Chapter 2: Jumpers and Connectors
LED Indicators
0
2
4
6
Activity
Link
Activity
Link
1
3
5
LED
Color
Status
Off
Ethernet
Green
On
LEDs
Blinking
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Description
No connection
Ethernet connected
Data transferring
16
SW1
SW2
SW3
PWR
LED
Color
Status
Amber
SW1
Green
Off
SW2
Green
On
Off
SW3
Green
On
PWR
Red
Steady
(Power)
Green
Steady
Description
User define
User define
Power down
User define
Power down
User define
Standby
Power on
DTA1376 Series User Manual
