Equipment Setup
Before inserting the software card, make sure the instrument is turned
OFF (O). Do NOT install or remove the software card while the power is
turned ON.
11. Hold the AccuPyc 1330 Software Card with the label facing up. Insert
The software card must be properly inserted in the pycnometer connec-
tor during operation. It is best to keep it installed at all times, even
when power to the unit is turned off.
12. Plug in the printer power cord and the pycnometer power cord.
2-6
the card (notched end first) into the connector on the rear panel of the
pycnometer and press firmly to lock into place.
Notched End of
Software Card
Figure 2-9. Inserting Software Card
AccuPyc 1330
September 1996
