AccuPyc 1330
8. Remove the rear panel by removing the retaining screws that hold the panel
in place.
9. Lift the side panels at the rear of the pycnometer and rotate forward as
shown in Figure A-4A. After about 100 degrees rotation, the assembly
should lock in an upright position as shown in Figure A-4B.
September 1996
Figure A-3. Removing Rear Panel
A
Figure A-4. Rotating Top Panel
APPENDIX A
B
A-3
