useful tasks.
Page 465: Using Do Not Disturb
MULTIMEDIA Using Do Not Disturb NOTE: Android Auto. Push and hold the VR button on the steering wheel, or press and hold the With Do Not Disturb, you can disable Only the beginning of your custom message  “Microphone” icon within Android Auto, to notifications from incoming calls and texts, will be seen on the touchscreen.
Page 466: Apple Carplay - If Equipped
MULTIMEDIA Refer to your Uconnect Owner’s Manual hold the VR button on the steering wheel, or Supplement for further information. press and hold the “Home” button within Apple CarPlay, to activate Siri, which recognizes NOTE: natural voice commands to use a list of your Requires compatible smartphone running iPhone’s features: Android 5.0 or higher and download app on...
Page 467: General Information
MULTIMEDIA Refer to your Uconnect Owner’s Manual General Information Supplement for further information. The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this NOTE: vehicle: Requires compatible iPhone. See dealer for phone compatibility. Data plan rates apply. This device complies with Part 15 of the FCC Vehicle user interface is a product of Apple.
Page 468: Additional Information
MULTIMEDIA CD/DVD DISC MAINTENANCE Additional Information © 2020 FCA US LLC. All rights reserved. Mopar To keep a CD/DVD in good condition, take the and Uconnect are registered trademarks and following precautions: Mopar Owner Connect is a trademark of FCA US Handle the disc by its edge;...
Page 469: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE Be Reasonable With Requests This is why you should always talk to an authorized dealer service manager first. Most FOR YOUR VEHICLE If you list a number of items and you must have matters can be resolved with this process. your vehicle by the end of the day, discuss the If for some reason you are still not satisfied, ...
Page 470: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE FCA US LLC Customer Center Customer Assistance For The Hearing Or weeks of the vehicle delivery date. If you have Speech Impaired (TDD/TTY) any questions about the service contract, call P.O. Box 21–8004 the manufacturer's Service Contract National To assist customers who have hearing Auburn Hills, MI 48321–8004 Customer Hotline at 1-800-521-9922...
Page 471: Warranty Information
CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS To contact NHTSA, you may call the WARNING! Vehicle Safety Hotline toll free at In The 50 United States And Washington, Engine exhaust (internal combustion engines 1-888-327-4236 (TTY: D.C. only), some of its constituents, and certain 1-800-424-9153);...
Page 472: Publication Order Forms
CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Diagnostic Procedure Manuals Owner's Manuals Diagnostic Procedure Manuals are filled with These Owner's Manuals have been prepared To order the following manuals, you may use diagrams, charts and detailed illustrations. with the assistance of service and engineering either the website or the phone numbers listed These practical manuals make it easy for specialists to acquaint you with specific FCA US...
Page 473: Index
INDEX ......... 52 ....... 201 Air Conditioning Automatic Transmission ..239 ......64 ..........358 Adaptive Cruise Control (ACC) (Cruise Control) Air Conditioning Filter Adding Fluid ....354 ........62 ......358 Adding Engine Coolant (Antifreeze) Air Conditioning System Fluid And Filter Change ............272 .......63 ..........
Page 474 ........129 ........317 ..........353 Brake Control System Changing A Flat Tire Cooling System .......... 357 ........... 361 ...... 354 Brake Fluid Chart, Tire Sizing Adding Coolant (Antifreeze) ........356 ........354 Brake System Check Engine Light (Malfunction Coolant Level ..........357 ..........
Page 475 Disposal Emergency, In Case Of Ethanol ............387 Antifreeze (Engine Coolant) .......355 Freeing Vehicle When Stuck ..... 332 Exhaust Gas Cautions ......190 Do Not Disturb ..........463 Hazard Warning Flasher ......295 Exhaust System ........190 Door Ajar ............120 Jump Starting ...........
Page 476 ......142 Forward Collision Warning Guide ...........206 ..........11 .............17 Four Wheel Drive Body Builders Ignition .......295 ............273 ............17 Four-Way Hazard Flasher GVWR Switch .........332 ..........49 Freeing A Stuck Vehicle Illuminated Entry ........358 Front Axle (Differential) In Vehicle Help ...............387 ........12 Fuel Hazard Vehicle User Guide...
Page 477 Key Fob Programming (Remote Keyless Entry) .. 17 Cargo ............47 Traction Control ........134 Keyless Enter-N-Go .........24 Center Mounted Stop ....... 305 Transfer Case ........... 212 Lock The Vehicle’s Doors ..402 Courtesy/Reading ........48 Turn Signals ....47 Passive Entry ..........24 Cruise ............
Page 478 ........... 69 ........152 ............. 380 Maintenance Occupant Restraints Paint Care ......343 ..... 387 ............14 Maintenance Free Battery Octane Rating, Gasoline (Fuel) Panic Alarm ........337 ..217 ..........198 Maintenance Schedule Off-Pavement Driving (Off-Road) Parking Brake ..217 ...... 253 Malfunction Indicator Light Off-Road Driving (Off-Pavement) ParkSense System, Rear...
Page 479 Tilt ............... 30 Refrigerant ............ 347 Safety, Exhaust Gas ........190 ..............30 Release, Hood ..........69 Schedule, Maintenance ........ 337 Power Steering Fluid ........393 Release, Tailgate ..........70 Seat Belt Reminder ........117 Pregnant Women And Seat Belts ....160 Reminder, Seat Belt ........
Page 480 ..........28 ..........24 Seats Side Steps, Power Steering ........... 28 ......... 47 ...........37 Adjustment Signals, Turn Tilt Column ........... 33 ..............462 ..........37 Easy Entry Siri Wheel, Heated ..........81 ......66 ............37 Folding Floor Sliding Rear Window, Power Wheel, Tilt ..........
Page 481 Tilt Steering Column ........37 Rotation ............ 377 Trailer Towing ..........274 Tip Start ............193 Safety ..........359 Cooling System Tips ........285 Tire And Loading Information Placard ...365 Sizes ............361 Hitches ............. 278 Tire Changing ..........317 Snow Tires ..........
Page 482 ..........327 Wheel Covers ....385 ............227 Uconnect Vehicle Identification Number (VIN) Winch .. 396 ........273 ..........229 Uconnect Settings Vehicle Loading Accessories ....11 ..........229 Vehicle Modifications/Alterations Operation ........63 ........236 Uconnect Settings Vehicle Storage Rigging Techniques ...24 ............
Page 483 Mobile radio equipment with output power greater than INSTALLATION OF RADIO TRANSMITTING normal may require special precautions. EQUIPMENT Special design considerations are incorporated into this All installations should be checked for possible interference between the communications equipment vehicle’s electronic system to provide immunity to radio and the vehicle’s electronic systems.
Page 484 ©2021 FCA US LLC. All Rights Reserved. Tous droits réservés. Ram is a registered trademark of FCA US LLC. Ram est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

This manual is also suitable for:

2500 2019

Save PDF
