Operating System Information

The built-in OS on DTA1376/DTA1376A is Ubuntu version 18.04 and Linux
kernel version is 5.4.47. The OS and bootloader are customized by NXP
LSDK version 20.12. For more information of LSDK, please visit
com to search LSDK or refer to LSDK user guide at following link:
www.nxp.com/docs/en/user-guide/LSDKUG_Rev20.12.pdf.

Logging into the System.

1. Connect the console port (refer to the section of
DTA1376/DTA1376A) to a PC using a RJ45 serial console cable.
2. Install a terminal software (e.g. PuTTY, Tera Term, or Minicom) on the
connected PC. The UART Baud rate setting is 115200-8-N-1 and no
flow control.
3. Log in to Ubuntu using the installed terminal software after powering
on the DTA1376/DTA1376A. By default, the username and password
both are "root".
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
C
onfIguratIon
www.nxp.
https://
Knowing Your
29

Mapping the Network Ports

Refer to the table below for network ports mapping.
Port Port Name
Number on Chassis
Port 0 RGMII
Port 1 QSGMI
Port 2 QSGMII
Port 3 QSGMII
Port 4 QSGMI
Port 5 RGMII
Port 6 SGMI
Port name Port name
in U-Boot in Linux
FM1@DTSEC3 fm1-mac3
FM1@DTSEC6 fm1-mac6
FM1@DTSEC5 fm1-mac5
FM1@DTSEC10 fm1-mac10
FM1@DTSEC1 fm1-mac1
FM1@DTSEC4 fm1-mac4
FM1@DTSEC9 fm1-mac9
