Chapter 2: Jumpers and Connectors

CPLD Program Connector

Connector type: 1x6 6-pin header
Connector location: CPLD_JP1
1 6
Pin Definition
1 V3P3_VSB
2 GND
3 JTAG_CPLD_TCK
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
4 JTAG_CPLD_TDO
5 JTAG_CPLD_TDI
6 JTAG_CPLD_TMS

SD Card Signal Connector

Connector type: 1x9 9-pin header
Connector location: JP2
1
Pin Definition
1 VDD
2 VSS
3 DATA0
4 CMD
5 CLK
18
9
Pin Definition
6 DATA3
7 DATA2
8 DATA1
9 CD_B
