Chapter 1: Product Introduction
Rear Panel
12V DC
LAN0 to LAN6
Input
Copper Ports
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Reset
Power
Button
Button
RJ45 Console
USB 3.0
4
12V DC Input
Used to plug a DC power cord.
LAN0 to LAN6 Copper Ports
Used to connect network devices.
Reset Button
Press and hold 4 seconds using a pin or paperclip to restart the system.
RJ45 Console Port
Used to connect to a PC using a DB9 to RJ45 console cable for configuration.
USB 3.0 Port
Used to connect a USB 3.0/2.0 device.
Power Button
Press to power on or off the system.
